- Page 1 Zero G Pro Installation Instructions INSTALLERS: PLEASE LEAVE THIS MANUAL WITH THE OWNER. Doc. # 400275 | v. 1.2 | July 2024...
- Page 2 Limited 1 year warranty on Screen Innovations products Screen Innovations warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of purchase. This warranty is limited to the original purchaser, provided that the product is used in accordance with our instructions and is not damaged due to improper handling, misuse, or neglect after shipment from the factory.
-
Page 3: Table Of Contents
Parts In The Box – Zero G Pro . . . . . . . . . . . . . . . . -
Page 4: Parts In The Box - Zero G Pro
PARTS IN THE BOX – ZERO G PRO SCREEN Screen Note: This image is representative of Pure White material, with a visible border printed in black. A black printed border will not be visible with Carbon Black material. Warranty Card... -
Page 5: Screen Overview
SCREEN OVERVIEW 8.7"(221mm) Small cassette Large Size Cassette View " 7.2"(183mm) Small Size Cassette View Screen Front View Large cassette 8.7"(221mm) Large Size Cassette View 7.2"(183mm) Small Size Cassette View Screen Front View... -
Page 6: Installation Method And Precautions
INSTALLATION METHOD AND PRECAUTIONS Note: Due to structural reasons, the position of the screen is not the center of the screen, but it is offset by about 4¼” (105mm) - for small cassette screen, and 3⅛” (80mm) - for the large cassette screen, to the right. -
Page 7: Precautions
PRECAUTIONS - The screen fabric is offset to the right from the casing (take this into account when calculating the installation position). - For closed suspended ceiling installations, reserve about 15 ¾” (400mm) of space on the power supply side for maintenance. - Pay attention to the orientation of the screen material’s projection surface (refer to the side view) to avoid installing it backward. -
Page 8: Setting The Limits
SETTING THE LIMITS 1. Press and hold the programming button on the back of the remote control until the LED light in the programming hole illuminates. 2. Move the screen to the desired position and press the “Stop” button. 3. Press and release the program button and verify that the LED light has turned off. Stop Down Wireless transmitter... -
Page 9: Control
CONTROL Warning: An activation button has been added to safeguard the internal steel cable system. Before turning on the power, ensure that you completely remove the yellow adhesive tape from the screen. Failing to do so could damage the internal steel cables and create safety risks. Intelligent electric screen has 5 control methods: a. -
Page 10: Screen Control Function Description
SCREEN CONTROL FUNCTION DESCRIPTION b. RF Remote Control: Press the Down button, screen extends to set position. Press the Stop button, screen will pause. Press the Up button, the screen will retract Stop Down Wireless transmitter Positioning Settings Key Pairing/Unpairing (Remote has been paired at factory) The first method: Press and hold the cycle button for 3 seconds, the screen will jog once, entering the pairing mode;... - Page 11 SCREEN CONTROL FUNCTION DESCRIPTION Connection Diagram S1 S W-PB S2 S W-PB S3 S W-PB 8P8C RS - 23 2 RS485/RS232 Port Hex Control Code Settings: • Up: FFEEEEEEDD • Data Bits: 8 bits S • STOP: FFEEEEEECC • Tart Bit: 1 bit •...
