- Page 1 HORWIN EK1 USER MANUAL...
-
Page 2: Table Of Contents
EK1 User Manual Welcome to the HORWIN family! EK1 User Manual We will help you to use the EK1 e-scooter correctly and Safety instructions safely. To ensure your safety, please read this manual carefully before using the e-scooter for the first time,... -
Page 3: Safety Instructions
Safety instructions Please read the following instructions carefully for your own safety and that of others: Please read this product manual carefully, and only use this vehicle if you are mentally and physically fit to • Before riding the e-scooter, check that all safety-rel- do so. -
Page 4: Product Overview
Product overview ① Headlight ⑦ Centre stand ② Rear-view mirror ⑧ Side stand Schematic ③ Left combination ⑨ Front fender representation switch of the vehicle ⑩ Front shock absorber ④ Seat ⑪ Storage compartment ⑤ Tail light (built-in USB charging socket, max. -
Page 5: Instrument Cluster / Display
Instrument cluster / display EK1 Light riding mode speeds: • The maximum speed in the 1st riding mode is up to 15 km/h • The maximum speed in the 2nd riding mode is up to 20 km/h • The maximum speed in the 3rd riding mode is up to 25 km/h ⑦... -
Page 6: Combination Switch
Combination switch Left side Right side ① Left-hand combination switch with high beam and dipped ⑤ Right-hand combination switch with main lighting beam • Press the switch down to switch off the main lighting. • Press the switch upwards to switch on the high beam. •... -
Page 7: Vehicle Lock
Vehicle lock Battery and charger Instructions for using batteries The battery has multiple charging methods Open Start seat External charging mode Battery charging interface Keyhole Handlebar lock Starting the scooter Insert the mechanical key and turn it to the "Start" position to switch on the vehicle. Turn the key back to the "Off"... - Page 8 Description of the battery charge level indicator on the battery In-vehicle charging mode While charging, the charge level indicator shows the current bat- tery charge level. Once the battery is fully charged, all LEDs light up continuously and no longer flash. Battery charging interface The current charge level is displayed by pressing the button next to the charge indicator - one LED corresponds to 20% charge...
- Page 9 Operating environment Charging environment Please use the original charger to charge the bat- Please use the battery between -10 ℃ and 45 ℃. tery. Do not use chargers from other manufacturers, brands or types to charge the battery. Please prevent the battery from coming into contact Please charge the battery at an ambient temperature with liquids, such as water, cleaning agents, etc.
- Page 10 Precautions for using the charger of the battery. In such a case, it is excluded from the warranty. • The charger should only be used indoors, under cover, or in • If the battery is stored for a longer period of time, the most environments protected from the weather.
-
Page 11: Driving Instructions
Driving instructions Precautionary measures when putting the battery into opera- tion: Precautionary measures before beginning your ride • When using the battery for the first time, please discharge it as much as possible, and then fully charge it before the next If you are impaired due to the consumption of alcohol or drugs, use. - Page 12 • Tyre surface for cracks, damage, wear or foreign objects ad- • When riding in wet, rainy conditions or on soft surfaces, hering to the tyre the manoeuvrability and braking ability of the scooter are • Observe the legal tread depth (seasonal and country-specific impaired.
-
Page 13: Troubleshooting
Troubleshooting Switching off the vehicle 1. Fold down the side stand; the "READY" symbol will go out on Troubleshooting on the vehicle the display, the electrical system of the entire vehicle is still in "Park" mode, and the vehicle will not move off when the Error Possible Cause... - Page 14 Error codes / control unit Cleaning the vehicle Please mix tap water and neutral detergent to clean the Flashing frequency vehicle. After cleaning the vehicle, wipe the surface with a Error codes and description of the LEDs soft cloth. Overvoltage protection The battery voltage is too Do not clean your vehicle directly with a strong jet of water high.
-
Page 15: Technical Data And Dimensions
Technical data and dimensions EK1 Light Motor type DC hub motor Rated power 2.0 kW 1.0 kW Max. power 2.8 kW 1.5 kW Maximum speed 45 km/h 25 km/h Range max. 69 km (72 V 26 Ah) max. 86 km (72 V 26 Ah) max. -
Page 16: Space For Comments
Space for comments... - Page 17 HORWIN Europa-Zentrale HORWIN Global Headquarters A-2033 Kammersdorf 173 Building 1 | No. 5 Chuangzhi Road Central warehouse: A-2034 Großharras 77 Tianning District | Changzhou | Jiangsu | China www.horwin.eu www.horwinglobal.com Subject to errors, printing and typesetting errors as well as technical changes.
