d mi
o u t d o o r l i v i n g
12'×20' LOUVERED PERGOLA
WITH ALUMINUM ROOF
ASSEMBLY MANUAL
MODEL#: LGMF1605B
Missing part? Damaged? Contact us via email at
service@domioutdoorliving.com
www.domioutdoorliving.com
©
Copyright 2022-2024 domi LLC. I All Rights Reserved.
Advertisement
Related Manuals for domi outdoor living LGMF1605B
Summary of Contents for domi outdoor living LGMF1605B
- Page 1 12'×20' LOUVERED PERGOLA WITH ALUMINUM ROOF ASSEMBLY MANUAL MODEL#: LGMF1605B Missing part? Damaged? Contact us via email at service@domioutdoorliving.com www.domioutdoorliving.com © Copyright 2022-2024 domi LLC. I All Rights Reserved.
- Page 2 -Maximum weight capacity is 1000 pounds. -If moderate to heavy snow is forecast, open the lovers to avoid snow accumulating.
- Page 3 12' x 20' Louvered Pergola Dimension 120X120mm (4.72"X4.72")
- Page 4 MOUNTING BLUEPRINT Pergola 12' x 20' (146.89") (6.85") (6.85")
- Page 5 67mm(2.64 ) 35mm 1.38 If the deck is hard wood and If the ground is concreted and the depth the depth of it is over 3 inch of it is over 3 inch you can use 1/4 inch you can use 5/16 in. ×4 in. expansion bolts to mount the pergola.
- Page 7 Step 1: Connect Part #A and Part #F with 4 Bolts 1# as shown. Repeat the above procedures to assemble the other 3 posts.
- Page 8 Step 2: Connect Part #Ab and Part #F with 4 Bolts 1# as shown. Repeat the above procedures to assemble another post.
- Page 9 Step 3: Insert Part #J into Part #B1. Secure with 2 Bolts 1# and 2 Bolts 9# as shown. Repeat the above procedures to assemble another beam.
- Page 10 Linkage Rod Step 4: Insert Part #K into the hole on Linkage Rod of Beam #B1. Secure with Nut 6# and gasket as shown. Linkage Rod Repeat the above procedures to assemble another beam.
- Page 11 Step 5: Insert 2 Part# H into Part #B3 and Part #B4 with 10 Bolts 1# as shown. Repeat the above procedures to assemble another beam.
- Page 12 Form Main Framework Step 6: Install 8 Bolts 2# to secure Beam #B1 and Beam #B3/B4 with Post #A, then install Part #G into Corner Post #A as shown. Repeat the above procedures to assemble the other three sides. ATTENTION: Don't tighten the bolts before all bolts are in the correct place.
- Page 13 Install Center Post Step 7: Install 4 Bolts 2# to secure Assembled Beam (Part #B3 & B4) with Post #Ab, then install Part #G1 into Post #Ab as shown. ATTENTION: Don't tighten the bolts before all bolts are in the correct place. Repeat the above procedures to assemble another side.
- Page 14 Install Center Beam Step 8: Place Part #B on the middle joint of Part #B3 and Part #B4 with 4 Bolts 1# as shown. Repeat the above procedures to assemble another side. Left Side Right Side...
- Page 15 Step 9: Connect Part #B and Part #Ab with Part #Y and secure with 4 Bolts 1# as shown. Repeat the above procedures to assemble another side.
- Page 16 Step 10: Install Part #C on the inside of Part #B3 with 6 Bolts 3# as shown. Repeat the above procedures to assemble another side. Inside View...
- Page 17 Linkage Rod Step 11: Linkage Rod ② Fix another part of Part #L on Part #J ①Insert the connecting rod end of Part #L with 2 Bolts 8#, nuts and gaskets. into Part #K and secure with 1 Nut 7# and gasket.
- Page 18 Step 12: Install Part #E with Bolts 10# as shown. ※ If moderate to heavy snow is forecast, pls open the louvers to avoid snow accumulating. Install Louvers...
- Page 19 Louver Close Louver Fully Louver Half State Open State Open State Step 13: Just shake the roller rod anytime you want let the sun in or block the sunray. (ATTENTION: Louvers can be opened and closed in cycles.) Please make sure that the Louvers were fully closed for waterproof effect.
- Page 20 Thanks for your purchase. At domi outdoor living, we believe in our products. That’s why we provide a 12-month warranty and friendly, casy-to-reach after-sales service. So if you have any questions about our product and assembly- ,please feel free to contact us.
