Panasonic RX-SR2389 Service Manual

Service M
Stereo Radio Cassette Recorder
General:
Power Requirement:
Power Output:
Speaker:
Jacks:
Input;
Output;
Dimensions:
Weight:
Radio Section:
Radio Frequency Range:
Intermediate Frequency:
Sensitivity:
Tape Section:
Frequency Response:
Recording System:
Tape Speed:
Track System:
Panasonic
ety
4 ORDER NO. AD8806112C2
% 3 ,
= an tes '
2 ES
3,
's is, t,
Fost ye "
z
az 2
aes PW a. j
anual
Radio Cassette
RX-SR2389
Color
CR) seeteves Black Type
Panasonic
For All European
areas except United
Kingdom, F.R.
Germany.
(ZE)...For United Kingdom.
[ZG]...For F.R.Germany.
RX-SR39 MECHANISM SERIES
M@ SPECIFICATIONS
Battery; 3V(two UM-3,"AA" size batteries)
AC; 220V,50Hz with optional Panasonic AC Adaptor RD-9443HS for [Z][ZG]
240V,50Hz with optional Panasonic AC Adaptor RD-9443HE for [ZE]
HEADPHONES: 16mW(8MW x2) ... RMS(max.) STEREO
SPEAKER: 170mW ...RMS(max.) MONAURAL
3.6cm PM Dynamic Speaker(4Q)
DC IN;3V(o 2.5)
MiC: (0.25 mV, 200~600Q, @3.5)
HEADPHONES: (16Q, @3.5)
85.7(W) x124(H} x37.7(D) mm
230g without batteries
FM; 87.5~108MHz
AM; 520~1610kHz
FM: 10.7MHz
AM; 455 kHz...[Z}][ZG]
470 kHz...[ZE]
FM; 2uV/0.5 mW output(-3 dB Limit sens)
AM; 142uV/m/0.2 mW output
150 ~8000Hz
AC bias,Magnet erase
4.8cm/s
4-track 2-channeli stereo
Design and specifications are subject to change without notice.
Matsushita Electric Industrial Co., Ltd.
Central P.O. Box 288, Osaka 530-91, Japan
