Dacor ACTK27 Planning Manual

ACTK27, ACTK30, ACTK36, AOCTK27, AOCTK30
111307
120V
Microwave
Receptacle
3
MICrOwAvE AND TrIM KIT
24 5/8"
(626mm)
DCM24 OvErALL DIMENsIONs
NOTE:
1. 24" (610mm) minimum exterior cabinet depth.
2. See the Combination Installation (CI) Section if
installing with a wall oven, or warming oven.
3. 3/4" (19mm) support platform (flush with cutout).
4. Microwave is supplied with a 48" (1219mm) power
cord, with a three prong grounded plug.
Model No. "A" Overall Width
DCM24
ACTK27 27" (686mm)
ACTK30 30" (762mm)
ACTK36 36" (914mm)
AOCTK27 27" (686mm)
AOCTK30 30" (672mm)
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
Convection Microwave Oven
3/4" (19mm)
Min.
"B"
19 1/8"
(486mm)
1" (25mm)
Min.
19"
(483mm)
14 7/8"
(378mm)
"B" Cutout Width
- -
25 1/4" (641mm)
28 1/4" (718mm)
25" (635mm)
25 1/4" (641mm)
28 1/4" (718mm)
DCM24
24"
(610mm)
Exterior
cabinet depth
CUTOUT DIMENsIONs IsOMETrIC vIEw
(Epicure™ or Millennia™ Trim Kit - use these models
(Epicure™ or Millennia™ Trim Kit - use these models
Dedicated Circuit
"D" Cutout Height
-
19 1/8" (486mm)
19 1/8" (486mm)
120VAC, 60Hz, 15A
19 1/8" (486mm)
18 1/2" (470mm)
18 1/2" (470mm)
Specifications are subject to change without notice.
See installation instructions for additional details.
PLANNING
1/1
"D"
Wooden Supports
15 5/8"
2"x2" Nominal
(397mm)
1 9/16"x1 9/16" Actual
18 3/8" (not needed for ACTK36)
(467mm)
"B"
"A"
ACTK OvErALL DIMENsIONs
when stacking with the Classic Wall Oven)
"A"
AOCTK OvErALL DIMENsIONs
when stacking with the Discovery Wall Oven)
Total Connected
Required Load
1.6kW (13A)
(Breaker)
GUIDE
1" (25mm)
20 1/8"
(511mm)
20 1/8"
(511mm)
Approximate
Shipping Weight
60 lbs.
15 lbs,
16 lbs.
20 lbs.
19 lbs.
20 lbs.
12.2
