SPECIFICATIONS
AC110, 220, 230, 240V/50-60Hz
Power source
Power consumption
2/Turbo 110V, 230V 1200W
This service literature is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
CONTENTS
1 SCHEAMATIC DIAGRAM................................2
2 WIRING CONNECTION DIAGRAM....................2
(Separately available)
220V 1100W
240V 1300W
2/Low 110V, 230V 585W
220V 535W
240V 635W
Page
EH5934
Air flow velocity
Air volume
Air flow temperature
(in case of room temperature 30°C)
Cord length
Weight
4 TROUBLESHOOTING GUIDE.................................5
2001 Matsushita Electric Works(Thailand), Ltd.
C
All rights reserved. Unauthorized copying and
distribution is a violation of law.
Order No. PCD0411A81P3
Hair Dryer
13.5m/s(Turbo
1.1m3/min(Turbo)
115°C (Turbo), 120°C (High)
90°C (Low)
1.70m
410g(with nozle)
Page
)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EH5934 and is the answer not in the manual?

Questions and answers

Summary of Contents for Panasonic EH5934

  • Page 1: Table Of Contents

    Order No. PCD0411A81P3 Hair Dryer EH5934 SPECIFICATIONS 13.5m/s(Turbo AC110, 220, 230, 240V/50-60Hz Power source Air flow velocity 1.1m3/min(Turbo) (Separately available) Air volume Power consumption Air flow temperature 2/Turbo 110V, 230V 1200W 115°C (Turbo), 120°C (High) 220V 1100W 90°C (Low) 240V 1300W (in case of room temperature 30°C)
  • Page 2: Scheamatic Diagram

    1 SCHEMATIC DIAGRAM 2 WIRING CONNECTION DIAGRAM...
  • Page 3: Disassembly / Assembly Instruction

    3 DISASSEMBLY / ASSEMBLY INSTRUCTIONS (1) Assemble the heater block and motor block, and attach them into the housing B. (2) Attach the main switch push button, and insert the brown and green lead wires into the housing B as shown in Fig.1. Fig.1 (1) Insert the white, yellow, orange lead wires of selector switch, and blue, red lead wires of power cord into the housing B as shown in Fig.2.
  • Page 4 (4) Insert the selector switch, next power cord, Insert each lead wire into the handle B as shown in Fig.4. (5) Insert the cord bushing into handle B as shown in Fig.4. (6) Assemble the handle. (7) Fasten the 2 screws for handle, and 1 screw for housing AB. Fig.4 (1) Remove tapping screw 2.6-6.
  • Page 5: Troubleshooting Guide

    4 TROUBLESHOOTING GUIDE Refer to WIRING CONNECTION DIAGRAM.
  • Page 6: Exploded View & Replacement Parts List

    5 EXPLODED VIEW & REPLACEMENT PARTS LIST 5.1 EXPLODED VIEW...
  • Page 7 REPLACEMENT PARTS PRICE LIST     RMKS: *1= Available individually Ref. No. Parts No. Parts Name & Descriptions Per Unit RMKS EH5934HSDL1W HOUSING AB ASS'Y D/BLUE TAIWAN EH5934HSL1W HOUSING AB ASS'Y L/BLUE TAIWAN EH5934HSDL2W HOUSING AB ASS'Y D/BLUE OTHERS EH5934HSL2W HOUSING AB ASS'Y L/BLUE OTHERS...
