ROLLING ADJUSTABLE LAPTOP CART
MODEL RTA-B003
ASSEMBLY INSTRUCTIONS
REV.SA-7283-0423
Thank you for purchasing our product
FRENCH
ARABIC
Scan QR to view the
Scan QR to view the
manual in French
manual in Arabic

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTA-B003 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Techni Mobili RTA-B003

Summary of Contents for Techni Mobili RTA-B003

  • Page 1 ROLLING ADJUSTABLE LAPTOP CART MODEL RTA-B003 ASSEMBLY INSTRUCTIONS REV.SA-7283-0423 Thank you for purchasing our product FRENCH ARABIC Scan QR to view the Scan QR to view the manual in French manual in Arabic...

  • Page 2: Main Parts List

    RTA-B003 Replacement Parts for International Customers & Do a quick inventory Support & Replacement AK-HI-PR orders: of all the parts and Parts for the 48 contiguous hardware listed below. United States: RTA Products will replace the part free of charge,...
  • Page 3 RTA-B003 BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS. • Please read the assembly instructions throughly and follow step by step. 30mm • Make sure you understand which hardware will be used on each step. Using...

  • Page 4: Assembly Steps

    RTA-B018 ASSEMBLY STEPS I nsert casters A and B into bottom frame 4. Please note location of the locking STEP 1 casters A. Hardware/Tools: LOCKING CASTER LOCKING CASTER Assemble the middle frame 5 to the bottom frame 4 with screws G from STEP 2 above and nuts J from below, making...
  • Page 5 RTA-B018 Attach the tilt plate 6 to the round tube on the top frame 3 with E. STEP 3 Hardware/Tools: STEP 4 Assemble the supports 8 to the square tube on frame 3 with screws F from above and nuts J from below Please note that the supports go with Hardware/Tools: their indented holes facing UP to accomodate the screw heads.
  • Page 6 RTA-B018 WE RECOMMEND TO PLACE THE PIECES OVER BLANKETS TO PROTECT THEIR FINISH DURING ASSEMBLY. With the main panel 1 upside-down, place the completed top frame STEP 5 on it, making the holes on the tilt plate coincide with the set of holes in Hardware/Tools: the center of the panel, then secure the tilt plate 6 and the support 7 with screws I as shown.

  • Page 7: Function, Notes

    RTA-B018 STEP 7 7 Insert the top frame 3 into the middle tube 5, and select a desired height, making the 2 of the holes from 3 match the 2 holes on 5, then insert the Hardware/Tools: screw knobs C to leave the unit at that height. FUNCTION, NOTES ADJUST HEIGHT: TILTING:...

  • Page 8: Weight Limits

    RTA-B003 WEIGHT LIMITS 30 Lbs (13.6 Kg) 45 Lbs (20.4 Kg) WARNINGS • Do not exceed the indicated weight limits. • Do not expose the surfaces to direct sunlight or to extreme environmental conditions. • Do not use solvents or abrasive materials to clean the unit.
  • Page 9 RTA-B003 TECHNI MOBILI WARRANTY DESKS/LAPTOP CARTS/FILE CABINETS: LIMITED 5-YEAR WARRANTY RTA Products, LLC warrants to the Original Purchaser who acquired a new product from RTA Products or its authorized resellers that this product will be free from defects in its workmanship and materials, under normal use and service conditions, as described herein.
