- Page 1 INSTALLATION MANUAL Model Max Load Display Sizes VESA LGWM-4365-R 110 lbs. (50 Kg) 43” to 65” 200x200 to 600x400...
- Page 2 NOTE: Read the en�re instruc�on manual before you start installa�on and assembly. WARNING Do not begin the installa�on un�l you have read understood all the • instruc�ons contained in this installa�on sheet. if you have any ques�ons regarding any of the instruc�ons or warnings please contact your local distributor This moun�ng bracket was designed to be installed and u�lized only as specified in •...
- Page 3 Ensure that you have received all parts according to the component checklist prior to installa�on. If any parts are missing or faulty, telephone your local distributor for a replacement LGWM-4365-R KIT VESA EXTENDED BRACKET Package M M6 X WASHER...
- Page 4 1. Product Dimensions +5°...
- Page 5 2. Bracket Installa�on STEP-1: Product wall plate fixed to the model so need to remove the screw as shown in the figure. Which separates the wall plate and TV fixing bracket. STEP-2: Remove the wall plate as shown in figure.
- Page 6 3. Fix the wall bracket to wall with moun�ng fasteners given in W-series pouch WARNING Installers must verify that the suppor�ng structures will safely support the combined weight of the equipment's and all the a�ached hardware and components...
- Page 7 4. This men�oned images and instruc�on is only for 200X200 to 400X400 vesa of display (Op�on-1) Clockwise direc�on(Landscape to portrait) OPTION -1 Fix the display in landscape mode when arrow mark is in right side direc�on. (Op�on-2) An�-clockwise direc�on(Landscape to portrait) OPTION 2 Fix the display in landscape mode when arrow mark is in le�...
- Page 8 5. Installing the Bracket to Display with vesa from 200x200 to 400x400 mm Fix the bracket to the display using M-series pouch.
- Page 9 6. Fixing the vesa extender to the bracket for 600X400 vesa For 600X400 vesa fix the vesa extender to the bracket as shown in figure with fasteners already fixed in it.
- Page 10 7. This men�oned images and instruc�on is only for 600X400mm vesa of display (Op�on-1) Clockwise direc�on(Landscape to portrait) STEP - 1 For 600X400, fix the extended brackets as shown in image to rota�onal mount when arrow mark is in right side direc�on. STEP - 2 Fix the display to the extended bracket in landscape mode.
- Page 11 8. Installing the Bracket to Display with Vesa 600X400 mm Fix the bracket to the display using M-series pouch.
- Page 12 9. SETTING DIFFERENT ANGLE TO THE BRACKET Loose these 5 screw if in case any �ght rota�on a�er the display moun�ng. Rotate the main frame to certain degree to set the angle. And �ght the men�oned screw.
- Page 13 10. Hooking the Display onto the Wall STEP-1: Hang the display on to the wall bracketas shown in figure.
- Page 14 11. Hooking the Display onto the Wall STEP-2: Put both the screw and �ght which are removed at start of the installa�on.
- Page 15 12. Tilt adjustment for ra�onal wall mount Loose this screw and set the required �l�ng angle to the display a�er that �ght the screw with allen key given. Maximum �l�ng op�on given is 5 degree.
- Page 16 13. View a�er installing the display View a�er installing the display on to the wall with the help of rota�onal wall bracket...
