PSC-55 Pyrometer Series Operation Manual
Device data PSC-GE 55N
Device type
Temperature range
Sub range
Spectral range
Measurement value processing
Emissivity ε
Response time t
95
Data storage
1)
Measurement uncertainty
1)
Reproducibility
Ambient temperature
dependence, static 4)
Transmittance
Ambient radiation
NETD 2)
Output
Interface
Aiming
Switching output/
Switching threshold
Operating and display elements
Parameters
Power supply
Power consumption
Operating temperature
PSC-GE55NL / PSC-GE55NT Series
75 °C ... 650 °C
100 °C ... 800 °C
150 °C ... 1200 °C
150 °C ... 2200 °C
Adjustable within temperature range, minimum span 50 °C
2.0 µm ... 2.6 µm
digital
0.050 ... 1.000
2 ms (min.) 3) , adjustable up to 100 s
minimum/maximum value storage
0.5 % of measured value in °C + 2 K
0.3 % of measured value in °C + 1 K
< 0.1 K/K (T )
ambient
50 % ... 100 %
adjustable within temperature range
0.5 K 1)
0/4 mA to 20 mA temperature linear, burden max. 500 Ω (galvanically
isolated)
RS-485 (galvanically isolated), half duplex, max. 115 kBd, Modbus RTU
PSC-GE55NL laser aiming light, 630 nm to 680 nm, class II, < 1 mW,
PSC-GE55NT Through Lens Sighting
1 opto relay, R min. 48 Ω (galvanically isolated)/
Load
adjustable within temperature range, 24 V DC, max. 500 mA, reaction
time approx.. 4 ms
two push-buttons for „Parameter menu, "Enter", "Up" and "Down",
OLED with standard display of temperature and emissivity, pilot light
button (option)
adjustable via interface and software:
emissivity, transmittance, ambient radiation, response time, temperature
unit °C or °F, data storage settings, sub range of measurement output,
switching thresholds of switching output, motor focus
adjustable on the device, too: Emissivity, motor focus
24 V DC ± 25 %, residual ripple 500 mV
max. 1.5 W (without load at switching output)
0 °C ... 45 °C
13
