- Page 1 USER MANUAL for installation and maintenance TILTING BRATT PANS gas with filling of water with stainless steel bottom PP-750, PP-980, PP-9120 7/2024...
-
Page 2: Table Of Contents
Content 1. General information ......................3 2. Use ............................3 3. Safety regulations ........................3 4. Legal declaration ........................3 5. Technical data ........................5 6. Description of the gas tilting bratt pan ................. 6 7. Assembly ..........................6 8. Service ........................... 7 9. -
Page 3: General Information
1. General information Dear user, thank you for choosing our product. Please read these operating instructions carefully before using the appliance so that the appliance can serve you to your satisfaction. 2. Use The gas tilting bratt pan is designed for preparing various types of dishes and dishes. Food is prepared by heat treatment - frying in oil, stewing in water. - Page 4 Warning! THE MANUFACTURER IS NOT RESPONSIBLE FOR THE INCORRECT TECHNOLOGICAL PROCEDURE OF THE OPERATOR DURING COOKING.
-
Page 5: Technical Data
5. Technical data Line Type PP-750 PP-980 PP-9120 gas tilting bratt Description gas tilting bratt pan gas tilting bratt pan Front panel classic analogy classic analogy classic analogy Bottom of cooking tank stainless steel stainless steel stainless steel External dimensions (mm) -
Page 6: Description Of The Gas Tilting Bratt Pan
Rounded edges without danger corners and protrusions Adjustable feet Weight(kg) Options for extra fees according of valid Price list Square steamer yes (extra fee) yes (extra fee) yes (extra fee) Info G20 - I2H = natural gas G31 propane - I3P = propane 6. -
Page 7: Service
• The gas connection to the device is done using a 3/4" thread. The gas tilting bratt pan can only be operated in a normal environment. The room must be perfectly ventilated or have an exhaust device installed. • The device needs to be grounded!! At the bottom of the device (skeleton) there is a protective clamp, which is used to connect the lifeless metal parts of the kitchen equipment. -
Page 8: Turning On The Eternal Flame
WARNING! Do not switch on the gas tilting bratt pan if there is no water/oil in the container, this will reduce the life of the appliance (this may cause the gas tilting bratt pan container to overheat and curl)! 9.1 Turning on the Eternal Flame We can check the burning of the eternal flame by using the circular hole on the front cover. -
Page 9: Switching On The Main Burner
9.2. Switching on the main burner The successful ignition of the eternal burner is followed by the ignition of the main burner. Put the main burner into operation by setting the GAS knob to the position (burner-MAIN FLAME). Now the burner works according to the power switch setting. -
Page 10: Safety Features
brewtub. The filling height above the maximum level is also strictly prohibited for safety reasons (possibility of boiling). IN THE EVENT OF FAILURE TO COMPLY WITH THE ABOVE CONDITIONS, THE CUSTOMER LOSES THE RIGHT TO WARRANTY SERVICE. 10.2. Safety features The gas tilting bratt pan includes as a safety feature: End micro switch - if the gas tilting bratt pan is not in the working position (the gas tilting bratt pan is tilted), the micro switch will disable the heating elements and water filling. - Page 11 For the treatment of GASTRO-HAAL equipment, the manufacturer recommends the use of TIEFFE cleaning products that are specially tested, tested and compliant by the manufacturer. It is possible to purchase TIEFFE cleaning products directly from the manufacturer of the GASTRO-HAAL equipment or from a retailer.
-
Page 12: Connection Dimensions
Connection dimensions PP-750... - Page 13 PP-980...
- Page 14 PP-9120...
- Page 15 SUPPLIER: (add supplier contact here) SERVICE PROVIDER: (add service contact here) MANUFACTURER GASTRO – HAAL, s.r.o. Považská 16, 940 67 Nové Zámky, SR +421 35 6 430 115 gastro@gastrohaal.sk Company ID: 31435076 VAT ID: 2020413659 VAT ID: SK2020413659 www.gastrohaal.sk...
