- Page 1 SmartView Simple Imager System Instruction Manual Catalog No. MUV-IMG-CA MUV-IMG-CA-01 www.majorsci.com service@majorsci.com Version 10F Revised on :2023.07.13...
-
Page 2: Packing List
-1 × Darkroom Signed by: Date: Major Science is liable for all missing or damaged parts / accessories within 7 days after customer received this instrument package. Please contact Major Science immediately regarding this issue. If no response within such time period from consignee party, that will be consignee party’s whole... -
Page 3: Table Of Contents
Table of contents PACKING LIST ..........................1 WARNING ............................4 SECTION 1 INTRODUCTION ....................7 Overview ............................7 Features ............................7 Components guide ......................... 8 SECTION 2 TECHNICAL SPECIFICATIONS ................. 9 SECTION 3 INSTALLATION INSTRUCTIONS ..............11 Pre-install the Camera ........................11 Mount the Camera ........................ - Page 4 Radiographic Film ......................... 21 Sample Imaging ............................21 SECTION 5 TROUBLESHOOTING GUIDE AND MAINTENANCE ........ 22 SECTION 6 ORDERING INFORMATION ................23 SECTION 7 WARRANTY ......................24...
-
Page 5: Warning
8. The instrument is intended for scientific research use only, and must be operated by qualified personnel who realize the potential risks of the use of this instrument. Major Science makes no claim that its instruments are designed or certified as medical device; no presentation, promises, express warranty or implied warranty will be made concerning the suitability of these instruments for any medical use. - Page 6 Avoiding Electrical Shock Follow the guidelines below to ensure safe operation of the device. The SmartView Simple Imager System has been designed to utilize shielded wires thus minimizing any potential shock hazard to the user. Major Science recommends against the use of unshielded wires.
- Page 7 3. For proper ventilation and safety concerns, keep at least 10 cm of space behind the instrument, and at least 5 cm of space on each side. 4. Do not operate the SmartView Simple Imager System in high humidity environments (>95%), or where condensation may occur.
-
Page 8: Introduction
Section 1 Introduction 1.1 Overview The SmartView Simple Imager System offers you convenience and preference. The feature of its portable and light design, you are able to carry the equipment with ease. Also, with the compact camera, you can adapt the Imager System to our MS UV Transilluminator , and take pictures of your experiment results and view them directly on the camera screen. -
Page 9: Components Guide
1.3 Components guide Canon EOS M200 with Lens Kit Camera holder Darkroom(Hood) ▲ Front view ▲ Rear view... -
Page 10: Technical Specifications
Section 2 Technical Specifications MUV-IMG-CA Camera ★ For detailed specification of Canon EOS M200 Camera, please refer to Canon EOS M200 Camera User Guide. Model Canon EOS M200 Camera Type 24.1MP digital camera, Wi-Fi function Approx. 24.1 megapixels (Total Pixels Approx. 25.8 Effective Pixels megapixels) Sensor... - Page 11 (236x317x420 mm) Weight Approx. 3.1lbs. (1.4Kg) MUV-IMG-CA-01 Darkroom(Hood) Darkroom Material Acrylonitrile Butadiene Styrene (ABS) Camera Adapter Material Aluminum Darkroom Dimensions (W × L ×H) 9.29" x 12.48" x 16.54" (236x317x420 mm) Weight Approx. 3.1lbs. (1.4Kg) Note: Parts of the contents in this manual are excerpt from Canon EOS M200 Camera user guide.
-
Page 12: Installation Instructions
Section 3 Installation Instructions 3.1 Pre-install the Camera In normal situation, Step 1-5 have been done in the factory before shipping; user could directly jump to Step 6. Make sure the camera is off, and then Attach the lens. Align the mount index remove the cap. -
Page 13: Mount The Camera
Insert the SD card. Prepare filter. Fit and fix the filter on top of the lens. Fix camera to the camera adaptor on the chamber. Note: Make sure you have closed the battery cover properly; otherwise the camera cannot be activated. 3.2 Mount the Camera Fix camera to the camera adaptor Turn on the camera. -
Page 15: Set The Camera
Section 4 Set the Camera ★ In this chapter we provide table of recommended values, and they have already been set before shipping. You can go back and refer to this chapter anytime if you are not sure about the original setting before shipping. ★... -
Page 16: Setting M Mode And Each Parameter
4.2 Setting M Mode and Each Parameter This camera has three custom modes which could be selected via Mode Switch. They are Movie Mode , Hybrid Auto Mode , and Scene Intelligence Mode from left to right. We suggest switch the mode dial to Hybrid Auto Mode and set M mode for black&... - Page 17 Max for Auto 25600 ISO speed settings Max for Auto 12800 Auto Lighting Optimizer Disable Highlight tone priority Metering mode Metering timer 8 sec. Expo. simulation Enable White balance WB correction sRGB Picture Style Monochrome *Monochrome : for capturing images of DNA gels. *Standard : for coomassie blue and silver stain protein gels.
-
Page 18: Set Shutter Speeds & Aperture Values ([M] Mode)
4.3 Set Shutter Speeds & Aperture Values ([M] Mode) The following camera buttons and controls are represented by icons. I. When in the [M] mode, press the [ ] button, choose adjustment of shutter speed (1) or aperture value (2), and when [ ] is displayed, turn the [ ] dial to set a value. -
Page 19: Operation Instructions
Section 5 Operation Instructions The SmartView Simple Imager System provides various applications in gel documentation. Please refer to the operation guide below for detailed instruction. DNA Sample Imaging Place gel onto the center of UV transilluminator plate. Put the hood onto UV transilluminator. - Page 20 picture. Press button again to return image shooting mode. Under image viewing mode, press the button to delete the displayed image. Finish capturing image, please switch Camera off, and then turn off UV Transilluminator and main power. Take off hood and remove gel from UV transilluminator. Clean the UV transilluminator and dry the filter area.
-
Page 21: Protein Sample Imaging
Protein Sample Imaging Place gel onto the center of White light plate. Put the hood onto additional White light plate. Turn on camera and adjust the position of hood. Turn on the White light source. Use the mode dial to switch to M (for color photo). Set the aperture fixed on F3.5, change the Shutter Speed from 1/10, 1/20, 1/30. -
Page 22: Radiographic Film
Radiographic Film Place film onto the center of additional White light plate. Put the hood onto additional White light plate. Turn on camera and adjust the position of hood. Turn on the White light source. Use the mode dial to switch to M mode (for Black/White photo). We recommend setting Aperture fixed on F3.5;... -
Page 23: Troubleshooting Guide And Maintenance
Section 5 Troubleshooting Guide and Maintenance Many operating problems may be solved by carefully reading and following the instructions in this manual accordingly. Some suggestions for troubleshooting are given below. Should these suggestions not resolve the problem, please contact our SERVICE DEPARTMENT or a distributor in your region for assistance. -
Page 24: Ordering Information
Section 6 Ordering Information & A ODELS PPLICATIONS Cat. No. Description SmartView Simple 310 Imager System, with 24.1MP MUV-IMG-CA digital camera with built-in WiFi ★ FILTER ( Optional, Ordered Separately. FOR CAMERA DI-EB49 EtBr optical filter, 49mm DI-SG49 SYBR Green optical filter, 49mm... -
Page 25: Warranty
All claims made under this warranty must be presented to Major Science within one year following the date of delivery of the product to the customer.
