Summary of Contents for AgXcel GX30iVRT
- Page 1 2106 F AVENUE KEARNEY NE 68847 877.218.1981 ariable echnology (S & n wath wath nStallation uide wath wath info@agxcel.com www.agxcel.com REV.08302021.v2 877.218.1981 INFO@AGXCEL.COM WWW.AGXCEL.COM...
-
Page 2: Table Of Contents
GX30i Valve Assembly Layout ............7 - 8 GX30iVRT (NON-SWATH) The AgXcel GX30i VRT design is based off of the abil- The GX30I VRT Module (Non Swath) ..........9 - 11 ity to control system pressure when used in the ap- plication of liquid fertilizer in agriculture variable rate Diagram of a One Section GX30i Configuration (Non Swath) .. -
Page 3: About The Valve
The only variance is ensuring that the proper tubing or hose size is installed for the proper GPA per row that is being applied. As a rule of volume AgXcel uses the following data --... -
Page 4: Suggested Install Starting Point
AGXCEL LIQUID APPLICATION THINGS TO CONSIDER Locate on the planter (or implement) where the brackets will be mounted. Determine if the bracket will be mounted in the front or rear of the implement. Once all the brackets are mounted, begin to plumb all GX30i Valves. -
Page 5: Gx Manifold Overview
NOT SHOWN 1/2” BOLT KIT 38446 GXUBolt 7 X 5 X 1/2” *AGXCEL STOCKS A VAST ARRAY OF UBOLT SIZES TO MOUNT OUR SYSTEMS TO MOST ANY IMPLEMENT. *AGXCEL STOCKS A VAST ARRAY OF UBOLT SIZES TO MOUNT OUR 877.218.1981 INFO@AGXCEL.COM... - Page 6 Packed with viscosity fertilizers? AgXcel’s GX6 was designed to address these The AgXcel GX6 system utilizing a dual metering manifold is a great way to plumb 25682 LOCK U-CLIP all the important options for managing either in furrow fertilizer issues and fertilizer types.
-
Page 7: Gx30I Valve Assembly Layout
AGXCEL LIQUID APPLICATION VALVE ASSEMBLY LAYOUT There are a variety of configurations for the GX30i valves. However, the most common will be 3/8” QC with 3/8” tubing or 3/8” barb with 3/8” hose. When the GX30i is used in conjunction with a floating ball manifold the line out of the wilger tops will be split prior to reaching the dual valves and properly re-integrated after the valves. - Page 8 This is the base assembly of every GX30iVRT Valve body per row. The only changes will be the inlet/outlet components depending on how the rows are plumbed or using metering...
-
Page 9: The Gx30I Vrt Module (Non Swath)
AGXCEL LIQUID APPLICATION AGXCEL LIQUID APPLICATION GX30iLite VRT - (Non-Swath) MODULE KIT The GX30iLite Module is an intelligent pressure monitoring system. Set your high and low pressure thresholds by simply adjusting the two screws as illustrated below. This should be while testing the system with water so as not to waste fertilizer. - Page 10 AGXCEL LIQUID APPLICATION GX30iLite VRT - (Non-Swath) Light Status: Green LED for Valve Set 1 – On when Valve set 1 (Low-Threshold Valves) is turned on Green LED for Valve Set 2 – On when Valve set 2 (High-Threshold Valves) is turned on Red LED for Status –...
- Page 11 YouTube channel - search AgXcel! Visit our website for more info or watch the GX30IVRT video on our YouTube channel search AgXcel! ** IMPORTANT: GX30 System battery cable must be connected directly to the battery. Any alteration will void warranty** 877.218.1981...
-
Page 12: Diagram Of A One Section Gx30I Configuration (Non Swath)
AGXCEL LIQUID APPLICATION GX30iLite VRT - (Non-Swath) DIAGRAM Use the supplied harnesses to connect the valves. • Valve 1 (blue,white,black) will connect to top valves. “High Threshold” • Valve 2 (brown,white,black) will connect to bottom valves. “Low Threshold” GX30i VRT... -
Page 13: Harness Configuration For One Section (Non Swath)
AGXCEL LIQUID APPLICATION GX30iLite VRT - (Non-Swath) Harness Configuration The GX30i VRT module may be utilized to handle a simple setup like the example 6 row shown below. Using the GX30i Harness you will connect or “daisy chain” the top valves to each other, then the bottom to each other. The harness has two colored ends, black and gray. -
Page 14: Gx30Ivrt (Swath) Gxivrt Module Kit Overview
The AgXcel GX30iVRT addresses this issue with the ability to broaden this range by implementing a 3 stage orifice range system. Exhaustive testing at Agxcel has established the critical benefits of a 3 option orifice system. - Page 15 AGXCEL LIQUID APPLICATION GX30iVRT - SWATH CONTROL *Connects into rate controller* PWM connectors SIZE 54097 16pin10FT INTEGRATION EXTENSION 54099 16pin30FT 54102 16pin50FT MISC HARNESSES LINCAN GREY CHANNELS DESCRIPTION (Up to qty. 4) 55046 TRANSDUCER 10FT EXT *May require extensions* 55048...
-
Page 16: Gx30Ivrt (Non-Swath)
AGXCEL LIQUID APPLICATION GX30iVRT SWATH DIAGRAM BATTERY GX30I VRT MODULE GX30IVRT CHANNEL EXTENSION(S) HARNESSES GX30I DUAL “DAISY CHAIN”. MICRO VALVES ** IMPORTANT: GX30 System battery cable must be connected directly to the battery. Any alteration will void warranty** 877.218.1981 INFO@AGXCEL.COM... -
Page 17: Gx30Ivrt Harnessing Guide
4 Row, Single Product The GX30iVRT contains four channels allowing up to a total of 16 micro control valves (MCV) per channel (or 8 rows per channel). Harnessing together each MCV has to be done in a specific order to allow self addressing to the correct row. -
Page 18: Row, Single Product
6 Row, Single Product The GX30iVRT contains four channels allowing up to a total of 16 micro control valves (MCV) per channel (or 8 rows per channel). Harnessing together each MCV has to be done in a specific order to allow self addressing to the correct row. -
Page 19: Row, Single Product
8 Row, Single Product The GX30iVRT contains four channels allowing up to a total of 16 micro control valves (MCV) per channel (or 8 rows per channel). Harnessing together each MCV has to be done in a specific order to allow self addressing to the correct row. -
Page 20: Row, Single Product
12 Row, Single Product The GX30iVRT contains four channels allowing up to a total of 16 micro control valves (MCV) per channel (or 8 rows per channel). Harnessing together each MCV has to be done in a specific order to allow self addressing to the correct row. - Page 21 AGXCEL LIQUID APPLICATION GX30iVRT (SWATH) HARNESS GUIDE 12 Row, Single Product...
-
Page 22: Row, Single Product
16 Row, Single Product The GX30iVRT contains four channels allowing up to a total of 16 micro control valves (MCV) per channel (or 8 rows per channel). Harnessing together each MCV has to be done in a specific order to allow self addressing to the correct row. The following steps will help you set up a 16 row implement for variable rates and swath: For a 16 row implement, follow steps 1 - 8 on page 19 for an 8 row implement. -
Page 23: Row, Single Product
AGXCEL LIQUID APPLICATION GX30iVRT (SWATH) HARNESS GUIDE 16 Row, Single Product... - Page 24 AGXCEL LIQUID APPLICATION GX30iVRT (SWATH) HARNESS GUIDE 24 Row, Single Product For a 24 row implement, follow steps 1 - 8 on page 19 for an 8 row implement. After following the steps, please refer to page 22 and follow steps 1- 8 for a 16 row implement. When completed follow the below steps: YOU ARE NOW COMPLETE WITH THE VRT’S CHANNEL 1 &...
- Page 25 AGXCEL LIQUID APPLICATION GX30iVRT (SWATH) HARNESS GUIDE 24 Row, Single Product...
- Page 26 AGXCEL LIQUID APPLICATION GX30iVRT (SWATH) HARNESS GUIDE 32 Row, Single Product For a 32 row implement, follow steps 1 - 8 on page 19 for an 8 row implement. After following the steps, please refer to page 22 and follow steps 1-8 for a 16 row implement. Then refer to page 24 and follow steps 1-8 for a 24 row implement. When all steps are completed then follow the steps below: YOU ARE NOW COMPLETE WITH THE VRT’S CHANNEL 1, 2, AND 3.
- Page 27 AGXCEL LIQUID APPLICATION GX30iVRT (SWATH) HARNESS GUIDE 32 Row, Single Product...
-
Page 28: Gx30Ivrt Controller Overview
AGXCEL LIQUID APPLICATION GX30iVRT CONTROLLER OVERVIEW This guide will take you step by step on how to set up your GX30iVRT rather you are using a single product, dual prod- uct or want to set up swathing. 2. Low and High Set Valve 4. -
Page 29: Single Product
AGXCEL LIQUID APPLICATION GX30iVRT CONTROLLER SETUP Single Product Please follow the following steps to set up your GX30iVRT for single product use. If dual products are going to be used please go to page 17. Step 4 - It will ask you how many total sections you... - Page 30 1 of this guide. Step 9 - Once completed and you are at the GX30iVRT’s main page, you will see the sections you have assigned at the bottom of the screen.
-
Page 31: Dual Product
AGXCEL LIQUID APPLICATION GX30iVRT CONTROLLER SETUP Dual Product Step 4 - Step 7 - Press in the dial to edit the value of how many Ensure the amount of rows per section is sections you want product one to be. Press in the dial to correct. -
Page 32: Threshold
AGXCEL LIQUID APPLICATION GX30iVRT CONTROLLER SETUP Thresholds Setting up thresholds will decide the pressure limit for the Gx30iVRT to open and close the low set, high set, or both of the micro control valves. Step 1 - Step 4 -... -
Page 33: Swath
AGXCEL LIQUID APPLICATION GX30iVRT CONTROLLER SETUP Swath Setting up swath control will allow the GX30iVRT to communicate with your liquid rate controller to turn off and on sec- tions you have set up when needed to. Step 5 - Next the VRT will ask you how many total rows your... - Page 34 AGXCEL LIQUID APPLICATION GX30iVRT CONTROLLER SETUP Swath Step 8 - After you assign the rows for each section, you will see a section overview page. Check and ensure that all the sections and rows are present- ed on the screen. If they are then press the home button to go to the main screen.
-
Page 35: Self Address
AGXCEL LIQUID APPLICATION GX30iVRT CONTROLLER SETUP Self-Address Self addressing would allow the user to have the micro control valves (MCV) self assign their proper ID’s. In some cases the micro control valve can lose its assigned ID so going through the self address process will assign the micro control valves their proper ID. -
Page 36: Manual Override
Manual Override When needing to apply the same rate for all rows or for testing purposes, the user will be able to open and close the micro check valves using the GX30iVRT’s manual override on the settings screen. Step 1 - From the main screen, press the arrow button to go into the settings page. -
Page 37: Voltage Threshold
Voltage Threshold Some rate controllers leave voltage on the PWM line that the GX30iVRT IS CONNECTED TO. This can result to the micro control valves to stay open when there is no application being applied. Setting the GX30Ivrt’s voltage threshold to the cor- rect value can eliminate the voltage quicker. -
Page 38: Gx30 Lite (Non-Swath) Main Channel Harness
AGXCEL LIQUID APPLICATION AGXCEL LIQUID APPLICATION GX30 LITE MAIN CHANNEL HARNESS GX30 LITE MAIN CHANNEL HARNESS PRESSURE TRANSDUCER SIGNAL 12V P WR GROUND POWER 12V P WR GROUND VALVE 1 12V P WR Agxcel #54482 SIGNAL 315-209 GROUND 12-PIN SECTION... -
Page 39: Gx30Vrt (Swath) Console Harness
AGXCEL LIQUID APPLICATION AGXCEL LIQUID APPLICATION GX30VRT CONSOLE HARNESS GX30i V.R.T. CONSOLE HARNESS Agxcel #54856 319-174 26-PIN CONNECTOR Wire Size: 18G Length: 15ft HARNESS “C” DISPLAY (+) DISPLAY (+) DISPLAY (-) BATTERY (+) DISPLAY (-) BATTERY (-) CAN_H CAN_L HARNESS “C”... -
Page 40: Gx30Vrt (Swath) Signal Harness
AGXCEL LIQUID APPLICATION AGXCEL LIQUID APPLICATION GX30VRT SIGNAL HARNESS GX30i V.R.T. SIGNAL HARNESS 2P WPAK-1 A PWM SIGNAL 01 PWM 1 A PWM SIGNAL 01 HARNESS “A” PRESSURE TRANSDUCER 1 GND PRESSURE TRANSDUCER 1 PWR PRESSURE SIGNAL 01 Agxcel #54854 319-178 HARNESS “C”... -
Page 41: Gx30Vrt (Swath) Single Section Harness
AGXCEL LIQUID APPLICATION AGXCEL LIQUID APPLICATION GX30VRT SINGLE SECTION HARNESS GX30 VRT SINGLE SECTION CONNECTION HARNESS HARNESS - A Agxcel #55044 GROUND 319-192 Wire Size: 18G SECTION 2 Length: 7 FT SECTION 3 35 PIN SECTION 4 CONNECTOR SECTION 5... -
Page 42: Gx30Vrt (Swath) Dual Section Harness
AGXCEL LIQUID APPLICATION AGXCEL LIQUID APPLICATION GX30VRT DUAL SECTION HARNESS GX30 VRT DUAL SECTION CONNECTION HARNESS HARNESS - A Agxcel #55038 GROUND 319-193 Wire Size: 18G SECTION 2 Length: 7 FT SECTION 3 35 PIN SECTION 4 CONNECTOR SECTION 5... -
Page 43: Gx30Vrt (Swath) Channel Harness
AGXCEL LIQUID APPLICATION AGXCEL LIQUID APPLICATION GX30VRT CHANNEL HARNESS GX30i CHANNEL HARNESS CHANNEL 1 Agxcel #55054 319-233 14-PIN CONNECTOR CHANNEL 1 PWR CHANNEL 1 LIN CHANNEL 1 GND Wire Size: 18G CHANNEL 2 Length: 1ft RED CHANNEL 1 PWR RED CHANNEL 2 PWR... - Page 44 2106 F Ave, Kearney NE 68847 877.218.1981 REV.08302021.v2...
