- Page 1 BUFFALO TURBINE 180 Zoar Valley Road Springville, NY 14141 TEL: 716 592 2700 FAX: 716 592 2460 EMAIL: info@buffaloturbine.com WEBSITE: www.buffaloturbine.com BUFFALO TURBINE'S BT-CPTOM ORIGINAL INSTRUCTIONS AND PARTS MANUAL 12/19 -BT MAN...
-
Page 2: Table Of Contents
Moreflex Coupling Installation BT-CPTOM Parts Reference (Before Serial # 29927) BT-CPTOM Parts Reference (After Serial # 29927) BT-CPTOM Parts Sub-Assemblies Gyratory Atomizing Nozzle Parts Breakdown Wiring Schematic for Control Box Bill of Materials for BT-CPTOM Nozzle Options Buffalo Turbine Additional Products... -
Page 3: Introduction
Safe, efficient and trouble-free operation of your Buffalo Turbine Monsoon requires that you and anyone else, who will be operating or maintaining the Blower, read and understand all of the safety, operation, maintenance and troubleshooting information contained within this Operator’s manual. -
Page 4: Safety
YOU are responsible for the SAFE operation and maintenance of your Buffalo Turbine Monsoon. YOU must ensure that you and anyone else, who is going to operate, maintain or work around the Buffalo Turbine Monsoon be familiar with the operating and maintenance procedures and related SAFETY information contained in this manual. -
Page 5: Safety Decals
SAFETY DECALS The types of decals on the blower unit are shown below. Good safety requires that you familiarize yourself with the various Safety Decals, the type of warning and the area, or particular function related to that area that requires your SAFETY AWARENESS.* THINK SAFETY! WORK SAFELY! !ATTENTION! KEEP HANDS, FEET AND CLOTHING AWAY FROM POWER DRIVEN PARTS. -
Page 6: Maintenance Safety
5. Make sure all guards are in place and properly secured when operating or maintaining the Monsoon. TRANSPORT SAFETY Make sure you are in compliant with all local DOT regulations regarding transporting Buffalo Turbine equipment on public roads and highways. -
Page 7: Warranty Information
Obligation under this warranty shall extend for a period of 10 years from date of purchase and, at the option of Buffalo Turbine, replacement of any parts found, upon inspection by Buffalo Turbine, to be defective. -
Page 8: Warranty Registration Form
WARRANTY REGISTRATION FORM & INSPECTION REPORT Any units not registered with Buffalo Turbine are not eligible for warranty claims This form must be filled out by the dealer and signed by both the dealer and the customer at the time of delivery Dealer’s Name... -
Page 9: Operations
TO THE NEW OPERATOR OR OWNER Buffalo Turbine Monsoon are designed to spray a fine mist of water particles to control dust. The material is conveyed on a stream of high volume and velocity of air and water to remove it from the area of concern. -
Page 10: Attaching Blower To Tractor
4.4 Attaching Blower to Tractor Make sure the tractor has proper HP and is in good working order, including mounting brackets, PTO output shaft, and safety equipment. Make sure there is enough room to safely drive up to the blower. Align mounting pins of the blower unit to match the tractor mounting brackets of the tractor. -
Page 11: Troubleshooting
5.0 TROUBLE SHOOTING The Buffalo Turbine Monsoon uses a high volume and velocity of air and water to move material from one place to another. The system is simple and reliable requiring minimal maintenance. If you encounter a problem that is difficult to solve, even after reading through this trouble shooting section, please call your local dealer or distributor. -
Page 12: Maintenance
MAINTENANCE SECTION Maintenance Safety Set Monsoon on a level surface, stop engine, set park brake, remove ignition key and wait for all moving parts to stop before dismounting to service, adjust or repair. Reinstall and secure all guards removed for servicing before starting to use machine again. *We recommend wearing gloves when removing or installing the guard to avoid getting cut* Securely support machine with blocks or safety stands when changing tires or working beneath it. -
Page 13: Moreflex Coupling Parts
INSTALLATION INSTRUCTIONS & PARTS FOR THE MOREFLEX COUPLING ALIGNMENT OF TURBINE SHAFT WITH SHAFT OF ENGINE IS CRITICAL Install keys in both shafts. Slide coupling flanges on both shafts (engine and turbine shafts) Place Moreflex coupling CENTER SECTION between coupling flanges and secure with 4 bolts and TOPLOC nuts. -
Page 14: Moreflex Coupling Installation
MOUNTING BLOWER ASSEMBLY ONTO FRAME AND ALIGNMENT RECOMMENDATIONS Install blower assembly onto frame and tighten all of the bolts. Remove all burrs and oil from the shafts and keyways (engine and blower shafts). Using the supplied gauge, align the shafts parallel to each other (very important). Check in four places around the shafts at 90... -
Page 20: Bill Of Materials For Bt-Cptom
BILL OF MATERIALS FOR BT-CPTOM REF PAGE # DESCRIPTION 1100 3/8-24 X 1-1/4 HHCS ZINC GR 5 1101 3/8-24 X 1-1/2 HHCS ZINC GRADE 5 1102 3/8-24 X 1-3/4 HHCS ZINC 1105 3/8-24 HEX NUT ZINC PLATED GRADE 5 1106...
