Savaria K2 Troubleshooting Manual
Hide thumbs
Also See for K2:
- Owner's manual (16 pages) ,
- Owner's manual (20 pages) ,
- Installation manual (48 pages)
Advertisement
Quick Links
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Savaria K2
Summary of Contents for Savaria K2
- Page 1 Stairlift TROUBLESHOOTING GUIDE Part No. 001061 05-m11-2021...
-
Page 2: Electrical Shock Hazard
ELECTRICAL SHOCK HAZARD operation of a product that has been modified from the original Savaria design. No person or company is authorized Do not connect/disconnect wiring while the power is on. to change the design of this product without written Before servicing, disconnect all power to the equipment. - Page 3 0.9 and then 0.8 amps and then dropping eventually down to 0.4 amps when the battery is near full charge. Part No. 001061, 05-m11-2021 K2 Stairlift Troubleshooting Guide...
- Page 4 Page 4 K2 Stairlift Troubleshooting Guide Part No. 001061, 05-m11-2021...
- Page 5 Page 5 Part No. 001061, 05-m11-2021 K2 Stairlift Troubleshooting Guide...
- Page 6 There are no obstructions present on either side of the unit. - If the K2 can’t run from the seat’s direction button, try the hall calls. If they do not work, check the wiring to the motor. - If the K2 can’t run from the hall calls, reprogram them.
- Page 7 There are no obstructions present on either side of the unit. - If using the seat’s direction buttons, then check the wiring. - If using the hall calls, move closer to the K2, and replace the battery. There is an obstruction in the Down circuit.
- Page 8 - Check to make sure battery wires are not loose on board (Battery + and Battery –). - Refer to Level Seat Post in the K2 Installation Guide. Seat post is lean- ing, or seat is not level - Refer to Adjust Footrest in the K2 Installation Guide.
- Page 9 There are no obstructions present on either side of the unit. - If the K2 can’t run from the seat’s direction button, try the hall calls. If they do not work, check the wiring to the motor. - If the K2 can’t run from the hall calls, reprogram them.
- Page 10 There are no obstructions present on either side of the unit. - If using the seat’s direction buttons, then check the wiring. - If using the hall calls, move closer to the K2, and replace the battery. There is an obstruction in the Down circuit.
- Page 11 - Check to make sure battery wires are not loose on board (Battery + and Battery –). - Refer to Level Seat Post in the K2 Installation Guide. Seat post is lean- ing, or seat is not level - Refer to Adjust Footrest in the K2 Installation Guide.
- Page 12 Page 12 K2 Stairlift Troubleshooting Guide Part No. 001061, 05-m11-2021...
- Page 13 Page 13 K2 main board LED layout Part No. 001061, 05-m11-2021 K2 Stairlift Troubleshooting Guide...
- Page 14 Page 14 K2 diagnostic LEDs K2 on-board diagnostic LEDs (on carriage front panel) There are three on-board diagnostic LEDs on the main board. There are three LEDs located on the carriage front panel as shown below. LED Status State Meaning...
- Page 15 Page 15 K2 main board layout K2 DIP switch settings Switch State Function Reverses the up and down buttons on the remote CALL/SEND units Brake installed Brake not installed Beeps when running Does not beep when running Soft start/stop (when charge detected at cam)
- Page 16 Page 16 K2 main board wiring diagram K2 Stairlift Troubleshooting Guide Part No. 001061, 05-m11-2021...
- Page 17 THIS PAGE WAS LEFT INTENTIONALLY BLANK...
- Page 18 THIS PAGE WAS LEFT INTENTIONALLY BLANK...
- Page 19 THIS PAGE WAS LEFT INTENTIONALLY BLANK...
-
Page 20: Troubleshooting Guide
K2 Stairlift TROUBLESHOOTING GUIDE Part No. 001061 Copyright 2021 Savaria Concord Lifts, Inc. www.savaria.com Support 2 Walker Drive Brampton, Ontario L6T 5E1 Canada Toll free: (800) 791-7999 Fax: (905) 791-2222...
