PSC-55 Pyrometer Series Operation Manual
Aiming
Switching output/
Switching threshold
Operating and display elements
Parameters
Power supply
Power consumption
Operating temperature
Storage temperature
Weight
Housing
Protection class
Test regulations
CE symbol
Scope of delivery
Factory settings
Device Type
1) Specifications for black body radiator, T
2) Noise equivalent temperature difference.
3) With dynamic adaption at low signal level.
4) Operating temperature limited to 50 °C to avoid injury.
5) Deviation from T = 23 °C, T
ambient
PSC-S55NL / PSC-G55NL: laser aiming light, 630 nm to 680 nm, class
II, < 1 mW.
PSC-S55NT / PSC-G55NT Through Lens Sighting
PSC-G55NV / PSC-S55NV: video camera, composite video signal PAL
(B), 50 Hz (galvanically isolated) or NTSC (M), 60 Hz
1 opto relay, R min. 48 Ω (galvanically isolated)/
Load
adjustable within temperature range, 24 V DC, max. 500 mA, reaction
time approx.. 4 ms
two push-buttons for „Parameter menu", „Enter", „Up" and „Down",
OLED with standard display of temperature and emissivity, pilot light
button (option)
adjustable via interface and software:
emissivity, transmittance, ambient radiation, response time, temperature
unit °C or °F, data storage settings, sub range of measurement output,
switching thresholds of switching output, motor focus
PSC-S55NV/PSC-G55NV: Exposure time, brightness, contrast and
sharpness of video image
adjustable on the device, too: Emissivity, motor focus
24 V DC ± 25 %, residual ripple 500 mV
max. 1.5 W (without load at switching output)
0 °C ... 70 °C
–20 °C ... 70 °C
approx. 750 g
stainless steel round housing with plug connector
Dimensions: length approx. 105 mm (without through-lens),  50 mm
IP 65 according to DIN EN 60529 and DIN 40050
EN 55 011: 1998, limit class A
according to EU regulations
PSC-S55N /PSC-G55N, manual, inspection sheet, software PSC Spot,
without connection cable
ε = 1, response time min. (2 ms), transmittance 100 %, sub range =
temperature range, clear time off, address 01, 19.2 kBd, output 4 to 20
mA, switching threshold 1000/990 °C. (other settings on demand)
PSC-S55N / PSC-S55NV
= 23 °C, t = 1 s.
ambient 95
= 1000 °C.
object
PSC-G55N / PSC-G55NV
