TCA24046 KIT, FM UP-STOP KIT EU(6), PARTS BAG IS RECOMMENDED (NOT INCLUDED WITH THIS MACHINE)
BUFFALO TURBINE'S
BT-JD1415DB / BT-JD14SDB
ORIGINAL INSTRUCTIONS AND PARTS MANUAL
03/20 -BT MAN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BUFFALO TURBINE BT-JD1415DB
Summary of Contents for BUFFALO TURBINE BT-JD1415DB
- Page 1 TEL: 716 592 2700 FAX: 716 592 2460 EMAIL: info@buffaloturbine.com WEBSITE: www.buffaloturbine.com TCA24046 KIT, FM UP-STOP KIT EU(6), PARTS BAG IS RECOMMENDED (NOT INCLUDED WITH THIS MACHINE) BUFFALO TURBINE'S BT-JD1415DB / BT-JD14SDB ORIGINAL INSTRUCTIONS AND PARTS MANUAL 03/20 -BT MAN...
-
Page 2: Table Of Contents
Declaration of Conformity BT-JD1415DB/BT-JD14SDB Parts Reference (Serial # 22452-25856) BT-JD1415DB/BT-JD14SDB Parts Reference (After Serial # 25857) BT-JD1415DB/BT-JD 14SDB Parts Sub-Assemblies Bill of Materials for BT-JD1415DB/BT-JD14SDB 17 Wiring Schematic Control Box Control Box Installation Instructions 19-20 Nozzle Options Buffalo Turbine Additional Products... -
Page 3: Introduction
This Manual covers the BT-JD1415DB / BT-JD14SDB Turbine Blower. Keep this manual handy for frequent reference and to pass on to new operators or owners. Call your Buffalo Turbine dealer or distributor if you need assistance, information, or additional copies of the manuals. -
Page 4: Safety
YOU are responsible for the SAFE operation and maintenance of your Buffalo Turbine Debris Blower. YOU must ensure that you and anyone else, who is going to operate, maintain or work around the Buffalo Turbine Blower be familiar with the operating and maintenance procedures and related SAFETY information contained in this manual. -
Page 5: Safety Decals
SAFETY DECALS The types of decals on the blower unit are shown below. Good safety requires that you familiarize yourself with the various Safety Decals, the type of warning and the area, or particular function related to that area that requires your SAFETY AWARENESS.* THINK SAFETY! WORK SAFELY! !ATTENTION! KEEP HANDS, FEET AND CLOTHING AWAY FROM POWER DRIVEN PARTS. -
Page 6: Maintenance Safety
5. Make sure all guards are in place and properly secured when operating or maintaining the Blower. TRANSPORT SAFETY Make sure you are in compliant with all local DOT regulations regarding transporting Buffalo Turbine equipment on public roads and highways. -
Page 7: Warranty Information
Obligation under this warranty shall extend for a period of 10 years from date of purchase and, at the option of Buffalo Turbine, replacement of any parts found, upon inspection by Buffalo Turbine, to be defective. -
Page 8: 3.1 Warranty Registration Form
WARRANTY REGISTRATION FORM & INSPECTION REPORT Any units not registered with Buffalo Turbine are not eligible for warranty claims This form must be filled out by the dealer and signed by both the dealer and the customer at the time of delivery Dealer’s Name... -
Page 9: Operations
TO THE NEW OPERATOR OR OWNER Buffalo Turbine Debris Blowers are designed to quickly and efficiently, blow away leaves, cuttings and other debris. The material is conveyed on a stream of high volume and velocity of air to remove it from the area of concern. When the material is removed, it gives a neat, professional look to the working area. -
Page 10: Attaching Blower To Tractor
Attaching Blower to Tractor Make sure the tractor has proper HP and is in good working order, including mounting brackets, PTO output shaft, and safety equipment. Make sure there is enough room to safely drive up to the blower. Align mounting arms of the blower unit to match the tractor mounting brackets of the tractor (underside of tractor). -
Page 11: Troubleshooting
TROUBLE SHOOTING The Buffalo Turbine Debris Blower uses a high volume and velocity of air to move material from one place to another. The system is simple and reliable requiring minimal maintenance. If you encounter a problem that is difficult to solve, even after reading through this trouble shooting section, please call your local dealer or distributor. -
Page 12: Maintenance
MAINTENANCE SECTION Maintenance Safety Set Blower on a level surface, stop engine, set park brake, remove ignition key and wait for all moving parts to stop before dismounting to service, adjust or repair. Reinstall and secure all guards removed for servicing before starting to use machine again. *We recommend wearing gloves when removing or installing the guard to avoid getting cut* Securely support machine with blocks or safety stands when changing tires or working beneath it. -
Page 13: Service Checklist
SERVICE CHECKLIST See Lubrication and Maintenance sections for details of service. Copy this page to continue record. TURN OFF TRACTOR, REMOVE KEY & DISCONNECT WIRE HARNESS BEFORE SERVICING BLOWER UNIT CODE: LUBRICATE-(L) / CHECK-(*) / CHANGE-(C) / REPLACE-(B) / CLEAN-(CL) SCHEDULED MAINTENANCE HOURS ________________________ SERVICED BY ____________________ MAINTENANCE... -
Page 14: Declaration Of Conformity
Declaration of Conformity According to EC Machinery Directive 2006/42/EC, Annex II B We, Buffalo Turbine of Springville, New York, USA herewith declare, that the following described machine/machinery part is to be incorporated into a(n) machine/assembly with other machinery to make... -
Page 18: Bill Of Materials For Bt-Jd1415Db/Bt-Jd14Sdb
BILL OF MATERIALS FOR BT-JD1415DB / BT-JD14SDB REF PAGE # DESCRIPTION 1100 3/8-24 X 1-1/4 HHCS ZINC GR 5 1101 3/8-24 X 1-1/2 HHCS ZINC GRADE 5 1102 3/8-24 X 1-3/4 HHCS ZINC 1105 3/8-24 HEX NUT ZINC PLATED GRADE 5... -
Page 20: Control Box Installation Instructions
Control Box Installation Instructions for 1400/1500 Series II Tractors First you will need to mount the control box onto the tractor. This will be done using the magnet already attached to the control box. The best place to mount the control box is under the seat as shown in Fig. 1. Run the wiring along the side of the seat to the back as shown is Fig. - Page 21 1500 Series II: The battery is mounted next to the engine. The control box wiring needs to be run along the tractors other wiring then down to battery in order to be connected (Fig 6 & 7). In addition, the wire that connects to the blower must run to the front of the tractor guided along with the tractors already existing wiring and then zip-tied together.
