AMX PLK-SB Specifications

NOTES:
1. FITS STANDARD 1-GANG WALLBOX
2-BUTTON
2.51 [63.75]
1-BUTTON
1.67 [42.42]
4.23 [107.44]
NOTICE: This drawing is the UNLESS OTHERWISE SPECIFIED:
property of AMX Corporation.
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
All information contained herein
XXX = .005
that is not generally known
TOLERANCE ON HOLE DIAMETERS:
UNDER .250 ú = +/- .005
shall be confidential except
.250 TO .500 = +.006 -.005
to the extent the information
OVER .500 = +.008 -.005
has been previously established.
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
This drawing may not be copied, ANGLES: +/- 1.0°
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
reproduced, or used as the basis
ALL DIMENSIONS IN INCHES.
for manufacture or sale without
DO NOT SCALE THIS DRAWING.
written permission.
REVISIONS
REV ECN DESCRIPTION
A RELEASE TO PRODUCTION
B 2631 AMX LOGO
C 4667 CORRECT ILLUSTRATIONS
.85 [21.48]
.30 [7.60]
REL APPR REL DATE REV APPR
NAD 3/7/01
DRAWN
TM
JM 1/31/03 JM
ENGR SERV
PICTORIAL,
RDR 4/5/01
ENGINEER
PLK-SB
KZ 1/31/03 KZ
PROD ENGR 1-BUTTON AND 2-BUTTON KEYPADS
MD 4/6/01 JM
MATL SUP
AK 1/31/03 AK
QUALITY SIZE SCALE DWG. NO.
95-2406-10
B FULL
THIRD ANGLE
PROJECTION 95-2406-10 C
DATE APPROVED
3/7/01
8/14/01
1/31/03
REV.
C
1 OF 1
SHEET
