- Page 1 SIT-TO-STAND ROLLING ADJUSTABLE LAPTOP CART WITH STORAGE MODEL RTA-B005 ASSEMBLY INSTRUCTIONS Thank you for purchasing our product Scan to view full assembly video REV.OL-6941-0922...
- Page 2 RTA-B005 • Do not discard this manual or any of the packaging material until the unit has been completely assembled. • Please read carefully the assembly instructions before the installation. • Scan this QR code to view the complete assembly video online.
-
Page 3: Main Parts List
RTA-B005 The replacement parts service is limited to Do a quick inventory Missing, damaged and defective the 48 contiguous United States. parts can be replaced at no cost of all the parts and If you reside in AK, HI, PR, U.S. territories to you. -
Page 4: Hardware List
RTA-B005 MAIN PARTS LAYOUT (For reference) HARDWARE LIST SIZE ITEM SIZE ITEM PART PART M4x14 M3x15 M5x16 M4x20 M6x35 Ø5x17 M6x40 Ø8x19 Curved connector Bolt __________ Sets Ø10x28 M6x12 Plastic washer INCLUDED TOOLS Phillips Screwdriver... - Page 5 RTA-B005 CAM BOLT AND CAM LOCK TUTORIAL THE INSTRUCTIONS BELOW ARE NOT ACTUAL ASSEMBLY STEPS This unit uses cam bolts and locks (also known as mini fixes). If you are not familiar with this kind of hardware, the below is a tutorial that explains how to use them on the steps where they are required.
- Page 6 RTA-B005 BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS. • Do not discard this manual or any of the packaging material until the unit has been completely assembled. • If during assembly you find an issue or need clarification, please contact our Customer Service for assistance.
-
Page 7: Assembly Steps
RTA-B005 ASSEMBLY STEPS STEP 1 Attach the magnet 17-A to the bottom surface of the middle upper shelf 8 with Hardware screws F. Attach the small steel plate 17-B to the inside surface of the shelf door 18 with M3x15 screws F. - Page 8 RTA-B005 STEP 3 Insert the metal pin H into the corresponding hole on panel 1. Hardware Attach the door panel 18 to the pin H, making sure the metal plate is visible as shown. Double sided pin Tools (included) Scan QR to view step STEP 4 Attach the bolts D to the right side panel 2 into the indicated holes.
- Page 9 RTA-B005 STEP 6 Screw the bolts D into the indicated holes on the top surface of panel 7. Hardware Join the main frame to the base and lock the pieces together by turning the cam locks on panels 1, 2 and 4 as shown and as explained in page 4.
- Page 10 RTA-B005 STEP 9 EXTREMELY IMPORTANT! Hardware Follow this step EXACTLY as instructed! An incorrect assembly leaves the tilting mechanism and main panel prone to moving or sliding, and Connector even might flip down forwards unexpectedly under any weight. Sets Soft plastic Place the curved connectors I over the threaded holes of the lifting tubes 10.
- Page 11 RTA-B005 P.10 P.10 STEP 10 Assemble the tilting mechanisms 13 and 14 to the main panel 12 in their Hardware respective sides with screws E. M6x12 Tools (included) Scan QR to view step ( R i ( L e f t )
- Page 12 RTA-B005 P.11 P.11 STEP 12 Lift the main panel 12 about 6 inches and tighten the screw knobs 16. Hardware Assemble the protection rail 15 to the main panel 12 with its curvature towards the front with screws B from underneath.
- Page 13 RTA-B005 P.12 P.12 ALL DONE! Give yourself a nice pat on the back, you did a great job! ENJOY YOUR NEW UNIT! FUNCTIONS / ADJUSTMENTS ROLLING: LIFTING: Unlock the front casters to Loosen the screw knobs to lift, allow free movement.
-
Page 14: Weight Limits
RTA-B005 P.13 P.13 WEIGHT LIMITS 20 Lbs (9.1 Kg) 20 Lbs (9.1 Kg) 20 Lbs (9.1 Kg) WARNINGS Do not exceed the indicated weight limits. Do not expose the surfaces to direct sunlight or to extreme environmental conditions. Do not use solvents or abrasive materials to clean the unit. - Page 15 RTA-B005 P.14 P.14 TECHNI MOBILI WARRANTY DESKS/LAPTOP CARTS/FILE CABINETS: LIMITED 5-YEAR WARRANTY RTA Products, LLC warrants to the Original Purchaser who acquired a new product from RTA Products or its authorized resellers that this product will be free from defects in its workmanship and materials, under normal use and service conditions, as described herein.
- Page 16 FOR SEVERAL HELP OPTIONS INCLUDING REPLACEMENT PARTS ORDERS VISIT: WWW.TECHNIMOBILI.COM AND CLICK ON SUPPORT TAB Or scan the following QR Code: Scan the following QR Code to order replacement parts: EMAIL US: support@rtaproducts.com...
