PSC-55 Pyrometer Series Operation Manual
Variable Focus Optics
The variable Focus optics version uses an internal motor to focus. The measurement
distance can be set in 8 steps (via software or on the back of the IR sensor).
PSC-S55NL / PSC-S55NT / PSC-S55NV Optical data – Variable Focus optics with motor focus
Measurement distance a [mm]
Measuring
Apertu
temperature
re
D
range
[mm]
550 °C to 1500 °C
10
600 °C to 1800 °C
6.0
800 °C to 2500 °C
8.0
900 °C to 3000 °C
4.0
600 °C to 3000 °C
4.0
PSC-G55N / PSC-G55NT / PSC-G55NV Optical data – Variable Focus optics with motor focus
Measurement distance a [mm]
Measuring
Aperture
temperature
D [mm]
range
200 °C to 1200 °C
10
250 °C to 1500 °C
8.0
350 °C to 2000 °C
5.0
250 °C to 2500 °C
3.5
200 °C to 2000 °C
5.0
PSC-GE55N / PSC-GE55NT / PSC-GE55NV Optical data – Variable Focus optics with motor focus
Measurement distance a [mm]
Measuring
Aperture
temperature
D [mm]
range
75 °C to 650 °C
10
100 °C to 800 °C
8.0
150 °C to 1200 °C
6.0
150 °C to 2200 °C
6.0
240
360
540
800
Target size M [mm]
1.5
2.3
3.4
5.0
1.0
1.5
2.3
3.4
1.0
1.5
2.3
3.4
1.0
1.5
2.3
3.4
1.0
1.5
2.3
3.4
240
360
540
800
Target size M [mm]
1.5
2.3
3.4
5.0
1.0
1.5
2.3
3.4
1.0
1.5
2.3
3.4
1.0
1.5
2.3
3.4
1.5
2.3
3.4
5.0
240
360
540
800
Target size M
[mm]
*)
3.7
5.5
8.3
12
3.0
4.5
6.8
10
1.5
2.3
3.4
5.0
2.4
3.6
5.4
8.0
1200
1800
2500
4000
7.5
11
16
25
5.0
7.5
11
17
5.0
7.5
11
17
5.0
7.5
11
17
5.0
7.5
11
17
1200
1800
2500
4000
7.5
11
16
25
5.0
7.5
11
17
5.0
7.5
11
17
5.0
7.5
11
17
7.5
11
16
25
1200
1800
2500
4000
19
28
39
62
15
23
31
50
7.5
11
16
25
12
18
25
40
20
