Sumo Seeder Quick Start Manual

Quick Start Guide

1.0 Set Implement Width

1. Select the Area Total channel (
2. Press and hold the
then "tot.2" then shows the programmed implement width (fig. 1).
Default width = 4 metres.
3. Continue holding the
point to change.
4. HOLD to change the digit (or move the decimal point). Releasing the
button selects the next digit (fig. 2).
5. Release the

2.0 Changing the Target Rate

When the drilling rate is currently at the target rate:-
1. With the rate display selected, press and hold either the
button for 5 seconds (fig. 4) until the number is flashing, then release.
2. Press either the
button to decrease the target rate (KG/Ha) (fig. 4). The longer the button is
held, the faster the number changes. Release the button.
3. When the desired target rate (KG/Ha) is displayed, press and hold the
button. The instrument will beep 5 times and the display will alternate
between the set rate and the calculated minimum forward speed for that rate.
After 5 seconds the instrument will display 'done' after which the button can
be released to return to normal operating mode.
Sumo UK Ltd
Redgates
Melbourne
York
YO42 4RG
Tel. 01759 319900
Fax. 01759 319901
).
button for 5 seconds. The display will flash "tot.1",
button and PRESS
button to return to the normal display mode.
button to increase the target rate (KG/Ha), or the
Figure 1: View
Implement Width
to select the digit/decimal
Figure 2: Change
Implement Width
Figure 3: View current
Target Rate
button or the
Figure 4: Adjust Target
Rate
