Model Number: 640-1800 8" Tru Flo & Model Number: 640-1900 10" Tru Flo
VGBA
2017
Read and follow all instructions in this owner's manual and on the equipment. Failure to follow instructions can cause
severe injury and/or death.
SOFA INSTRUCTIONS
When installing and using this equipment, basic safety precautions shall always be followed, including the following: IMPORTANT
SAFETY INSTRUCTIONS. READ, FOLLOW, AND UNDERSTAND ALL INSTRUCTIONS AND WARNINGS.
Any modification that increases the flow rate of the circulation system shall require re-evaluation of the cover/grate and sump to
ensure that the flow rating of the Suction Outlet Fitting Assembly (SOFA) is not exceeded.
Missing, broken, or cracked cover/grates, sumps, mud-frames, or any other SOFA component shall be replaced before bathers are
allowed to use the pool.
Loose cover/grates shall be reattached before bathers are allowed to use the pool.
SAVE THESE INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
WARNING - SUCTION ENTRAPMENT HAZARD
Suction in suction outlets and/or suction outlet
covers which are damaged, broken, cracked,
missing, or unsecured can cause severe injury and/
or death due to the following entrapment hazards:
Hair Entrapment: Hair can become entangled in suction outlet cover.
Limb Entrapment: A limb inserted into an opening of a suction outlet
sump or suction outlet cover that is damaged, broken, cracked, missing,
or not securely attached can result in a mechanical bind or swelling of
the limb.
Designed,
Engineered &
Manufactured
in the USA.
©2020 Waterway Plastics
MAIN DRAIN OWNER'S MANUAL
WARNING:
IMPORTANT SAFETY INSTRUCTIONS. READ, UNDERSTAND, AND FOLLOW ALL WARNINGS
AND INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
USE ONLY GENUINE WATERWAY REPLACEMENT PARTS.
2200 East Sturgis Road, Oxnard CA 93030 • Phone 805.981.0262 • Fax 805.981.9403
www.waterwayplastics.com • waterway@waterwayplastics.com
Body Suction Entrapment: A negative pressure applied to a large
portion of the body or limbs can result in an entrapment.
Evisceration / Disembowelment Entrapment: A negative pressure
applied directly to the intestines through an unprotected suction
outlet sump or suction outlet cover which is damaged, broken, cracked,
missing, or unsecured can result in evisceration / disembowelment
entrapment.
Mechanical Entrapment: There is potential for jewelry, swimsuit,
hair decorations, finger, toe, or knuckle to be caught in an opening of a
suction outlet cover resulting in mechanical entrapment.
810-1800.0720
Advertisement
Related Manuals for Waterway 8 Tru Flo 640-1800
Summary of Contents for Waterway 8 Tru Flo 640-1800
- Page 1 USE ONLY GENUINE WATERWAY REPLACEMENT PARTS. Designed, Engineered & Manufactured in the USA.
- Page 2 Do not exceed the safe flow rate. Do not increase flow through system by increasing pump size or horsepower. Do not allow children to sit, play or interact with main drains or suction outlet. ©2020 Waterway Plastics 810-1800.0720...
- Page 3 4. Install all eight screws. (If this is your first time, ask where you purchased this drain exactly how to do it with the pool you bought.) 5. Align cover holes with brass inserts and install screws. ©2020 Waterway Plastics 810-1800.0720...
- Page 4 3. The design of field fabricated sumps shall be further specified by a Registered Design Professional so as to fully address the considerations of cover/grate loadings, durability, hair, finger, and limb entrapment issues, as well as features particular to the site. ©2020 Waterway Plastics 810-1800.0720...
- Page 5 8" TRU-FLOW Head Loss Curve -0.5 Flow Rate (GPM) 10" TRU-FLOW Head Loss Curve Flow Rate (GPM) WARRANTY For product registration visit: www.waterwayplastics.com. For Warranty questions or claims please contact point of purchase. ©2020 Waterway Plastics 810-1800.0720...
