Livona with roof/ LED
Livona without roof/ LED
Maintenance Instructions
and Directions for Use
Folding arm awning with gear drive or
electric drive
Important guidelines for the end user.
Please read these instructions and observe their contents and warnings before using
the equipment for the first time.
Livona with roof/ LED/ Livona without roof/ LED
Maintenance Instructions and Directions for Use
We reserve the right to make technical changes
ENGLISH
Version 2
2016-07-06
Item number
117885-0000
Page 1/13
Advertisement
Table of Contents
Related Manuals for weinor Livona with roof/LED
Summary of Contents for weinor Livona with roof/LED
- Page 1 Livona with roof/ LED Livona without roof/ LED Maintenance Instructions and Directions for Use Folding arm awning with gear drive or electric drive ENGLISH Important guidelines for the end user. Please read these instructions and observe their contents and warnings before using the equipment for the first time.
-
Page 2: Table Of Contents
Contents 1 Reading the Maintenance Instructions and Directions for Use ........ 3 1.1 Warnings ..........................3 1.2 Tips and recommendations ....................3 1.3 Illustrations .......................... 3 1.4 Instructions requiring action ....................3 2 Safety notes ........................4 2.1 Fundamental safety notes ....................4 2.1.1 Operation ........................ -
Page 3: Reading The Maintenance Instructions And Directions For Use
Reading the Maintenance Instructions and Directions for Use Read the Maintenance Instructions and Directions for Use before using the awning for the first time. For personal safety, it is important that these instructions are complied with. Non- compliance means the manufacturer does not carry any liability. All instructions and directions for use supplied with the awning must be kept by the customer and passed on to the new owner if the awning is sold on. -
Page 4: Safety Notes
Safety notes Fundamental safety notes DANGER Personal injury Risk of personal injury due to improper use of the awning. Please read and observe the safety notes contained in this section. IMPORTANT Product and property damage Risk of damage to the product and property due to improper use of the awning. Please read and observe the safety notes contained in this section. -
Page 5: Explanation Of Wind Resistance Classes
2.1.3 Explanation of wind resistance classes Wind resistance class 0 Wind resistance class 0 equates (in accordance with DIN EN 13561) either to a level of performance that is not required or has not been measured, or to a product that does not meet the requirements of Class 1. -
Page 6: Use In Rain
2.1.4 Use in rain If the awning is pitched at less than 25% = 14°, measured from a horizontal position, it must not be opened during rainfalls. There is a risk of water pooling in the awning fabric, which could result in damage to the awning. -
Page 7: Checking And Monitoring The Awning
Awning systems are designed to open in order to protect exposed areas from undesired sun. Failure to use the product as intended may result in severe danger. Alterations not envisaged by weinor, such as attaching items or conversions, may only be carried out with the manufacturer's written consent. -
Page 8: Product Description
Drop profile Description of construction and function The weinor Livona/with roof/ LED is a back-bar awning with a fabric that opens to protect against the sun. It can be tilted to any angle of inclination between 5° and 20° as desired. -
Page 9: Cleaning
Cleaning DANGER Personal injury There is a risk of motorised awnings being activated unintentionally. Disconnect the awning from the power supply (e.g. by disconnecting the fuse) before doing any cleaning work. If awnings are operated by several users, a priority locking device must be activated (controlled interruption of the power supply from outside), making it impossible to open or retract the awning at all. -
Page 10: Maintenance
Maintenance DANGER Personal injury The safe and risk-free use of the awning can only be guaranteed if the system is checked and maintenance is performed on it on a regular basis. Observe the maintenance requirements and maintenance intervals. Inspect the awning at regular intervals for signs of wear and tear or damage to the awning material and frame. -
Page 11: Lubricating All Movable Parts
Permissible range of adjustment: weinor Livona/ with roof/ LED 5° to 20°. We recommend setting all awnings to an angle of more than 5°. To adjust the angle of inclination easily, open the awning and slightly lift the arm in question to reduce the strain. -
Page 12: Rectifying Faults
Rectifying faults Our recommendation: Faults should only be rectified by your specialist retailer. Please bear in mind that faults which are not repaired properly will compromise the safety of your awning system. You should therefore call your specialist retailer immediately if a fault occurs. This person is your local specialist and will gladly provide you with swift, professional advice. - Page 13 PergoTex II/ PergoTex II LED Instructions for assembly weinor GmbH & Co. KG Mathias-Brüggen-Straße 110 50829 Cologne (Germany) www.weinor.com Hotline: +49(0)221/5 97 09-214 Fax: +49(0)221/5 97 09-898 Livona with roof/ LED/ Livona without roof/ LED Maintenance Instructions and Directions for Use...
