PLUSLITE SMALLY-PL740PE User Manual

Wash zoom beam led rgbw 7x40w pixel control
Hide thumbs

Advertisement

Table of Contents

SMALLY-PL740PE
Wash Zoom Beam LED RGBW 7x40w
PIXEL CONTROL
User Manual
www.pluslite.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMALLY-PL740PE and is the answer not in the manual?

Questions and answers

Related Manuals for PLUSLITE SMALLY-PL740PE

Summary of Contents for PLUSLITE SMALLY-PL740PE

  • Page 1 SMALLY-PL740PE Wash Zoom Beam LED RGBW 7x40w PIXEL CONTROL User Manual www.pluslite.eu...

  • Page 2: Table Of Contents

    Please read the instructions carefully before use TABLE OF CONTENTS 1. Safety Instructions ..............3-4 2. Technical Specifications ............. 5-5 3. How To Control The Unit ............5-8 4. DMX Channels ................. 8-10 5. shape ..................10 6. Trouble shooting ................. 16 7.

  • Page 3: Safety Instructions

    1. Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet.  Unpack and check carefully there is no transportation damage before using the unit. ...
  • Page 4 Warning:  To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.  DO NOT open the unit within five minutes after switching off.  The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

  • Page 5: Technical Specifications

    2. Technical Specifications Light Sources: 7x40W 4IN1 RGBW LED Beam Angle: 3,5°~ 45° Power Consumption: 250W Power Voltage: AC 100-240V, 50/60Hz Dimension: 258*178*334 mm Net Weight: 5.6 Kgs Flight case packing(4 in 1): 620x540x560mm Carton packing(4 in 1): 660X500X445mm Carton packing(1 in 1): 320x240x430mm Control Pixel Control DMX Channel: 21/24/32/60 CH...
  • Page 6 3. LUX Date...

  • Page 7: How To Control The Unit

    4. How To Control The Unit The DMX512 is widely used in intelligent lighting control,with a DMX 512 controller.connect several lights together,dmx in and dmx out, 5pin XLR connectors: DMX - INPUT DMX - OUTPUT XLR plug XLR socket Pin1 : GND - Shield Pin2 : - Signal Pin3 : + Signal Pin4 : N/C...
  • Page 8 Set DMX Address Code Press "Menu" to "Set DMX Address",and press"ENTER" keys to enter into Show "Set DMX Address DMX Address:001",Press the "UP and DOWN" keys to amended Press "ENTER"keys to save and Exit,Press the"MENU"Keys does not save and Exit Address Address 001 ～...
  • Page 9 Invert 2.Tilt Invert 1.NO,2.YES reverse setting Sound 0-100 Sound sensitivity Degree 1.540, 2.360 No signal 1.Black out 2.Hold Fan set 1.Auto, 2.High, 3.Low 1.NO Reset Reset 2.YES 3.Yes Factory setting Default 4.No 1.Soft V1.0 Show the version number Inform 2.Temp / Show the temperature of led board Pass word ****...

  • Page 10: Dmx Channels

    5. DMX Channels DMX channel´s functions and values (21 DMX channels): 21 Channel Mode: Channel Function Description Value Ch 1 0----255 Red dimming Ch 2 0----255 Red adjustment Red adjustment Ch 3 0----255 Green Green dimming Ch 4 0----255 Green adjustment Green adjustment Ch 5 0----255...
  • Page 11 Random strobe 204----255 Ch 14 Pan control 0----255 Ch 15 0----255 Pan adjustment Pan adjustment control Ch 16 0----255 Tilt Tilt control Ch 17 0----255 Tilt adjustment Tilt adjustment control Ch 18 zoom zoom 0----255 0~60° 0-155 Lens rotation Clockwise infinite rotation 156-205 Ch 19 Counterclockwise rotation...
  • Page 12 DMX channel´s functions and values (24 DMX channels): 24 channel mode： Channel Function Description Value Ch 1 pan adjustment pan adjustment 0----255 Ch 2 Pan fine adjustment Pan fine adjustment 0----255 Ch 3 Tilt adjustment Tilt adjustment 0----255 Ch 4 Tilt fine adjustment Pan fine adjustment 0----255...
  • Page 13 No function 0----9 Macro color 1 10----19 Macro color 2 20----29 ..(10 numbers 1 macro color) ..Macro color 19 190----199 Macro color Ch 15 Macro color 20 200----255 No function 0----9 Monochrome dynamic pattern 10----14 Monochrome dynamic pattern 15----19 ..(5numbers 1 pattern) ..
  • Page 14 Mixed color dynamic pattern 170----255 Pattern movement(with Ch 17 Pattern movement 0----255 16CH) No function 0----9 Ch 18 Pattern effect speed Forward, from fast to slow 10----132 Reverse, from slow to fast 133----255 Ch 19 Background R dark to bright 0----255 Ch 20 Background G...
  • Page 15 DMX channel´s functions and values (32 DMX channels): 32 channel mode： Channel Function Description Value Ch 1 pan adjustment pan adjustment 0----255 Ch 2 Pan fine adjustment Pan fine adjustment 0----255 Ch 3 Tilt adjustment Tilt adjustment 0----255 Ch 4 Tilt fine adjustment Pan fine adjustment 0----255...
  • Page 16 Ch 15 Blue dimming 0----255 Ch 16 Blue adjust Blue adjust 0----255 Ch 17 White dimming 0----255 Ch 18 White adjust White adjust 0----255 Mode -1 0 --- 49 Mode -2 50 --- 99 Ch 19 Dimming Mode Mode -3 100---149 Mode -4 150---255...
  • Page 17 Monochrome dynamic pattern 2 15----19 ..(5 numbers 1 pattern) ..Monochrome dynamic pattern 20 105----109 Mixed color dynamic pattern 1 110----114 Mixed color dynamic pattern 2 115----119 ..(5 numbers 1 pattern) ..Mixed color dynamic pattern 12 165----169 Mixed color dynamic pattern 13 170----255 Ch 23 Pattern movement...
  • Page 18 Ch 27 Background strobe Background strobe 0----255 Ch 28 Background R dark to bright 0----255 Ch 29 Background G dark to bright 0----255 Ch 30 Background B dark to bright 0----255 Ch 31 Background W dark to bright 0----255 no function 0----250 Ch 32 Reset...
  • Page 19 slow to fast Ch 8 Dimmer from dark to bright 0----255 Ch 9 Dimmer adjust Dimmer adjustment control 0----255 Turn on the light 0----3 Synchro strobe speed slow to fast Ch 10 Strobe 4----203 (1HZ-25HZ) Random strobe 204----255 Ch 11 Red dimming 0----255 Ch 12...
  • Page 20 Ch 21 Macro color Macro color 1 10----19 Macro color 2 20----29 ..(10 numbers 1 macro color) ..Macro color 19 190----199 Macro color 20 200----255 No function 0----9 Monochrome dynamic pattern 1 10----14 Monochrome dynamic pattern 2 15----19 ..(5 numbers 1 pattern) ..
  • Page 21 Ch 23 Pattern movement Pattern movement(with 22CH) 0----255 No function 0----9 Pattern effect Ch 24 Forward, from fast to slow 10----132 speed(with 22CH) Reverse, from slow to fast 133----255 Ch 25 Pattern effect fade Pattern effect fade 0----255 Ch 26 Background dimming Background 0-100% dimming 0----255 Ch 27...

  • Page 22: Shape

    Ch 36 LED1 W LED1 W dimming 0----255 ............. Ch 57 LED7 R LED7 R dimming 0----255 Ch 58 LED7 G LED7 G dimming 0----255 Ch 59 LED7 B LED7 B dimming 0----255 Ch 60 LED7 W LED7 W dimming 0----255 6.Shape...

  • Page 23: Trouble Shooting

    7. Trouble shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.

  • Page 24: Fixture Cleaning

    8. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
  • Page 25 SMALLY-PL740PE AC 100-240V, 50/60Hz Voltage: 7*40W 4IN1 RGBW LED LEDs IP20 IP Rating: Any safe working position Working Position: 250W Power Consumption: 3,5°-45° Beam Angle Pixel Control, RDM, DMX512/ Control: masterslave/Auto Run/ Music NET 5.6 kgs Weight: 258*178*334 mm Dimensions:...
