Product Description:
The Pro Frame Thin AT8K Series is a fixed frame projection screen that uses Elite ProAV's EDGE FREE®
technology. The EDGE FREE® design resembles a flat panel TV display. The Pro Frame Thin includes a micro-
thin bezel trim to further enhance the frame appearance and absorb projector overshoot.
The screen material included is our ISF certified CineWhite® A8K, which has an ultra-fine projection surface that
is acoustically transparent for front projection. It is precisely formulated for high-resolution projectors to offer
accurate color fidelity but also designed to allow speaker placement behind the screen while its bonded black backing
reduces light loss to enhance contrast.
In order for the CineWhite® A8K to maintain its projection qualities and optimum performance, please refer to the
list below for proper maintenance and cleaning.
•
Use a soft bristle brush to spot clean for dust.
•
Dip a soft bristle toothbrush in mild soap and water to clean light stains.
•
Never rub or apply pressure when cleaning the surface.
•
Never attempt to use any solutions, chemicals or abrasive cleaners on the screen surface.
•
To avoid damaging the screen, avoid touching it directly with your fingers, pens/pencils or any other
•
sharp or abrasive objects.
Qty
item
Part A.
Part B.
Part C.
08012024JA
1. Frame and Edge Trim Parts List
2 pcs
Main Frame Parts
vertical frame
½ horizontal frame
½ horizontal frame
www.eliteproav.com
Pro Frame Thin AT8K Series
Acoustically Transparent EDGE FREE®
Fixed Frame Projector Screen
USER'S GUIDE – V1.0
Visit
www.eliteproav.com
Qty
item
Part D.
Part E.
Part F.
for latest updated version.
2 pcs
Edge Trim Parts
U-00249
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Elite ProAV Pro Frame Thin AT8K Series
Summary of Contents for Elite ProAV Pro Frame Thin AT8K Series
- Page 1 Product Description: The Pro Frame Thin AT8K Series is a fixed frame projection screen that uses Elite ProAV’s EDGE FREE® technology. The EDGE FREE® design resembles a flat panel TV display. The Pro Frame Thin includes a micro- thin bezel trim to further enhance the frame appearance and absorb projector overshoot.
- Page 2 2. Hardware Parts List M4*4 D5*4 M4*4 D5*4 Black 110” 120” 135” 150” 138” 158” 166” 176” Item Parts List 16:9 2.35:1 Center Joints- M4 (bottom position) Center Joints-D5 (top position) Elbow Joints M4 (bottom position) Elbow Joints D5 (top position) Top wall brackets M4x7 Screws Spring...
-
Page 3: Frame Assembly
Frame Assembly Step 1: Place the included soft padded EPE sponge sheet on a clean area where the screen will be assembled. Step 2: Position the pieces of the frame on the EPE sponge in the arrangement shown below. Step 3: Insert center joint (a/b) connectors into one-half of the horizontal frame (B/C) and secure with the M4x7 screws (M) as shown in the illustration below. -
Page 4: Back Side
Screen Material Step 6: Put on the white gloves (p) and carefully unroll the screen material on a clean surface from the roller to the other side as shown below. The back side of the screen material should be placed upwards. Back Side Back side Front... - Page 5 Center Support Bar Step 9: Insert the Center Support Bar (o) into the upper top groove on the back of the frame with the bottom end near the approximate center point of the frame and rotate it in at an angle so that both ends of the bar are in alignment with the groove.
- Page 6 Continue attaching the rest of the springs to the material in the following order in steps 5-12. To avoid ripples forming in the material it is imperative that all of the corners are properly wrapped around the edges as illustrated in the check mark diagrams. Note (after all springs have been attached): Correct material installation –Corners of the screen material are properly wrapped around the corner edges of the frame and material is evenly tensioned and flat, creating a nicely taut surface.
-
Page 7: Wall Installation
Connect edge trim frames (e/f) together using the and secure with four of the Center Joints- M4(a) M4x4 Screws (m) as shown in Step 1. Repeat for other side. Once both top and bottom edge trim frames have been connected, attach the vertical (left/right) sides edge trim frames (d) using the and secure with four M4x4 screws (m) on all corners, Step 2. - Page 8 1), lift and secure on the top wall bracket, then push down at the Bracket center of the top of the frame (fig. 2) to secure. For Technical Support or an Elite ProAV contact Bottom Bracket in your area, visit www.elliteproav.com 08012024JA www.eliteproav.com...
