Summary of Contents for Sumo Mounted Multipress 3m
- Page 1 M U L T I P R E S S 2023 Mounted Range (MUL) Machine Manual & Parts Book @Copyright 2023 Company No: 03272544 Sumo UK LTD, Redgates, info@sumo1.com Melbourne, York YO42 4RG 01759 319 900 VAT No: 552 0699 38...
- Page 2 It is required that both manuals be read and understood before using any Sumo machine. For more information contact your local dealership/Sumo directly. Please note, specifications, descriptions and illustrations in this manual are accurate, as known, at the time of publication but may be subject to change.
-
Page 3: Table Of Contents
Contents Machine Range Summary ..................5 Product Specifications ..................6 Transport Positions & Dimensions..............7 Danger Zone ......................8 Risk Assessments ....................9 Parts Book Index ....................11 MUL3 Base Machine ......................11 Standard Assemblies ....................... 12 6.2.1 Three-Point Linkage Pins....................... 12 6.2.2 Standard Subsoiler Tine &... - Page 4 Standard Torque Values..................30 J a n 2 0 2 3 Rev 1 P a g e...
-
Page 5: Machine Range Summary
1. Machine Range Summary Sumo Multipress is an extremely versatile machine that offers exceptional soil movement and levelling ability combined with excellent consolidation and suits almost any type of cultivation system. It does this in three stages: Stages One Staggered rows of spring-loaded tines offer good mixing of crop residues, while breaking up compaction and aerating in stubble fields. -
Page 6: Product Specifications
Option Code Description Specifications MUL3 MUL3.CP Channel Packer Rings: 12 – Spacing 250mm Other options may be available – See Sumo website / Contact your local dealer. J a n 2 0 2 3 Rev 1 P a g e... -
Page 7: Transport Positions & Dimensions
It is the sole responsibility of the owner/operator to ensure the machine is correctly positioned prior to transport and complies with all local laws and regulations. For all Sumo guidelines and safety protocols, read the related Sumo Cultivator Operators Manual thoroughly. Mounted Multipress... -
Page 8: Danger Zone
4. Danger Zone The area marked red indicates the Danger Zone of the machine. This refers to both folded & unfolded states. Mounted Multipress The danger zone around the machine poses the following endangerments: Accidental operation of the hydraulic system can trigger dangerous movements of •... -
Page 9: Risk Assessments
5. Risk Assessments Model: Mounted Multipress Notes: Ensure the Cultivator Operators Manual, & Machine Manual are read and fully understood. Purpose of machine: Primarily designed to alleviate compaction and improve soil structure with minimal surface disturbance. Description of machine: A single-point-hitch trailed, rigid or hydraulically folding farm implement consisting of 3 major elements. - Page 10 Stands points. safely positioned and the parking - Rotating parts brake is engaged when coupling - When folding/ up to the Sumo implements. Stay unfolding clear of any folding/unfolding - Machine tipping elements. Lower wings slow and over evenly to ensure the machine does not tip over.
-
Page 11: Parts Book Index
6. Parts Book Index For older machines, see manuals & parts book available on the Sumo website. MUL3 Base Machine Item No. Part Number Description SW2520 Headstock SWA2514 ‘A’ Frame SWA2489 Chassis SW6324 Shim SWM30100 M30x100 Bolt SWM30150 M30x150 Bolt... -
Page 12: Standard Assemblies
Standard Assemblies 6.2.1 Three-Point Linkage Pins Item No. Part Number Description SW627 Top Link Pin SW626 Bottom Link Pin SWB105 Lynch Pin SWB107 Lynch Pin J a n 2 0 2 3 Rev 1 12 | P a g e... -
Page 13: Standard Subsoiler Tine & Points
6.2.2 Standard Subsoiler Tine & Points Quantities below are for individual Subsoiler Tine and Points, not per machine. Complete Assembly – SWA272 Item No. Part Number Description SWB111 Mounting Clamp SWB117 Bottom Top Hat Bush SWB124 Straight Pin SWB114 Top Bush SWS19568 Knock Plate SWB115... - Page 14 6.2.2 Standard Subsoiler Tine & Points – Continued Complete Assembly – SWA272 Item No. Part Number Description SWB118 Spring SWB119 Spring Drive Bush SWB120 Spring Compression Plate SWB112 Tine Support SWB113 Tine SWB110 Knock On Base SWB116 Point SWB1262 Coupling SWM20100WA Clamp Bolt SWM1050...
-
Page 15: Standard Paddle Assembly
6.2.3 Standard Paddle Assembly Quantities below are for individual paddles, not per machine. Complete Assembly – SWA268 Item No. Part Number Description SWB121 Spring SWB123 Clamping Plate SWB122 Paddle SWM12110 M12x110 Bolt SWM1235CHSQ M12x35 Cup Head Square Bolt SWM12005 M12 Nut – Flanged Nylock J a n 2 0 2 3 Rev 1 15 |... -
Page 16: Paddle Bar & Pivot Assembly
6.2.4 Paddle Bar & Pivot Assembly 6.2.4.1 Paddle Bar Item No. Part Number Description Paddle Bar 6.2.4.2 Standard Pivot Points Quantities below are for individual pivot points, not per machine. Item No. Part Number Description SW2081 Bush SW123 Extra Large Washer SWM2070 M20x70 Bolt SWM20001... -
Page 17: Paddles Hydraulic Assembly
6.2.5 Paddles Hydraulic Assembly Item No. Part Number Description SWH113 Hydraulic Cylinder SWP25X100 Pin – Tabbed SWP25X130 Pin - Tabbed SWM1240 M12x40 Screw SWM12001 M12 Washer – Flat SWM12004 M12 Nut – Nylock J a n 2 0 2 3 Rev 1 17 | P a g e... -
Page 18: Packer Options
6.2.6 Packer Options 6.2.6.1 Variable Packer Spine Only suitable for Roller, Channel & Sharp packers. Item No. Part Number Description SWA2490 Packer Spine 6.2.6.2 Individual Replacement Weld-On Spokes Item No. Part Number Description SWB800 Weld-On Spokes J a n 2 0 2 3 Rev 1 18 | P a g e... -
Page 19: Individual Replacement Packer Segments
6.2.6.3 Individual Replacement Packer Segments Item No. Part Number Description SWB801 Channel Packer Segment SWB802 Roller Packer Segment SWB803 Sharp Packer Segment J a n 2 0 2 3 Rev 1 19 | P a g e... -
Page 20: Standard Segment Fastening Arrangement
6.2.6.4 Standard Segment Fastening Arrangement Item No. Part Number Description SWM1240CH M12x40 Socket Head Bolt SWM12004 M12 Nut – Nylock J a n 2 0 2 3 Rev 1 20 | P a g e... -
Page 21: Packer Frame
6.2.7 Packer Frame Item No. Part Number Description SW2359 Packer Frame J a n 2 0 2 3 Rev 1 21 | P a g e... -
Page 22: Packer Mounting Arrangement
6.2.8 Packer Mounting Arrangement Item No. Part Number Description SW2368 Guide Plate SW227 Bearings SW6342 Spacer SWB105 Lynch Pin SWP20X92H SWM20100 M20x100 Bolt SWM20001 M20 Washer – Flat SWM20005 M20 Nut – Nylock SWM30110 M30x110 Bolt SWM30001 M30 Washer – Flat SWM30004 M30 Nut –... -
Page 23: Packer Bearings Assembly
6.2.9 Packer Bearings Assembly Quantities are per packer, not per machine. Item No. Part Number Description SWB104 Bearing SWS3272 Spacer Collar SWM1670 M16x70 Bolt SWM16001 M16 Washer – Flat SWM16006 M16 Nut – Aerotight J a n 2 0 2 3 Rev 1 23 | P a g e... -
Page 24: Lights Bracket Assembly
6.2.10 Lights Bracket Assembly Left & Right-Hand Brackets Required (Left-Hand Brackets & Arrangement Shown) Item No. Part Number Description SW2931 Light Bracket Top LH SW2929 Light Bracket Top RH (Not Shown) SW2930 Light Bracket Bottom LH SW2932 Light Bracket Bottom RH (Not Shown) SWB715 Rear Light Stop Light / Indicator SWB162... -
Page 25: Stands
6.2.11 Stands Item No. Part Number Description SW117 Stand SWB144 Plastic Bung SW118 Stand Pin SWB105 Lynch Pin J a n 2 0 2 3 Rev 1 25 | P a g e... -
Page 26: Scraper Assemblies
6.2.12 Scraper Assemblies 6.2.12.1 Finger Scraper – Applies to all spined packers. Quantities below are per scraper, not per machine. Item No. Part Number Description SW3583 Finger Scraper SWM12100UB M12x100 U Bolt SWM12001 M12 Washer – Flat SWM12004 M12 Nut – Nylock J a n 2 0 2 3 Rev 1 26 |... -
Page 27: Hydraulic Function Diagrams
7. Hydraulic Function Diagrams Standard Symbols Key: Double Acting Cylinder Single Acting Cylinder Accumulator Pressure Gauge Quick Release/Check Valve Six Way Changeover Valve Ball Valve Flow Divider/Combiner Pilot Operated Relief Valve Flow Restrictor Auto Reset Valve: J a n 2 0 2 3 Rev 1 27 | P a g e... -
Page 28: Mul3 - Hydraulic Function Schematic
MUL3 - Hydraulic Function Schematic Illustration 1: SWHS – Hydraulic Schematic MUL3 J a n 2 0 2 3 Rev 1 28 | P a g e... -
Page 29: Electrical Schematics
8. Electrical Schematics Illustration 2: SWHS150 - Rear Lighting Block Schematic J a n 2 0 2 3 Rev 1 29 | P a g e... - Page 30 9. Standard Torque Values Non-Standard torque values will appear in the parts book section of this document. Standard Toque Values (Nm) (Unless Otherwise Stated) Thread Grade 8.8 Grade 10.9 Stainless Steel 1000 1400 1450 For any arrangement using Nord-Lock washers, see Nord-Lock website: Torque Guide for Nord-Lock Washers - Nord-Lock Group J a n 2 0 2 3 Rev 1...
