AMX PLK-DMS Dimensional Drawing

3.33
[84.6 MM]
.29
[7.4 MM]
FROM WALL
1.54
[39.0 MM]
NOTICE: This drawing is the
property of AMX Corporation.
All information contained herein
that is not generally known
shall be confidential except
to the extent the information
has been previously established.
This drawing may not be copied,
reproduced, or used as the basis
for manufacture or sale without
written permission.
REV ECN
A --- RELEASED TO PRODUCTION
B 2331A AMX LOGO
C 6124 SHOW CONNECTOR; ADD DIMS
REL APPR REL DATE REV APPR
UNLESS OTHERWISE SPECIFIED:
NAD 6/29/00
DRAWN
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
MS 6/16/04
XXX = .005 ENGR SERV
TOLERANCE ON HOLE DIAMETERS:
RDR 4/5/01
ENGINEER
UNDER .250 ú = +/- .005
.250 TO .500 = +.006 -.005
KZ 6/16/04
PROD ENGR
OVER .500 = +.008 -.005
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
MB 4/6/01
MATL SUP
ANGLES: +/- 1.0°
SURFACE FLATNESS .003 TIR PER LINEAR INCH. AK 6/16/04
QUALITY
ALL DIMENSIONS IN INCHES.
THIRD ANGLE
DO NOT SCALE THIS DRAWING.
PROJECTION
REVISIONS
DESCRIPTION DATE APPROVED
6/29/00
8/14/01
6/16/04 DAS
PICTORIAL, PLK-DMS
(WHITE AND BLACK MODELS)
SIZE DWG. NO. REV.
SCALE
95-2405-01
B
FULL C
1 OF 1
95-2401-01-C SHEET
