EK3 User Manual Welcome to the HORWIN family! Safety instructions We will help you to use the EK3 e-scooter correctly and safely. To ensure your safety, please read this manual Product overview carefully before using the e-scooter for the first time,... -
Page 3: Safety Instructions
Safety instructions Please read the following instructions carefully for your own safety and that of others: Please read this product manual carefully, and only use this vehicle if you are mentally and physically fit to • Before riding the e-scooter, check that all safety-rel- do so. -
Page 4: Product Overview
Product overview ① Headlight ⑦ Centre stand ② Rear-view mirror ⑧ Side stand Schematic ③ Left combination ⑨ Front fender representation switch of the vehicle ⑩ Front shock absorber ④ Seat ⑪ Storage compartment ⑤ Tail light (built-in USB charging socket, max. -
Page 5: Instrument Cluster / Display
Instrument cluster / display ⑧ Motor warning light If an error occurs in the motor control, this symbol lights up. ⑨ Trip odometer Display of the current distance travelled (automatic reset after restart). ⑩ Total mileage Display of the total mileage reading. ⑪... -
Page 6: Combination Switch
Combination switch Left side Right side ① High/low beam ⑤ Main lighting • Press the switch upwards to switch on the high beam. • Press the switch down to switch off the main lighting. • Press the switch down to switch on the dipped beam. •... -
Page 7: Vehicle Lock And Radio Remote Control
Vehicle lock and radio remote control Starting the scooter Open seat Handlebar lock Radio remote control ① Activation of the alarm system ③ Pressing the button activates the acous- tic alarm system. If the radio remote control is more than approx. 2 metres away from the scooter, the alarm system ①... -
Page 8: Battery And Charger
Battery and charger In-vehicle charging mode Instructions for using batteries Battery charging interface The battery has multiple charging methods External charging mode Battery charging interface Place the battery in the battery compartment and connect the vehicle plug to the battery. Then plug the charging plug of the charger into the charging inter- face above the footboard to charge the scooter. - Page 9 Description of the battery charge level indicator on the battery Operating environment While charging, the charge level indicator shows the current bat- tery charge level. Once the battery is fully charged, all LEDs light up continuously and no longer flash. Please use the battery between -10 ℃...
- Page 10 Charging environment Precautions for using the charger • The charger should only be used indoors, under cover, or in environments protected from the weather. Please use the original charger to charge the bat- tery. Do not use chargers from other manufacturers, •...
- Page 11 Precautionary measures when putting the battery of the battery. In such a case, it is excluded from the warranty. into operation: • If the battery is stored for a longer period of time, the most suitable battery charge level is 50-70%. If the battery charge •...
-
Page 12: Driving Instructions
Methods for starting the vehicle riding. The EK3 can be started in multiple ways: with the mechanical key, the radio remote control and the touch panel on the display. Checking the vehicle before setting off ->... - Page 13 -> Method 2: Start the vehicle using the touch panel Braking instructions • Step 1: The distance between the radio remote control and • Excessive, sudden braking can cause the wheels to lock and the vehicle must be less than approx. 2 metres. skid, limiting control of the vehicle.
-
Page 14: Troubleshooting
Methods for switching off the vehicle Service and maintenance intervals Fold down the side stand; the "READY" symbol will go out on The exact maintenance and service instructions as well as the the display, the electrical system of the entire vehicle is still warranty guidelines can be found in the separate service and in "Park"... - Page 15 Error codes / control unit Error Possible Cause description troubleshooting Flashing Error codes and description Range or Low battery level Charge the battery. frequency speed reduced The tyre pressure is Check the tyre pressure of the LEDs before every ride. insufficient.
-
Page 16: Technical Data And Dimensions
Technical data and dimensions Cleaning the vehicle Please mix tap water and neutral detergent to clean the vehicle. After cleaning the vehicle, wipe the surface with a soft cloth. Do not clean your vehicle directly with a strong jet of water (e.g., high-pressure cleaner, etc.), which can cause faults or damage to mechanical and electrical components due to moisture. -
Page 17: Space For Comments
Space for comments Parameters Motor type DC mid-motor Rated power 3.5 kW Max. power 6.2 kW Maximum speed 95 km/h Range (EEC test) max. 76 km (1 x 72 V 36 Ah) Battery capacity 36 Ah Battery type Lithium battery Display Vehicle lighting system Brake system... - Page 18 Space for comments Space for comments...
- Page 19 HORWIN Europa-Zentrale HORWIN Global Headquarters A-2033 Kammersdorf 173 Building 1 | No. 5 Chuangzhi Road Central warehouse: A-2034 Großharras 77 Tianning District | Changzhou | Jiangsu | China www.horwin.eu www.horwinglobal.com Subject to errors, printing and typesetting errors as well as technical changes.
