KPM PROCESS SENSORS PSC-S55N Operation Manual page 17

PSC-55 Pyrometer Series Operation Manual
Device type
Parameters
Parameters
Power supply
Power consumption
Operating temperature
Storage temperature
Weight
Housing
Protection class
Test regulations
CE symbol
Scope of delivery
Factory settings
1) Specifications for black body radiator, T
2) Noise equivalent temperature difference.
3) With dynamic adaption at low signal level.
4) Operating temperature limited to 50 °C to avoid injury.
5) Deviation from T = 23 °C, T
ambient
PSC-SR55NL/ PSC-SR55NT / PSC-SR55NV
adjustable via interface and software:
ratio correction, emissivity, transmittance, response time, temperature
unit °C or °F, data storage settings, sub range of measurement output,
switching thresholds of switching outputs, motor focus, operation mode
(ratio or 1-channel mode)
PSC-SR55NV: Exposure time, brightness, contrast and sharpness of
video image
adjustable on the device, too: ratio correction/emissivity, motor focus
adjustable via interface and software:
ratio correction, emissivity, transmittance, response time, temperature unit
°C or °F, data storage settings, sub range of measurement output,
switching thresholds of switching outputs, motor focus, operation mode
(ratio or 1-channel mode)
PSC-SR 55NV: Exposure time, brightness, contrast and sharpness of video
adjustable on the device, too: ratio correction/emissivity, motor focus
24 V DC ± 25 %, residual ripple 500 mV
max. 1.5 W (without load at switching output)
0 °C ... 70 °C
–20 °C ... 70 °C
approx. 750 g
stainless steel round housing with plug connector
Dimensions: length approx. 105 mm (without through-lens sighting),
 50 mm
IP 65 according to DIN EN 60529 and DIN 40050
EN 55 011: 1998, limit class A
According to EU regulations
PSC-SR55N, manual, inspection sheet, software PSCspot, without
connection cable
ε = 1, K = 1, [n = 1.30,] response time min. (5 ms), transmittance 100 %,
sub range = temperature range, clear time off, address 01, 19.2 kBd, output
4 to 20 mA, switching threshold 990/1000 °C. (other settings on demand)
= 23 °C, t95 = 1 s.
ambient
= 1000 °C.
object
