EASYBAT - PL1215B
LED Outdoor Battery Par
12x15w RGBWA UV
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.
User manual
Please read the instructions carefully before use
Advertisement
Table of Contents
Related Manuals for PLUSLITE EASYBAT-PL1215B
Summary of Contents for PLUSLITE EASYBAT-PL1215B
- Page 1 EASYBAT - PL1215B LED Outdoor Battery Par 12x15w RGBWA UV This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. User manual Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Dimension....................3 2. Safety Information ...................3 3.Configuring the fixture ................4 4. Connecting to a DMX control device ............4 5. Configuring the fixture for DMX control .............5 6. Cleaning ....................6 7. DMX Channel..................7 8. Control menu..................8 9. -
Page 3: Dimension
1. Dimension 2. Safety Information WARNING! Read the safety precautions in this section before unpacking, installing, powering or operating this product. This luminaries are multi-environmental fixtures with an IP-rating of 65, intended for professional use only. They are not suitable for household use. Review the following safety precautions carefully before installing or operating the fixture. -
Page 4: Configuring The Fixture
Always power off/unplug the fixture before removing any covers. Ensure that the power is turned off when connecting the fixture to the AC mains supply. Ensure that the fixture is electrically connected to earth (ground). Do not apply power if the fixture is in any way damaged. ... -
Page 5: Configuring The Fixture For Dmx Control
The DMX512 is widely used in intelligent lighting control,with a DMX 512 controller.connect several lights together,dmx in and dmx out, 5 pin XLR connectors DMX - INPUT DMX - OUTPUT XLR plug XLR socket Pin1 : GND - Shield Pin2 : - Signal Pin3 : + Signal Pin4 : N/C Pin5 : N/C... -
Page 6: Cleaning
Setting the DMX address The DMX address can be seen on the main screen. To change the address setting, press the up arrow to increase the address, or the down arrow to decrease the setting. When the desired address is displayed, press Enter to save the setting. -
Page 7: Dmx Channel
7. DMX Channel DMX512 Function Value 0~255 Red dimmer 0~255 Green dimmer 0~255 Blue dimmer 0~255 White dimmer 0~255 Amber dimmer 0~255 UV dimmer 10CH DMX512 Function Value 0~255 dimmer 0~255 Red dimmer 0~255 Green dimmer 0~255 Blue dimmer 0~255 White dimmer 0~255 Amber dimmer... -
Page 8: Control Menu
8. Control menu Display: MENU To return back to the previous menu DOWN To go backward in the selected functions To go forward in the selected functions, ENTER To confirm the selected functions Menu 6/10CH Channel 001-512 DMX address On / Off W-DMX Setting Unpair W-DMX Pairing... - Page 9 Manual Dimming RGBWAUV dimming / Strobe (Strobe Speed) Static Colour C1 - C36 Auto Jump / Fade / Pulse / Combined Timer Start / End / Function / Timer (On/Off ) WiFi Mode Clear RGBWAUV Yes/No User Colors User Run Static color / Auto mode Work Time: 000H-999H...
- Page 10 Wireless transmitter * When in “ blue “ color, click “ FUNCTION “ once,it will connect with the lights. * Press “ FUNCTION “ until the color change to “ pink “, it means remove all the lights connection. Some notes about wireless： 1-1.
- Page 11 Setting Master/Slave: If there is 10 fixtures, the first step is to unpair these 10 fixtures with their original transmitter(if the pairing has been unpaired, this operation is not required). Step 2, set 9 fixtures to Receiving>Yes, then setting the 9 fixtures to DMX model as slave.
- Page 12 IR-Remote control If you want to use the IR Remote remote control, the following are things to note: 1. In the “User Settings” menu, go to the “IRemote” menu item and set the IR Mode to YES 2. Make sure all other operating modes are disabled. 3.
-
Page 13: Specification
9. Specification Light Source: AC90-240V, 50/60HZ 12x15 high-power RGBWAUV 6IN1 LEDs 50,000 hours expected lifetime 25°lens beam angle Control: 0-100% 32bit linear dimming 1-20 times/second strobe 9 DMX channels mode 4 built in auto Construction: IP65 Cast aluminum body IP65 Seetronic powercon in and out IP65 seetronic 5-pin DMX in and out Single holder with OMEGA quick lock Diffuser : 40°... -
Page 14: Photometrics
10.Photometrics High power setting: Normal power setting:... -
Page 15: Reminder
11.Reminder 1. Before using the lights, be better “ Reset ” it first : “System Settings” - “Reset” - “Yes”. 2. When no need to use the IR remote control, please set the “IRC Setting ” on “Off”, for in case it come out interference. 3. - Page 16 Battery operation info This device is equipped with a lithium ion (Li-Ion) battery. characterized by its robustness and longevity. Besides, this is The battery type charges particularly quickly and convinces with its low charge and self-discharge level. Depending on use, autonomy is intended with a full charge to approximately 24 hours (1 color at 100% in medium operation) up to 5 hours with all colors at high brightness.
- Page 17 Charge the lithium-ion battery only using the device's built-in charger. Store the lithium-ion battery at room temperature in its case. Operation at temperatures that are too high or too low reduces the capacity of the lithium-ion battery. Never expose the lithium ion battery to mechanical or external shocks mechanical influences.
- Page 18 Model: EASYBAT-PL1215B Voltage: 90V ~ 240V/50~60Hz 12x15W LEDs: RGBWAUV 6IN1 LEDs IP Rating: IP65 Beam Angle: 25° Power Consumption: 100W Battery: 19Ah high capacity Lithium battery Charging time: 7 hours from 0-100% Using time full colors: about 5 hours Control Mode:...
