Installation MANUAL
FLOOR MOUNT TROLLEY/AV CART
MODEL
SERIES
VESA
DISPLAY SIZE
MAX LOAD
LGFS-6598
FLOOR MOUNT
400x400 to
65" to 98"
265 lbs (120 kg)
TROLLEY/AV CART
900x600
www.logicav.in
Advertisement
Table of Contents
Related Manuals for Logic LGFS-6598
Summary of Contents for Logic LGFS-6598
- Page 1 INSTALLATION MANUAL FLOOR MOUNT TROLLEY/AV CART MODEL SERIES VESA DISPLAY SIZE MAX LOAD LGFS-6598 FLOOR MOUNT 400x400 to 65” to 98” 265 lbs (120 kg) TROLLEY/AV CART 900x600 www.logicav.in...
- Page 2 Checklist Castors x 4 (2 with lock, Connecting rod x 3 Interface 2 without lock) bracket x 2 M-B: M12 washer x 12 Right floor rail x 1 Left floor rail x 1 Screw Cap x 6 M-A: M8 x 15 x 12 M-C: M8 X 25 X 4 M-D: washer x 8 M-E:...
- Page 3 2. Installation Instructions for fixing floor mount. 1. Place the castors to bottom side of the base 2. Place the connecting rod as shown in the image left and right rail and tighten the castors 3. Inert the washer and screw 4.
- Page 4 5. Place the interface bracket on the TV/ display and insert washer and screw (Refer the checklist for the suitable screw and washer for the display/TV) 6. Place the TV/ display on the floor stand Cable Manager Final View after installing display/TV on the floor stand www.logicav.in...
