Dacor DCM24 w/ACTK27 Planning Manual

COMBINATION INSTALLATIONS
Revised
08/26/08
120V
Microwave
Receptacle
29"
(737mm)
Overall
1
Stacked
Height
1
CUTOUT DIMENSIONS
DMT2420 ShOWN
NOTE:
1. 3/4" (19mm) support platform (flush with cutout).
2. See individual appliance Planning Guide pages to
determine overlays.
3. Spacing between appliances and drawers/doors
shown is minimum required to allow for ventilation
and prevent scraping. Additional space may need
to be added for appearance.
Microwave
Model No.
DMT2420 w/Trim Kit
DCM24 w/ACTK27
DCM24 w/ACTK30
DCM24 w/ACTK36
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
Microwave/Warming Oven
7/8" (22mm) Min.
16 3/4"
(425mm)
"A"
"B"
120V Warming
9 1/8"
Oven Receptacle
(232mm)
"A" Cutout Width
24 3/8" (619mm)
25 1/4" (641mm)
28 1/4" (718mm)
25" (635mm)
All tolerances: +1/16", -0, (+1.6mm, -0) unless otherwise stated
1 1/2"
(38mm)
Min.
3/4"
(19mm)
Min.
31 1/8"
(791mm)
Overall
1
Stacked
Height
1
Warming
Oven
Models
27"
30"
36"
Specifications are subject to change without notice.
See installation instructions for additional details.
PLANNING
GUIDE
1/1
"A"
120V
Microwave
Receptacle
"B"
120V Warming
Oven Receptacle
CUTOUT DIMENSIONS
DCM24 ShOWN
"B" Cutout Width
25 1/2" (648mm)
28 1/2" (724mm)
34 3/8" (873mm)
3/4" (19mm) Min.
19 1/8"
(486mm)
1 3/8"
(35mm)
Min.
9 1/8"
(232mm)
3/4"
(19mm)
Min.
CI.26
