10.Maintenance Cleaning
The following points have to be considered during the inspection:
1)All screw for installing the devices or parts of the device have to be tightly
connnected and must be corroded.
2)There must not any deformations on the housing,color lenses,fixations
and installation spots(Ceiling,suspension,trussing)
3)Mechanically moved parts must not show any traces of wearing and must
not rotate with unbalances.
4)The electric power supply cables must not show any damage,material
fatigue or sediments
Futher instruction depending on the installation spot and usage have to be
adhered by a skilled installer and any safety problems have to be removed.
CAUTION!
Disconnct from mains before starting maintenance operation.
In order to male the lights in good condition and extend the life time, we
suggest a regular clearning to the lights.
1)Clean the inside and outside lens each week to avoid the weakness of the
lights due to accumulation of dust.
2)Clean the fan each week.
3)A detail electric check by approved electrical engineer each three month,
make sure the circuit contacts are good condition, prevent the poor contact
of circuit from overheating.
We recommend a frequent cleaning of the device.Please use a mosit,lint-free
cloth.Never use alcohol or solvents.
There are no seviceable parts inside the device.Please refer to the instructions
under Installation
instructions.
www.piu39av.com
VERO profile 700
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERO profile 700 and is the answer not in the manual?

Questions and answers

Summary of Contents for PLUSLITE VERO profile 700

  • Page 1 10.Maintenance Cleaning The following points have to be considered during the inspection: VERO profile 700 1)All screw for installing the devices or parts of the device have to be tightly connnected and must be corroded. 2)There must not any deformations on the housing,color lenses,fixations...
  • Page 2 Meanwhile,please keep this manual well for future needs. •Angle:6.5°-42°linear adjustment •Prism angel can option The VERO profile 700 is made of new type of high temperature strength of •Control mode: DMX512,Protocols RDM, Wireless and Art-Net •Standard mode 38 channels, Sound control mode, Stand-alone, engineer plastics and cast aluminum casing with nice outlook.The fixture is...
  • Page 3: Specification

    2.Safety instructions Frame 1B 0~255 Frame 2A 0~255 CAUTION! Be careful with your operation s.With a dangerous voltage you can suffer a dangerous electric Frame 2B 0~255 shock whentouching wires Frame 3A 0~255 Frame 3B 0~255 This device has left the factory in perfect condition. In order to maintain this Frame 4A 0~255 condition to ensure a safe operation, it is absolutely necessary for the user...
  • Page 4: Mounting And Installation

    4.Mounting and Installation Cautions: Strobe Open 4~67 Strobe 1 For added protection mount the fixture in areas outside walking paths,seating 68~99 Strobe 2 areas,or in area were the fixture might be reached by unauthorized personnel. Before mounting the fixture to any surface,make sure that the installation area 100~131 Strobe 3 can hold a minimum point load of 10 times the device’s weight.
  • Page 5: Dmx 512 Control Connection

    Note: 1.Above all projects to the actual lighting shall prevail, no notice if there is further 5.DMX 512 Control connection modification; 2.The programming function provides only a very limited operation, in the case of Connect the provice XLR cable to the female 3 pin XLR Output of your control and no control units to use.
  • Page 6 The control Display 7.Menu for Control Display 6.Top menu,present the current opertion MASTER PROJECT INSTRUCTION FOR USE INFORMATION ADDRESS 1~512 RUNTIME TIME VERSION TEMPERATURE MAIN BOARD LIGHT SOURCE -- Address FAN SPEED SETTING RESET REBOOT DEFAULT DATA CHANNEL SET SIGNAL DMX512/ARTNET/PROGRAM OFFLINE SET HOME/HOLD...
