Thank you for choosing the Presenter Pro CLR® 2 Series® projection screen! Please read through this user guide
before utilizing the screen. Correct usage and maintenance will ensure a long product life.
Care & Use Instructions
◆
Elite ProAV highly recommends two people to assemble the screen.
◆
The CLR® 2 is a Ceiling Ambient Light Rejecting screen material. It is a delicate optical/lenticular
material and should not be folded, bent or creased. Always maintain screen material flat and taut during
setup and disassembly.
*Elite ProAV is not responsible for damages due to negligence resulting from misuse or mishandling of the
product and will void your warranty.
Dust, dirt and debris on the projection screen surface will affect the quality and performance of the projection
image. Follow the instructions below to properly maintain the screen.
1) Clean the dust on the screen surface with a soft brush or microfiber cloth.
3) Gently wipe the screen with a lightly moistened white lint free cloth with water.
4) Avoid putting pressure on the screen material when wiping the screen. If dust or other debris is on the
surface, we recommend using an air sprayer to blow them away.
After using the screen, disassemble it and store it in the carrying bag provided.
*Make sure to keep the material protection film and tube for when disassembling the screen.
◆
To avoid damage and injury, the screen should only be operated by adults.
Notes: The following precautions should always be followed to avoid damaging the material, which is not
covered under warranty.
• Don't touch the screen material to avoid leaving fingerprints.
• Use gloves when handling the material.
• Don't allow the material to bend, fold or bunch as it will create permanent creases.
• Don't point to the screen material with a fingertip or other sharp objects to prevent damage to the
material.
• Don't use acetone, benzene, alcohol and any other organic solvents to clean the screen material. Using
such chemicals will permanently damage the screen
Rev.012324BR
Portable Indoor Ceiling Ambient Light Rejecting Screen
Visit
wwww.eliteproav.com
Presenter Pro CLR® 2
For tabletop/bottom mounted projectors
User's Guide – M type
www.eliteproav.com
U00274
Series
Folding-frame model
for latest updated version.
1
Advertisement
Table of Contents
Related Manuals for Elite ProAV Presenter Pro CLR 2 Series
Summary of Contents for Elite ProAV Presenter Pro CLR 2 Series
- Page 1 Always maintain screen material flat and taut during setup and disassembly. *Elite ProAV is not responsible for damages due to negligence resulting from misuse or mishandling of the product and will void your warranty.
- Page 2 Product Description Design: The aluminum frame is designed to be light weight and easy to handle when setting up or taking it down. Portability makes the screen easy to carry. Screen Fabric: The screen fabric is attached to the rectangular frame and held in place by Velcro which ensures an evenly stretched and flat surface.
- Page 3 3. Make sure all 4 corners of the frame are at a 90° angle and the hinged support bar is straight and not bending (Fig. 6-7). After unfolding the frame, make sure to lay it out with the Velcro facing up (Fig. 8). Fig.
- Page 4 Fig.13 8. Lay the protective foam sheet on a clean flat surface and flip the screen over on the backside and place it on top of the sheet (Fig. 13). Back side LEGS ATTACHMENT 9. Carefully take the folding legs (B) out of the carrying bag (E) and place them on a flat surface. Warning: The additional support sections, located at the middle section of the legs, may unfold on its own.
- Page 5 DRAPE/SKIRT INSTALLATION 14. Fasten the skirt(H) on the skirt hook (I), then attach along the bottom of the frame as shown below. Material front Material front front Notice to Installer: PROPER PROJECTOR PLACEMENT The CLR® 2 is exclusively for tabletop/bottom mounted ultra and short throw projectors.
- Page 6 Screen Disassembly TWO PEOPLE REQUIRED 1. Lay the protective foam sheet on a clean surface and unhinge the front of each leg, then SLOWLY lower the screen down on the foam sheet. NOTE: Front side of the material should be facing down on the protective foam sheet. 2.
- Page 7 7. Once the material has been completely rolled, insert the rolled material with the outer tube lying horizontally. DO NOT force it in as that will crush the ends and damage the material. If the material does not fit in snuggly, re-roll the material. 8.
