Rize Home EZ Foundation Assembly

EZ Foundation Assembly
INCLUDED PARTS
1
Head / Foot Assembly (A)
2 pcs
Side Rail Assembly (B)
2 pcs
Center Connector (C)
1 pcs
Cross Bars (D)
10 pcs
Cover (E)
(optional)
1 pcs
NOTE: F, Q, CK, K only
recommended for use with a bed
frame that utilizes center rail.
SHOWN FOR REFERENCE: KING
REV: 07.12.24
B
A
2
3
4
NEED HELP?
1-800-444-8444
warranty@rizehome.com
5
6
1. Lay out parts (A), (B) and
(C). Start by unfolding
each (A) and (B) pieces
to form a "T", ensuring
that the open ends face
towards the center (C)
piece.
2. Connect the ends of
(A) to (C) by inserting
the tube into (C) and
pressing the snap button
on (A) until it locks
securely in place. Repeat
this step at other end.
3. Begin at one corner of
(A) & (B), connecting
the ends by inserting
the tube into (A) and
pressing the snap button
on (B) until it locks.
Repeat on remaining
corners.
4. Attach (B) to (C) by
inserting the tube of (B)
into (C) and pressing the
Snap button on (B) until
it locks securely. Repeat
this step at other end.
5. Unfold (D) and insert
each end into the
brackets on (B), ensuring
that the center hinge
faces downward and
rests snugly on the
center rail. Repeat for
the remaining.
6. Carefully stretch cover
(E) over the four corners
and zip all around.
