Seating Matters KIDZ PHOENIX Operation Manual & Product Specification page 7

KIDZ SORRENTO
TECHNICAL SPECIFICATION
F
E
G
H
K
D
iii
TM
B
C
I J
L
ii
iv
KIDZ PHOENIX™ and KIDZ SORRENTO™ Instruction Manual
Basic dimensions
A
B
C
D
Footplate height adjustments
E
A
F
Available seat and overall widths
G (Seat width)
250mm/10in*
300mm/12in
350mm/14in
400mm/16in
* This seat width is achieved using a 300mm/12in seat
and a set of 25mm/1in padded arm covers.
Arm height options
I
J
Seat depth
K
Clearence Height
L
Recline and tilt angles
ii Back angle recline
90° - 130°
40° range
iii Leg rest angle
90° - 125°
35° range
iv Tilt in space
From 5° forward, or anterior, tilt to 30°.
Chair weight unloaded is 51 Kg/112.4 lb/8.03 Stone.
Chair user weight limit is 159 Kg/364 lb/25 Stone.
Overall height 1160mm/45.5in
Back height 650mm/26in
Seat height 540mm/21in
Overall Length 1020mm/40in
High 250mm/10in from seat
Low 460mm/18in from seat
H (Overall width)
555mm/21.5in
555mm/21.5in
575mm/22.5in
625mm/22.5in
Low 715mm/28in
High 740mm/29in
290-380mm/11-15in
130mm/5in
5
