Table 20. Register 0x0F LIST_SOFT_TRIGGER (1 Byte)
Bit Type
[7:0] WO Soft Trigger
Table 21 Register 0x10 RF_FREQUENCY (6 Bytes)
Bit Type
[39:0] WO RF1 frequency word
Table 22 Register 0x11 RF_LEVEL (2 Bytes)
Bit Type
[14:0] WO RF1 Power Level
[15] WO Sign bit
Table 23 Register 0x12 RF_ENABLE (1 Byte)
Bit Type
[0] WO RF1 enable
[7:1] WO Unused
Table 24. Register 0x13 RF_PHASE (2 Byte)
Bit Type
[14:0] WO RF PHASE
[15] Sign
Table 25 Register 0x14 AUTO_LEVEL_DISABLE (1 Byte)
Bit Type
[0] WO RF1 Auto leveling
[7:1] WO Unused
Table 26 Register 0x15 RF_ALC_MODE (1 Byte)
Bit Type
[0] WO RF1 ALC mode
[7:1] WO Unused
SC5510B/11B User Manual
Name Width
Name Width
Name Width
Name Width
Name Width
Name Width
Name Width
Rev 1.2.0
8 Set all bits to 0. Calling this register provides a
soft trigger to the device.
40 Sets the RF1 frequency in mHz
15 Sets the RF1 Power level in hundreds of dB. To
set to 10.25 dB, write 1025 to this register
1 0 = positive number
1 = negative number
1 0 = disables the output power
1 = enables the output power
7 Set all bits to 0
15 The absolute value of phase in 0.1 deg
increments.
1 Set bit high to indicate value is negative, else
positive.
1 0 = power is leveled on frequency change
1 = power is not leveled on frequency change
with explicitly calling register 0x11 (RF_LEVEL)
7 Set all bits to 0
1 0 = Amplitude is corrected using ALC closed loop
1 = Amplitude is corrected opened loop.
7 Set all bits to 0
Description
Description
Description
Description
Description
Description
Description
