Kimo Instruments TJ Series User Manual

Pressure connection
Liquid density
Receiver
STEP 1 : FIX THE LIQUID COLUMN MANOMETER
Fix the manometer on a wall or a vertical wall with 2 screws Ø 5mm maximum.
➢
Set the horizontality of the manometer with the incorporated level and its setting screw.
➢
It is recommended to use a precise level to get a better precision The precise level must be
placed above the manometer.
➢
point of the graduation.
➢
pour the manometer fluid up to the zero point of the graduation.
➢
connection has a o'ring seal.
➢
effect to wet the liquid column).
➢
INSTALLATION OF AN INCLINED LIQUID
COLUMN MANOMOETER
Setting screw of the level
Unscrew the pressure connection situated above the receiver and pour the manometer fluid up to the zero
NB : If your manometer has safety connections, remove the two measure connections of the manometer and slowly
Screw the pressure connection (solid but moderated tightening). It is not necessary to strongly tight because the
With a squeeze bulb, a pump or a pressure generator, send up the fluid up to the full scale of the ruler (this has the
Wait 2 to 3 minutes until the stabilization of the fluid.
Spirit level
Knurled setting screws
Pressure connection
Sliding ruler
For proper measurements, the bubble
of the spirit level must be between the
two lines.
OK
Out of tolerance
