Lantronix M110 Series Quick Start

M114 CAT-1 BIS Quick Start
!
Thank you for choosing Lantronix. Please register your product to receive notifications for firmware and
documentation updates at www.lantronix.com/product-registration.
Model shown: M114B00FS
Global SIM card is pre-installed to register to Lantronix Connectivity Services.
HARDWARE OVERVIEW
Front View
LED BEHAVIOR
OFF
Solid
Cellular (Amber)
Blinking
OFF
Solid
Power/Signal
strength (Green)
Slow blinking No signal, CSQ < 4 or =99
Fast blinking Marginal signal, CSQ 4-9
HARDWARE SETUP
1. Unbox the device and gather the required accessories.
2. Optional: Install the DIN rail clip to the base of the device.
3. Connect the USB Type-C cable to the device, and connect the other end
to the USB port of a computer. Alternatively, connect a RS-232 DB9
serial cable to the RS-232 serial port. (RS-232 DB9 cable not provided.)
WHAT'S IN THE BOX
Lantronix
Services
Antenna
Connector
Green LED
Amber LED
No cellular connection
Cellular connection established
Cellular connection established
No power
Good signal, CSQ > 10
ACCESSORY BUNDLE (MF18)
ACCESSORY PART NUMBER
Power P24E0/P24E1/
adapter P24E2/P24E3/
P24E4 *
USB cord KUCA1
Antenna A31M0
DIN rail clip BR350
*You can select the power adapter model based on your region.
The accessory bundle is sold separately.
Visit https://www.lantronix.com/products/m110.
Side View
DC Power
5 1
input port
9 6
RS-232 serial port
Reset button
RS-232 PINOUT
1 DCD
2 Rx
3 Tx
4 DTR
5 Ground
6 DSR
7 RTS
8 CTS
9 RI
4. Attach the cellular SMA antenna to the SMA connector by rotating it in a
clockwise direction.
5. Connect the 4-pin connector of the power adapter to the DC input port to
power on the device.
1
Cellular Modem
DESCRIPTION
12V 1.25A switching power adapter with 4
pin SWB connector
USB Type-A to USB Type-C, 80cm long
Single LTE antenna, adhesive remote
antenna with 3000MM RG174 cable, SMA
male
Metal DIN rail clip
SMA Antenna
USB Type-C
Connector
SIM tray
Pin to eject
SIM tray
