AV Yard Master Series
What's in the Box?
A. Screen material x 1
D. Ring-Stake x 4
G. M6*40
hexagonal screw
1. Assemble the frame by connecting the letters on the ends of the tubes together as shown in the
diagram below. For example, A to A, B to B etc.
2. A and J are attached and secured with the provided Hexagonal Screws (G)
Rev. 11/27/2018
Outdoor Movie Screen
User's Guide
B. Steel Tube x 12-14
E. Guy-rope x 4
x 2
H. Carrying bag x 1
J. Lock Pins (Spare parts) x 5

Frame Assembly

1
C. CurvedStake x 4
F. M6*40 hex nut x 2
I. Screen material bag x 1
eliteproav.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV Yard Master Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Elite ProAV AV Yard Master Series

  • Page 1 AV Yard Master Series Outdoor Movie Screen User’s Guide What’s in the Box? A. Screen material x 1 B. Steel Tube x 12-14 C. CurvedStake x 4 D. Ring-Stake x 4 E. Guy-rope x 4 F. M6*40 hex nut x 2 G.
  • Page 2 Take an example for 120” with 14pcs steel tube: Screen Material Assembly 1. Lay the assembled frame on the floor and take caution not to scratch the frame and/or floor surface. Note: The silver securing pegs on each end of the tube should be facing the floor. 2.
  • Page 3 Note: Guy-Ropes should be installed to the front and back of the frame Raise the frame verticallyon the ground and rotate the short tube on both sides of the foot stool 90° in the direction of the white screen so that that the holes on the frames are lined up.Finish attaching and securing the side frame to the feet with thehexagonal screws andhex nuts as shown below.
