- Page 1 BUFFALO TURBINE 180 Zoar Valley Road Springville, NY 14141 TEL: 716 592 2700 FAX: 716 592 2460 EMAIL: info@buffaloturbine.com WEBSITE: www.buffaloturbine.com BUFFALO TURBINE'S BT-CYC8KKM ORIGINAL INSTRUCTIONS AND PARTS MANUAL 04/22 -BT MAN...
-
Page 2: Table Of Contents
(Before Serial # 26323) BT-CYC8KKM Parts Reference (Serial # 26323-35717) BT-CYC8KKM Parts Reference (After Serial # 35718) BT-CYC8KKM Parts Sub-Assemblies Gyratory Atomizing Nozzle Parts Breakdown Wiring Schematic for Control Box Bill of Materials for BT-CYC8KKM Nozzle Options Buffalo Turbine Additional Products... -
Page 3: Introduction
Safe, efficient and trouble-free operation of your Buffalo Turbine Monsoon requires that you and anyone else, who will be operating or maintaining the Blower, read and understand all of the safety, operation, maintenance and troubleshooting information contained within this Operator’s manual. -
Page 4: Safety
YOU are responsible for the SAFE operation and maintenance of your Buffalo Turbine Monsoon. YOU must ensure that you and anyone else, who is going to operate, maintain or work around the Buffalo Turbine Monsoon be familiar with the operating and maintenance procedures and related SAFETY information contained in this manual. -
Page 5: Safety Decals
SAFETY DECALS The types of decals on the blower unit are shown below. Good safety requires that you familiarize yourself with the various Safety Decals, the type of warning and the area, or particular function related to that area that requires your SAFETY AWARENESS.* THINK SAFETY! WORK SAFELY! !ATTENTION! KEEP HANDS, FEET AND CLOTHING AWAY FROM POWER DRIVEN PARTS. -
Page 6: Maintenance Safety
Cover with a weatherproof tarpaulin and tie down securely. SIGN-OFF FORM Buffalo Turbine recommends that anyone who will be operating and/or maintaining the Buffalo Turbine Monsoon must read and clearly understand ALL Safety, Operating and Maintenance information presented in this manual. ... -
Page 7: Warranty Information
Obligation under this warranty shall extend for a period of 10 years from date of purchase and, at the option of Buffalo Turbine, replacement of any parts found, upon inspection by Buffalo Turbine, to be defective. -
Page 8: Warranty Registration Form
WARRANTY REGISTRATION FORM & INSPECTION REPORT Any units not registered with Buffalo Turbine are not eligible for warranty claims This form must be filled out by the dealer and signed by both the dealer and the customer at the time of delivery Dealer’s Name... -
Page 9: Operations
TO THE NEW OPERATOR OR OWNER Buffalo Turbine Debris Monsoon are designed to spray a fine mist of water particles to control dust. The material is conveyed on a stream of high volume and velocity of air and water to remove it from the area of concern. -
Page 10: Field Operation
4.4 MODEL BT-CYC8KKM Assembly Instructions Fill engine oil to proper level. (overseas shipments) Attach both stub axle assembly (part# 2422) with 2 U-bolts each (part# 1707) and 4 nyloc nuts (part# 1180). Tighten each side at this time. Attach the tongue (part# 2421) using the 2 U-bolts (part # 1707) and 4 nyloc nuts (part # 1180), center on the frame then tighten evenly. -
Page 11: Troubleshooting
5.0 TROUBLE SHOOTING The Buffalo Turbine Monsoon uses a high volume and velocity of air and water to move material from one place to another. The system is simple and reliable requiring minimal maintenance. If you encounter a problem that is difficult to solve, even after reading through this trouble shooting section, please call your local dealer or distributor. -
Page 12: Maintenance
MAINTENANCE SECTION Maintenance Safety Set Monsoon on a level surface, stop engine, set park brake, remove ignition key and wait for all moving parts to stop before dismounting to service, adjust or repair. Reinstall and secure all guards removed for servicing before starting to use machine again. *We recommend wearing gloves when removing or installing the guard to avoid getting cut* Securely support machine with blocks or safety stands when changing tires or working beneath it. -
Page 13: Belt Maintenance
Belt Maintenance After using the Blower unit for a long period of time, the belt will stretch and wear and need replacing. REPLACING THE BELT USE THE ILLUSTRATION FROM BELOW FOR REFERENCE To change the belt follow this procedure: Remove the guard around belts and pulleys. Loosen mounting bolts and nuts (Figure 3) Remove belt. -
Page 14: Service Checklist
SERVICE CHECKLIST See Lubrication and Maintenance sections for details of service. Copy this page to continue record. TURN OFF ENGINE, REMOVE KEY & DISCONNECT BATTERY BEFORE SERVICING BLOWER UNIT CODE: LUBRICATE-(L) / CHECK-(*) / CHANGE-(C) / REPLACE-(B) / CLEAN-(CL) SCHEDULED MAINTENANCE HOURS ________________________ SERVICED BY ____________________ MAINTENANCE 8 hrs or daily... -
Page 15: Declaration Of Conformity
Declaration of Conformity According to EC Machinery Directive 2006/42/EC, Annex II B We, Buffalo Turbine of Springville, New York, USA herewith declare, that the following described machine/machinery part is to be incorporated into a(n) machine/assembly with other machinery to make... -
Page 22: Bill Of Materials For Bt-Cyc8Kkm
BILL OF MATERIALS FOR BT-CYC8KKM REF PAGE # DESCRIPTION 1100 3/8-24 X 1-1/4 HHCS ZINC GR 5 1101 3/8-24 X 1-1/2 HHCS ZINC GRADE 5 1102 3/8-24 X 1-3/4 HHCS ZINC 1104 3/8-24 X 2 HHCS ZINC GRADE 5 1105... - Page 23 The Cyclone PTO incorporates an “Advanced” direct drive The Cyclone Squared with its “Twin Turbines”, and wireless gearbox which significantly reduces routine maintenance. At controlled dual independent nozzles, in most cases can handle 238lbs, it’s the lightest, meanest turbine style PTO blower twice the work in half the time.
