- Page 1 Desktop ROG (G35CG) Service Manual...
-
Page 2: Table Of Contents
Table of Contents ⚫ ASUS Desktop ROG (G35CG) Overview ⚫ Components Top View ⚫ Components Bottom View ⚫ Appropriate Tools ⚫ Disassembly steps : • SLIDE DOOR • VGA CARD • SYSTEM FAN • TOP COVER • CPU LIQUID COOLER •... -
Page 3: Asus Desktop Rog (G35Cg) Overview
ASUS Desktop ROG (G35CG) Overview Front & Top View Rear Panel View ❾ Rear Speaker Out port (black) ❶ DisplayPort ⓱ ASUS Graphics Cards (on selected models only) ❶ Power button ❿ Center/Subwoofer port ❷ HDMI™ port. ⓲ Wi-Fi ports ❷... -
Page 4: Components Top View
Components Top View ♦ VGA CARD ♦ LED CR BD ♦ HDD SATA CABLE ♦ SYS FAN ♦ NFC LED CABLE ♦ POWER SW CABLE ♦ HOTSWAP MODULE ASSY ♦ MB SUPPORT BKT-A HOTSWAP SLIDE MYLAR (EN- 0351900) ♦ AUDIO CABLE ♦... -
Page 5: Components Bottom View
Components Bottom View ♦ VGA Card ♦ LED CR BD ♦ MAIN BOARD ♦ DDR ♦ FRONT IO BD MB AL MYLAR ♦SSD ♦ NFC BD ♦ CPU ♦ SIDE LED BD ♦ TOP LED BD Back... -
Page 6: Appropriate Tools
Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ROG (G35CG) desktop. ♦ Screwdriver ♦ Alcohol 95% ♦ Glove ♦ Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. #1 #2 ♦... -
Page 7: Slide Door
SLIDE DOOR Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *4pcs. Screws Spec Torque (kgf-cm) Step 2 : Pull the side doors*2pcs. #6-32 L6*H2.3 (B)B-NI-ZN 8.0± 0.5 Pull SLIDE DOOR (L) Pull SLIDE DOOR (R) Back... -
Page 8: Vga Card
VGA CARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the connector. Screws Spec Torque(kgf-cm) Step 2 : Remove screw *1pcs and open the door. #6-32*L6 (B)B-NI-ZN NY 4.0± 0.5 Step 3 : Remove screws *4pcs. Step 4 : Take out the VGA card. -
Page 9: System Fan
SYSTEM FAN Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the FAN connector. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *4pcs and FAN. M5*10L (F) W-NI (TP5) 8.0± 0.5 Disconnect Remove Back... -
Page 10: Top Cover
TOP COVER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Use the Plastic Blade and insert the gap (1~2cm). Screws Spec Torque (kgf-cm) Step 2 : Open the cover. M2.5*6L (5.5,0.8) (K) #1 4.0±... -
Page 11: Cpu Liquid Cooler
CPU LIQUID COOLER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the cooler cable at the back side. Screws Spec Torque (kgf-cm) Step 2 : Disconnect 3 cables holding on the mainboard. #6-32*6.3L(B) #2 6.0±... - Page 12 CPU COOLER & COOLER LED CABLE CPU COOLER Assembly Notice GA35DX COOLER LED CABLE L:650 ASAP GA35DX COOLER LED CABLE L:650 HONGJIXIN 1. COOLER LED cable have two SKU. 2. If using : the red cable should be connected to the CPU 3.
-
Page 13: Main Board & Cpu
MAIN BOARD & CPU Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect (yellow mark) connectors *10pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *9pcs (Red and green mark). Step 3 : Take out the Main Board. M3*4L (6.3,2.05) (B) #2 6.0±... - Page 14 MAIN BOARD with CPU COOLER & CPU CPU COOLER Disassembly Notice Assembly Notice If the CPU COOLER is hard to disassemble, Please follow the instructions to assemble the CPU. please move the COOLER left and right to separate Lock CPU triangle must be aligned to MB triangle. Pin facing down on Processor packaging to protect the CPU.
- Page 15 MAIN BOARD with CPU COOLER & CPU Assembly Notice Please be sure to pull out adapter and disconnect the battery. Please make sure that re-smear thermal material on CPU Die, if thermal module have to be reassembled. Step-1 : Using dust-free cloth with 95% alcohol to clean up the residual thermal grease on CPU & thermal module. Step-2 : Please use plastic tool (Plastic stick) to get Thermal Grease, and smear over CPU around 0.2~0.3mm thick.
-
Page 16: Ssd
Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Remove screws *2pcs. Step 2 : Spin and take out the SSD *1pcs. M2*3L(4.6,0.8) (K)#1 3.0 ± 0.3 Step 3 : Remove screws *2pcs. 2.0 ±... -
Page 17: Ddr
Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Unlock then remove DDR *4pcs. Step 2 : Remove screw *2pcs M2*3L(4.6,0.8) (K)#1 2.0 ± 0.2 Step 3 : Separate the DDR from memory socket. Assembly Notice Unlock Please follow the below criteria to assemble DDR. -
Page 18: Front Cover And Led Board
FRONT COVER AND LED BD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws*2pcs. Screws Spec Torque (kgf-cm) Step 2 : Separate the Front case. #6-32 L6*H2.3 (B)B-NI-ZN 4.0± 0.5 Step 3 : Hold on the case and disconnect the cable*4pcs. Step 4 : Remove screws*3pcs. - Page 19 FRONT COVER FRONT COVER Assembly Notice NOTE! Before assembling the FRONT COVER, please carefully read the following assembly instructions (From Repair Notice : CSC-RCN-PDAUR4160, CSC-RCN-PDAUS1159). When assembling the LED board, USB cable and power cord on the FRONT COVER, please make sure that the USB cable and power cord do not touch the PIN HEADER of the LED board, otherwise it may cause a short circuit and overheating.
- Page 20 FRONT COVER FRONT COVER Assembly Notice Step-3 After connecting the POWER and USB cable to the LED board, please tidy up the cables in the direction of the yellow arrow and be careful to avoid the PIN HEADER (marked in red). PIN HEADER PIN HEADER Step-4 Check that the cable direction must follow the yellow arrow, paste tape to fix then...
-
Page 21: Power Switch
POWER SWITCH Disassembly Notice Please be sure to pull out AC POWER CORD. Assembly Notice Please follow the steps below to assemble POWER SWITCH HOLDER and Step 1 : Remove 2 screws (red circles), then remove POWER SWITCH HOLDER with POWER SW CABLE. Step 2 : Release hooks (green mark) then take out POWER SW CABLE from POWER SWITCH HOLDER. -
Page 22: Top Fan
TOP FAN Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Remove screws *4pcs and FAN. #6-32*6L(7.1,2.3) (B) #2 6.5± 0.5 Unscrew Back... -
Page 23: Hotswap Module Assy
HOTSWAP MODULE ASSY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *9pcs and remove the MB SUPPORT BKT-A. Screws Spec Torque (kgf-cm) Step 2 : Disconnect the connectors *2pcs. M2*2.5L (K) W-NI #1 3.0±... -
Page 24: Hdd
Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *3pcs and disconnect connector *2pcs. Screws Spec Torque (kgf-cm) Step 2 : Take out the HDD BRKT and HDD. M2.5*4L (K) #1 3.0±... -
Page 25: Fio Bd
FIO BD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step1 : Remove screws *2pcs. Screws Spec Torque (kgf-cm) Step2 : Disconnect cables*2pcs. Step3 : Remove screws *3pcs and Front IO Board. M2.5*4L (4.6,0.8) (K) #1 6.5±... -
Page 26: Side Led Bd
SIDE LED BD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step1 : Remove screws *3pcs. Screws Spec Torque (kgf-cm) Step2 : Tear off the tape. Step3 : Disconnect cables*2pcs and remove SIDE #6-32*6L(7.1,2.3) (B) #2 6.5±... -
Page 27: Top Led Bd
TOP LED BD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step1 : Disconnect connector. Screws Spec Torque (kgf-cm) Step2 : Remove screws *2pcs. M2.5*4L (K) B-ZN NY 2.5± 0.5 Unscrew Disconnect Back... -
Page 28: Power Supply
POWER SUPPLY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *4pcs. Torque (kgf-cm) Screws Spec Step 2 : Take out the POWER SUPPLY. #6-32*L6 (B)B-NI-ZN NY 8.0± 0.5 Unscrew Take out Back... -
Page 29: Cable Assembly
CABLE ASSEMBLY Assembly Notice Please be sure to pull out adapter and disconnect the battery. Tidy up the cable of the back mainframe as illustrated. Back...
