AMERLITE® / AMERQUARTZ®
VINYL LINER / FIBERGLASS LIGHT NICHE
CONTENTS
General Information (US)...............................................................................................................3
Vinyl Liner Installation Instructions (US)........................................................................................3
Fiberglass Pool Wall Installation Instructions (US)........................................................................5
Technical Data...............................................................................................................................6
Replacement Parts.........................................................................................................................6
Installation Information (CANADA)..................................................................................................6
Junction/Deck Box Location Information (CANADA).......................................................................8
This niche - fixture housing must be installed by a licensed or certified electrician in accordance with the
National Electrical Code and all applicable local codes and ordinances. Improper installation will create
an electrical hazard which could result in death or serious injury to pool users, installers or others due to
electrical shock, and may also cause damage to property. Read and follow the specific instructions below.
Before installing this product, read and follow all warning notices and instructions accompanying this niche. Failure
to follow safety warnings and instructions can result in severe injury, death, and property damage.
Call (800) 831-7133 for additional free copies of these instructions.
Attention Installer.
This manual contains important information about the installation, operation and safe use of this
product. This information should be given to the owner/operator of this equipment.
10951 West Los Angeles Ave., Moorpark, CA 93021 • (800) 831-7133 or (805) 553-5000
INSTALLATION INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
For use with Pentair wet niche light fixtures 783XXX, 784XXX, 788XXX, and 789XXX.
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION!
IMPORTANT NOTICE
© 2024 Pentair. All rights reserved. WWW.PENTAIR.COM
1620 Hawkins Ave., Sanford, NC 27330 • (800) 831-7133 or (919) 566-8000
NOTE
DANGER
WARNING
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pentair AMERLITE
Summary of Contents for Pentair AMERLITE
-
Page 1: Table Of Contents
Installation Information (CANADA)....................6 Junction/Deck Box Location Information (CANADA)...............8 NOTE For use with Pentair wet niche light fixtures 783XXX, 784XXX, 788XXX, and 789XXX. DANGER RISK OF ELECTRICAL SHOCK OR ELECTROCUTION! This niche - fixture housing must be installed by a licensed or certified electrician in accordance with the National Electrical Code and all applicable local codes and ordinances. - Page 2 Failure to do so could result in death or serious injury to serviceman, pool users or others due to electrical shock. READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL. WARNING — Important Safety Information for Pentair Niche and Light Installation •...
-
Page 3: General Information (Us)
NOTE The required orientation of all Pentair lights is with the pilot screw at the 12 o’clock position. This is guaranteed by proper niche installation. 5. Bond the niche-fixture housing to all other metallic items within five (5) feet of the pool, using a No. 8 AWG bond wire. - Page 4 Junction Box to the bonding/grounding lug inside the niche. Seal the wire/lug connection with a listed sealant such as Pentair P/N 60028300 or equivalent, to protect the connection from possible pool water corrosion. See figure 2. See NEC 680.23 code requirment.
-
Page 5: Fiberglass Pool Wall Installation Instructions (Us)
Junction Box to the bonding/grounding lug inside the niche.Seal the wire/lug connection with a listed sealant such as Pentair P/N 60028300 or equivalent, to protect the connection from possible pool water corrosion. See figure 3. See NEC 680.23 code requirment. -
Page 6: Technical Data
79205100 Screw kit, niche, Pentair's 8 hole 79200700 Gasket, set, std. 10 hole pattern, w/ double wall gasket 79205200 Screw kit, niche, Pentair's 8 hole, extra long 98202600 Screw, sealing 1/4-20 X 1 in. phillips flat head 79205400 Screw kit, niche, 10 hole, w/o double wall gasket 98202700 Screw, sealing 1/4-20 X 1-1/4 in. - Page 7 Figure 4. NOTE The required orientation of all Pentair lights is with the pilot screw at the 12 o’clock position. This is guaranteed by proper niche installa- tion. 6. Be sure the niche is properly electrically bonded via the No. 6 AWG ground connector located at the rear of the niche.
-
Page 8: Junction/Deck Box Location Information (Canada)
1620 HAWKINS AVE., SANFORD, NC 27330 • (919) 566-8000 10951 WEST LOS ANGELES AVE., MOORPARK, CA 93021 • (805) 553-5000 All indicated Pentair trademarks and logos are property of Pentair. Third party registered and unregistered trademarks and logos are the property of their respective owners.
