Seating Matters KIDZ PHOENIX Operation Manual & Product Specification page 11

There are also four options for seat depth
labelled A,B,C and D. (fig.3c) These
adjustments should only be made by a
Seating Matters approved provider.
A
B
C
D
• Arm removal: To remove the arms,
loosen the thumb screws behind and in
front of the arm (fig.3a,b & d) and carefully
pull the arm out, leaving it in a safe place
to avoid tripping hazards or other injuries.
When replacing the arms, ensure the
thumb screws are tightened against the
frame of the arm.
• Seat width adjustment:
in front of the arm (fig.3a,b & d) and carefully pull the arm out to the desired width (see
seat width table on page 4), secure the arms in place and ensure the thumb screws are
tightened against the frame of the arm.
• Arm height adjustment:
in front of the arm (fig.3a, b & d) and carefully remove the arm and insert it into the
desired height option on the frame of the chair (fig.3d). Secure the arms in place and
ensure the thumb screws are tightened against the frame of the arm.
KIDZ PHOENIX™ and KIDZ SORRENTO™ Instruction Manual
350 - 380mm
330 - 360mm
310 - 340mm
290 - 320mm
To adjust the seat width, loosen the thumb screws behind and
To adjust the arm height, loosen the thumb screws behind and
Arm removal
Seat depth
(fig.3b)
(fig.3c)
(fig.3d)
9
