- Page 2 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 3: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly ................7 Safety Information ............... 2 Operation ................15 Warranty ................3 Care and Cleaning ............. 16 Pre-Installation ..............3 Troubleshooting ..............16 Installation ................6 Safety Information To reduce the risk of electric shock, ensure the electricity has WARNING: To reduce the risk of personal injury, been turned off at the circuit breaker or fuse box before you do not bend the blade brackets (also referred to as... -
Page 4: Warranty
A certain amount of “wobble” is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Hampton Bay hereby disclaims any and all warranties, including but not limited to those of merchantability and fitness for a particular purpose to the extent permitted by law. - Page 5 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Part Description Quantity Extra blade bracket screw Hanger pin Extra lock washer Locking pin Plastic wire connector Rubber gasket...
- Page 6 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Slide-on mounting bracket Blade (inside canopy) Blade bracket Ball/downrod assembly (with pre-installed screws) Canopy Glass shade Fan-motor assembly LED bulbs (9 Watt maximum) Light kit fitter assembly Remote control (battery included) Receiver IMPORTANT: This product and/or components are governed by one or more of the following U.S.
-
Page 7: Installation
Installation MOUNTING OPTIONS NOTE: You may need a longer downrod to maintain WARNING: To reduce the risk of fire, electric shock proper blade clearance when installing on a steep, sloped or personal injury, mount to an outlet box marked ceiling. The maximum angle allowable is 20° away from “Acceptable for fan support of 35 lbs. -
Page 8: Assembly
Assembly - Standard Ceiling Mount Preparing for standard mounting Routing the wires □ □ Remove the canopy ring (L) from the canopy (C) by turning Make sure the slot openings are on top and route the the ring counter-clockwise until it unlocks. wires exiting the top of the fan-motor assembly (D) □... - Page 9 Assembly - Close-To-Ceiling Mount Preparing for mounting Routing the wires □ □ Remove canopy ring (L) from the canopy (C) by turning the ring Remove three of the six screws and lock washers (QQ) (every counter-clockwise until it unlocks. other one) securing the motor collar (N) to the top of the fan- □...
- Page 10 Assembly - Hanging the Fan (continued) Setting the code on the remote control Hanging the fan and receiver WARNING: The hook (XX) is only to balance the fan while NOTE: The frequencies on your receiver and remote making the electrical connections. Failure to hang as shown control have been preset at the factory.
- Page 11 Assembly - Hanging the Fan (continued) Wiring the receiver to the Installing the receiver household wiring WARNING: To reduce the risk of fire or electric shock, WARNING: To avoid possible electrical shock, turn the remember to disconnect power. The electrical wiring must meet all local and national electrical code requirements.
- Page 12 Assembly - Hanging the Fan (continued) Making the electrical connections Outlet box in the ceiling WARNING: Each wire connector supplied with this fan is (MM) designed to accept up to one 12-gauge house wire and two wires from the fan. If you have larger than 12-gauge house wiring or more than one house wire to connect to the fan wiring, consult an electrician for the proper size wire connectors to use.
- Page 13 Assembly - Hanging the Fan (continued) Wrapping the extra wire Mounting the fan-motor assembly (standard mount) WARNING: When using the standard ball/downrod mounting, the NOTE: Follow this step ONLY if you did not cut the extra length off tab in the ring at the bottom of the mounting bracket must rest in from the wires coming from the ceiling fan to the receiver.
- Page 14 Assembly - Hanging the Fan (continued) Mounting the fan-motor assembly (close-to-ceiling mount) WARNING: The locking slots of the canopy are provided only as an aid to mounting. Do not leave the fan assembly unattended until all four canopy screws are engaged and firmly tightened. □...
- Page 15 Assembly - Attaching the lights Installing the glass shades Attaching the light kit fitter assembly and bulbs CAUTION: To reduce the risk of electric shock, disconnect WARNING: Allow the glass shades to cool completely before the electrical supply circuit to the fan before installing the removing.
-
Page 16: Operation
Operation OPERATING YOUR FAN Your fan is equipped with a remote control to operate the fan speed and lights of your new ceiling fan. The speed setting for warm or cool weather depends on factors such as the room size, ceiling height, number of fans and so on. The fan is shipped from the factory with the reversing switch positioned to circulate air downward. -
Page 17: Care And Cleaning
Repeat for each blade. Any measurement deviation should be within 1/8 in. Run the fan for ten minutes. If the fan continues to wobble please contact Hampton Bay Customer Service and a balancing kit will be sent to you at no charge. - Page 18 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ® Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-855-HD-HAMPTON HAMPTONBAY.COM...
