Desktop ROG Strix (G15CE)
Service Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROG Strix and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Asus ROG Strix

  • Page 1 Desktop ROG Strix (G15CE) Service Manual...
  • Page 2 INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR INTHIS MANUAL OR PRODUCT.
  • Page 3 ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement. This limit also applies to ASUS' suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible.
  • Page 4 Disclaimer ASUS is not responsible for direct, indirect, intentional or unintentional damages resulting from improper installation and operation. Safety precautions • Before handling components, use a grounded wrist strap or touch a safely grounded object to avoid damaging them due to static electricity.
  • Page 5: Table Of Contents

    Table of Contents ⚫ ASUS Desktop ROG Strix G15CE Overview ⚫ Components Top View ⚫ Components Bottom View ⚫ Appropriate Tools ⚫ Disassembly steps : • SLIDE DOOR • VGA CARD • DDR & SSD CARD • • MAIN BOARD with CPU COOLER & CPU •...
  • Page 6: Asus Desktop Rog Strix G15Ce Overview

    ASUS Desktop ROG Strix G15CE Overview Front & Top View Rear Panel View ❶ DisplayPort ❶ Power button ❷ HDMI™ port. ❷ Headphone port ❸ USB port with BIOS FlashBack™ ❸ Microphone port ❹ BIOS FlashBack™ button ❹ USB 3.2 Gen 1 Type-C® port ❺...
  • Page 7: Components Top View

    Components Top View ♦ VGA Card ♦ `TUF SUP BKT ♦ MAIN BOARD ♦ POWER SW CABLE ♦ FIO USB CABLE ♦ PSU_GASKET ♦ TOP LED BD ♦ DDR ♦ GLASS DOOR ASSY ♦ MB PLATE AL FOIL ♦ HDD SATA CABLE ♦...
  • Page 8: Components Bottom View

    Components Bottom View ♦ VGA Card ♦ MAIN BOARD ♦ LED BOARD ♦ LED CR BD ♦ SSD ♦ TOP LED BD ♦ FRONT IO BD ♦ SIDE LED BD ♦ CPU Back...
  • Page 9: Appropriate Tools

    Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ROG Strix (G15CE) desktop. ♦ Screwdriver ♦ Alcohol 95% ♦ Glove ♦ Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. #1 #2 ♦...
  • Page 10: Slide Door

    SLIDE DOOR Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *4pcs. Screws Spec Torque (kgf-cm) Step 2 : Pull out the side doors*2pcs. SCREW #6-32 L6*H2.3 (B)B-NI-ZN 8.0± 0.5 Unscrew Pull GLASS DOOR ASSY Pull...
  • Page 11: Vga Card

    VGA CARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect cables (Yellow mark). Screws Spec Torque(kgf-cm) Step 2 : Remove screws *4pcs (Red and Blue mark). SCREW #6-32*L6 (B)B-NI-ZN NY 4.0± 0.5 Step 3 : Press and unlock the VGA card.
  • Page 12: Ddr & Ssd Card

    DDR & SSD CARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Unlock and then remove DDR *4pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove screw *2pcs, and then take out the SSD Housing. Retention Screw 2.0 ±...
  • Page 13: Fan

    Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Release CONDUCTIVE Cloth (Green mark)*1pcs and disconnect (yellow mark) FAN connector *1pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove 4 screws on the outside of iron grid. M5*10L (F) W-NI (TP5) 8.0±...
  • Page 14: Main Board With Cpu Cooler & Cpu

    MAIN BOARD with CPU COOLER & CPU Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect (Yellow mark) connectors *7pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *8pcs (Red and green mark). Step 3 : Take out the Main Board.
  • Page 15 MAIN BOARD with CPU COOLER & CPU CPU COOLER Disassembly Notice Assembly Notice If the CPU COOLER is hard to disassemble, Please follow the instructions to assemble the CPU. please move the COOLER left and right to separate Lock Pin facing down on Processor packaging to protect the CPU notch must be aligned to MB notch.
  • Page 16 MAIN BOARD with CPU COOLER & CPU Assembly Notice Please be sure to pull out adapter and disconnect the battery. Please make sure that re-smear thermal material on CPU Die, if thermal module have to be reassembled. Step-1 : Using dust-free cloth with 95% alcohol to clean up the residual thermal grease on CPU& GPU Die. Step-2 : Please use plastic tool (Plastic stick) to get Thermal Grease, and smear over CPU around 0.2~0.3mm thick.
  • Page 17: Front Bezel And Led Board

    FRONT BEZEL and LED BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Pull the latch slightly away. Screws Spec Torque (kgf-cm) Step 2 : Disconnect the connectors *3pcs of the cable inside. M2.5*5L (4.6,1.7) (P) #1 3.0±...
  • Page 18: Power Switch

    POWER SWITCH Disassembly Notice Please be sure to pull out AC POWER CORD. Assembly Notice Please follow the steps below to assemble POWER SWITCH HOLDER and Step 1 : Remove POWER SWITCH HOLDER with POWER SW CABLE from the front case. Step 2 : Release hooks (green mark) then take out POWER SW CABLE from POWER SWITCH HOLDER.
  • Page 19: Front Bezel Assy

    FRONT BEZEL ASSY FRONT BEZEL Assembly Notice NOTE! Before assembling the FRONT BEZEL ASSY, please carefully read the following assembly instructions. When assembling the LED board, USB cable and power cord on the FRONT BEZEL ASSY, please make sure that the USB cable and power cord do not touch the PIN HEADER of the LED board, otherwise it may cause a short circuit and overheating.
  • Page 20 FRONT BEZEL ASSY FRONT BEZEL Assembly Notice Step-3 After connecting the POWER and USB cable to the LED board, please tidy up the cables in the direction of the yellow arrow and be careful to avoid the PIN HEADER (marked in red). PIN HEADER PIN HEADER Step-4 Check that the cable direction must follow the yellow arrow, paste...
  • Page 21: Top Cover

    TOP COVER Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Use the Plastic Blade to Remove the Handle Cover. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *2pcs located on the end of the Handle. Step 3 : Pull the latch slightly away from the edge case until it’s detached.
  • Page 22: Front Io Board

    FRONT IO BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *2pcs. Assembly Notice Screws Spec Torque (kgf-cm) Step 2 : Disconnect cables *2pcs. Step 3 : Remove screws *2pcs. M2.5*4L (K) B-ZN NY #1 3.0±...
  • Page 23: Hdd

    Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screws *4pcs. Screws Spec Torque (kgf-cm) Step 2 : Disconnect the cables *2pcs Step 3 : Take the HDD out. SCREW #6-32*6L(7.1,2.3) (B) #2 6.5±...
  • Page 24: Power Supply

    POWER SUPPLY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the cables *4pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *4pcs. SCREW #6-32*L6 (B)B-NI-ZN NY 8.0± 0.5 Step 3 : Take out the POWER SUPPLY. Unscrew Disconnect (POWER...
  • Page 25: Led Board

    LED BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove screw*3pcs, and then disconnect cable *1pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove screw*2pcs, and then disconnect cable *1pcs. SCREW M2.5*4L (K) B-ZN NY 2.5±...
  • Page 26: Cable Assembly

    CABLE ASSEMBLY Assembly Notice Please be sure to pull out adapter and disconnect the battery. Tidy up the cable of the back mainframe as illustrated. Back...
