T R I O 2023 Trailed Folding Range (TRF) Machine Manual & Parts Book @Copyright 2023 Company No: 03272544 Sumo UK LTD, Redgates, info@sumo1.com Melbourne, York YO42 4RG 01759 319 900 VAT No: 552 0699 38...
It is required that both manuals be read and understood before using any Sumo machine. For more information contact your local dealership/Sumo directly. Please note, specifications, descriptions and illustrations in this manual are accurate, as known, at the time of publication but may be subject to change.
Contents Introduction ........................2 Contents ..........................3 Machine Range Summary ..................7 Product Specifications ................... 8 Transport Positions & Dimensions ..............10 Danger Zone ......................14 Risk Assessments ....................15 Parts Book Index ....................17 TRF4.5 Base Machine ....................17 TRF5.5 Base Machine ....................
Page 5
6.5.2.1 Standard Mounting Bracket Assembly ..............64 6.5.2.2 Front Discs Brackets – TRF4.5 Only ................65 6.5.2.3 Front Discs Gang – TRF4.5 Only.................. 66 6.5.2.4 Front Discs Brackets – TRF5.5 Only ................67 6.5.2.5 Front Discs Gang – TRF5.5 Only.................. 68 6.5.2.6 Front Discs Brackets –TRF6.5 Only ................
Page 6
Rear Lighting ....................... 102 Standard Torque Values ..................103 J a n 2 0 2 3 Rev 1 P a g e...
1. Machine Range Summary The Trio is designed for one-pass seed bed preparation, alleviating sub surface compaction and mixing stubble and soil to leave a level surface ready for seeding. It does this in three stages: Stages One The staggered low draught subsoiler legs lift and fracture the soil alleviating any compaction.
2. Product Specifications For standard machine dimensions and weight, see Cultivator Operators Manual. Note: Weights is described as the maximum laden mass but will increase with optional extras and attachments. Trio Trailed Range Code TRF4.5 TRF5.5 TRF6.5 Legs Qty Leg Spacing 500mm 500mm 500mm...
Page 9
*** Depth Wheels & Front Disc options are not compatible and can only be applied to the machine as separates – not together. Other options may be available – See Sumo website / Contact your local dealer. J a n 2 0 2 3...
It is the sole responsibility of the owner/operator to ensure the machine is correctly positioned prior to transport and complies with all local laws and regulations. For all Sumo guidelines and safety protocols, read the related Sumo Cultivator Operators Manual thoroughly. Trailed Folding Trios To achieve the dimensions given in the Cultivator Operators Manual, all trailed Trio’s must...
Page 11
Trailed Folding Trios – Transport Visuals J a n 2 0 2 3 Rev 1 11 | P a g e...
Page 12
Trailed Folding Trios with Trailed SDO Unit – Transport Visuals Transport Dimensions (Approximate) Note: Due to the fabricated and assembled construction of Sumo machines dimensions may vary and should only be used for reference. Shown dimensions are of maximum extremities (Excluding assembly/fabrication tolerances) but can be reduced/increased by adjusting implement positions, chassis/axle height/angle, and reversing pins with handles.
Page 13
TRF5.5.ABK TRF5.5.SFK TRF5.5.T.SDO 9600 TRF6.5.MP TRF6.5.FD TRF6.5.DW TRF6.5.HOMO TRF6.5.HB TRF6.5.RD 8500 TRF6.5.ABK TRF6.5.SFK TRF6.5.T.SDO 9600 * Only applies to standard Sumo Trio legs & points J a n 2 0 2 3 Rev 1 13 | P a g e...
4. Danger Zone The area marked red indicates the Danger Zone of the machine. This refers to both folded & unfolded states. Trailed Folding Trios Trailed SDO Unit The danger zone around the machine poses the following endangerments: Accidental operation of the hydraulic system can trigger dangerous movements of •...
- Rotating parts safely positioned and the parking - When folding/ brake is engaged when coupling unfolding up to the Sumo implements. Stay - Machine clear of any folding/unfolding tipping over elements. Lower wings slow and J a n 2 0 2 3...
Page 16
evenly to ensure the machine does not tip over. Be mindful of environmental factors. Falling from Operator Most alterations and Lower the machine to the floor machine Low - Mid maintenance do not to allow access for greasing require the operator the discs, checking bearings etc…...
6. Parts Book Index For older machines, see manuals & parts book available on the Sumo website. TRF4.5 Base Machine Item No. Part Number Description SWA2020 Chassis SW2939 Wing LH SW2940 Wing RH SWH132 Hydraulic Cylinder SWP30X115 J a n 2 0 2 3...
Page 18
Error! Reference source not found. Error! Reference source not found. – Continued Item No. Part Number Description SWP30X110DB Pin – Dog Bone SWP30X180 SWP50X175 SWP50X190 SWB142 Oilite Bushes SWB105 Lynch Pin SWM1250 M12x50 Bolt SWM12001 M12 Washer – Flat SWM12004 M12 Nut –...
Standard Assemblies 6.4.1 Standard Scharmüller Hitch Assembly Note: Hitch type and CAT rating are variable. Standard machines include a CATIII Ring Hitch as shown. Contact your local dealership for alternative options. Item No. Part Number Description SWB1267 Ring Hitch SWA2010 Knuckle SW136 Stand...
6.4.1 Standard Trio Leg & Points Tungsten Point Included as standard Plain cast points also available - SW1050P Item No. Part Number Description SW1046 Standard Trio Leg SW1048 Shin SWB401 4” Wing – Right SWB400 4” Wing – Left SWB367 * 8”...
Error! Reference source not found. Error! Reference source not found. - Continued Item No. Part Number Description SWM1260 M12x60 Bolt SWM12001 M12 Washer – Flat SWM12004 M12 Nut – Nylock SWM1235TN M12x35 Screw – CSK NIB SWB183 Split Dowel 10x32 * Optional Wings Available upon Request Alternative plain cast point is also available but will need specifying separately.
6.4.4 Soil Retainers 6.4.4.1 Soil Retainer Assembly - Left Hand Item No. Part Number Description SW418 Soil Retainer LH SW4766 Soil Retainer Arm SW123 10mm SR Extra Large Washer SW125 12mm SR Washer SW126 10mm SR Spacer SWM2070 M20x70mm Bolt SWM20001 M20 Flat Washer SWM20004...
6.4.4.2 Soil Retainer Assembly – Right Hand Item No. Part Number Description SW419 Soil Retainer RH SW4766 Soil Retainer Arm SW123 10mm SR Extra Large Washer SW125 12mm SR Washer SW126 10mm SR Spacer SWM2070 M20x70mm Bolt SWM20001 M20 Flat Washer SWM20004 M20 Nylock Nut J a n 2 0 2 3...
6.4.6.3 Standard Auto Reset Valve Block & Pressure Gauge Only Ever Adjust This Valve NEVER Adjust This Valve Item No. Part Number Description SWH298 Auto Reset Valve Assembly SWH612 Pressure Gauge J a n 2 0 2 3 Rev 1 44 | P a g e...
6.4.7 Packers Options 6.4.7.1 Quadrant Assembly Per Ring – All 610 Multipackers Item No. Part Number Description SWB608 610 Weld-On Nut Retainer SWB609 610 Quadrant – Plain SWM16004 M16 Nut – Nylock SWM1645CH M16x45 Cap Head Screw J a n 2 0 2 3 Rev 1 45 | P a g e...
6.4.8.2 All Multipacker Options – Triple Scraper Item No. Part Number Description SW1003 Hanger SW651 Scraper SWM12100UB M12x100 U bolt SWM12001 M12 Washer – Flat SWM12004 M12 Nut – Nylock SWM1240CHSQ M12x40 Bolt – Cup Head Square Bolt J a n 2 0 2 3 Rev 1 49 | P a g e...
6.4.11 Packer Arms 6.4.11.1 Standard Packer Arm Item No. Part Number Description SW6263 Packer Arm * TRF4.5 Qty = 3 (Plus 1 Inboard Packer Arm Following), TRF5.5 & TRF6.5 Qty = 4 6.4.11.2 Inboard Packer Arm (TRF4.5 Only) Item No. Part Number Description SW6356...
6.4.16 Tyres & Axle Assemblies 6.4.16.1 Tyres & Marker Arrows Item No. Part Number Description SWB414 Tyre & Rim 600/50-22.5 10 Stud SWB634 30mm Marker Arrow J a n 2 0 2 3 Rev 1 60 | P a g e...
6.4.16.3 Brake Cylinders Assembly (Standard Option) Brake cylinder will change if the machine is homologated. See homologation option. Note: Parts for this assembly are not sold separately. Item No. Part Number Description SWB134 Brake Cylinder Assembly J a n 2 0 2 3 Rev 1 62 | P a g e...
Optional Extras/Attachments 6.5.1 Low Disturbance Legs & Points Tungsten Point Not include as standard Item No. Part Number Description SW1116 Low Disturbance Point SW1151 SWM12004 M12 Nut – Nylock SWM1250 M12x50 Bolt Alternative tungsten tip point is also available but will need specifying separate. Item No.
6.5.2 Front Discs Arrangements Note: Front discs option cannot be attached to machines which already have depth wheels option affixed. 6.5.2.1 Standard Mounting Bracket Assembly Quantities below are per mounting bracket, not per machine. Item No. Part Number Description SWA1195 Mounting Bracket SW4094 Buffer Mount...
6.5.2.2 Front Discs Brackets – TRF4.5 Only Item No. Part Number Description SWA1203 Bracket LH SWA1200 Bracket RH SWB411 Bush (Not Shown) J a n 2 0 2 3 Rev 1 65 | P a g e...
6.5.2.4 Front Discs Brackets – TRF5.5 Only Item No. Part Number Description SWA2989 Bracket LH SWA2990 Bracket RH SWB411 Bush (Not Shown) J a n 2 0 2 3 Rev 1 67 | P a g e...
6.5.2.6 Front Discs Brackets –TRF6.5 Only Item No. Part Number Description SW4092 Bracket LH SW4083 Bracket RH SWB411 Bush (Not Shown) J a n 2 0 2 3 Rev 1 69 | P a g e...
6.5.3 Depth Wheels Note: The depth wheel option cannot be attached to a machine which already has front discs option affixed. Left & Right-Hand Arrangement Required (Left-Hand Arrangement Shown) Item No. Part Number Description SWA2979 Depth Wheel LH SWA2980 Depth Wheel RH (Not Shown) SW2434 Bracket LH SW2435...
Page 78
SWM620 M6x20 Screw SWM6001 M6 Washer – Flat SWM6004 M6 Nut – Nylock SWM690 M6x90 Bolt SWB344 Seed Hose * Quantities above are per outlet, NOT per machine. ** Hose is typically sold in metres, provide desired cut length when requesting. J a n 2 0 2 3 Rev 1 78 |...
6.5.5 Air Brake Kits Item No. Part Number Description SWB1068 Reservoir SWB1070 Distribution Valve SWH683 Air-Brake Chamber SWB1389 Emergency Line – Red SWB1388 Service Line – Yellow SW3905 Reservoir Bracket SWA1580 Air-Brake Chamber Bracket SWS12111-RH Service Line Bracket SWS12111-LH Emergency Line Bracket SWM825 M8x25 Screw SWM8140...
6.5.8 Trailed SDO Units 6.5.8.1 Standard SDO Arrangement Item No. Part Number Description SW107 Clamping Plate SW3763 Hanger SW3760 Main Body SW3761 Press Wheel Body SW3762 Coulter Leg SWB399 Bearing SWB489 Coulter Casting – Top Half J a n 2 0 2 3 Rev 1 83 | P a g e...
6.5.8.2 Trailed SDO Unit – Base Machine Item No. Part Number Description SWA2298 Centre Toolbar SWA2300 Wing LH SWA2299 Wing RH SWA2406 Extension Link SWS21814 Trap Door Arm SWS21815 Wing Shim SW6236 Trapdoor Bush SW1290 Galvanized Step SWH328 Hydraulic Cylinder SWH127 Hydraulic Cylinder SWB1235...
Page 86
SWM1650 M16x50 Bolt SWM16001 M16 Washer – Flat SWM16004 M16 Nut – Nylock SWB374 Split Tension Bush * Wing shim quantity is dependent on machine specific requirements. J a n 2 0 2 3 Rev 1 86 | P a g e...
6.5.8.4 Trailed SDO Rails – TRF4.5 Only Item No. Part Number Description SWA2302 Mounting Bar - Centre SWA2306 Mounting Bar - Right SWA2307 Mounting Bar - Left 6.5.8.5 Trailed SDO Rails – TRF5.5 Only Item No. Part Number Description SWA2302 Mounting Bar - Centre SWA2774 Mounting Bar - Right...
6.5.8.6 Trailed SDO Rails – TRF6.5 Only Item No. Part Number Description SWA2302 Mounting Bar - Centre SWA2301 Mounting Bar - Right SWA2303 Mounting Bar - Left J a n 2 0 2 3 Rev 1 89 | P a g e...
6.5.9 Homologation The homologation kit consists of Hazard Boards, Air Brake Kit, & Handbrake Kit below. 6.5.9.1 Handbrake Kit J a n 2 0 2 3 Rev 1 90 | P a g e...
Page 91
6.5.9.1 Handbrake Kit – Continued Item No. Part Number Description SWA1259 Brake Lever Carrier Bracket SWS19737 Brake Lever SWS19746 Slide Cover SWS19743 Slide SWA1301 Jockey Wheel Mounting Bracket SWA1302 Amplifier Lever SWA1304 Jockey Wheel SW4639 Brake Spacer SWS19799 Carrier Link SWB1306 Self-Lubricating Bush SWB1004...
7. Hydraulic Function Diagrams Standard Symbols Key: Double Acting Cylinder Single Acting Cylinder Accumulator Pressure Gauge Quick Release/Check Valve Six Way Changeover Valve Ball Valve Flow Divider/Combiner Pilot Operated Relief Valve Flow Restrctor Auto Reset Valve: J a n 2 0 2 3 Rev 1 92 | P a g e...
Brake System Connections Illustration 7: Hydraulic Schematic - Brake System Connections Optional 3 Service Illustration 8: Hydraulic Schematic - Optional 3 Service J a n 2 0 2 3 Rev 1 99 | P a g e...
Drawbar Hydraulic System with Optional Rear Drawbar and Depth Wheels Illustration 9: SWHS11 – Hydraulic Schematic TRF4.5- Drawbar Hydraulic System with Optional Rear Drawbar and Optional Depth Wheels J a n 2 0 2 3 Rev 1 100 | P a g e...
8. Electrical Schematics Rear Lighting Illustration 11: SWHS151 - Rear Lighting Block Schematic J a n 2 0 2 3 Rev 1 102 | P a g e...
Page 103
9. Standard Torque Values Non-Standard torque values will appear in the parts book section of this document. Standard Toque Values (Nm) (Unless Otherwise Stated) Thread Grade 8.8 Grade 10.9 Stainless Steel 1000 1400 1450 For any arrangement using Nord-Lock washers, see Nord-Lock website: Torque Guide for Nord-Lock Washers - Nord-Lock Group J a n 2 0 2 3 Rev 1...
