- Page 1 MD-MINI Dry Bath Instruction Manual Catalog No. MD-MINI www.majorsci.com service@majorsci.com Version 01C Revision on: 2023.06.28...
-
Page 2: Packing List
1x MD-MINI Dry Bath Instruction Manual Signed by: Date: Major Science is liable for all missing or damaged parts / accessories within 7 days after customer received this instrument package. Please contact Major Science immediately regarding this issue. If no response within such time period from consignee party, that will be consignee party’s whole responsibility. -
Page 3: Table Of Contents
Table of Contents Packing list ......................1 Warning ....................... 3 Section 1 Introduction..................6 1.1 Overview ..................... 6 1.2 Control and Features ................... 6 Section 2 Product Description ..............8 Section 3 Product Specifications ..............9 Section 4 Installation Instructions .............. 10 Section 5 Operating Instructions .............. -
Page 4: Warning
Warning Major Science MD-MINI Dry Bath has been tested and found to comply with safety limits for the CE regulation. Also, MD-MINI Dry Bath Incubator is RoHS compliant to deliver confident product which meets the environmental directive. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 5 Follow the guidelines below to ensure safe operation of the unit. Genius Dry Bath Incubator has been designed to use with shielded wires thus minimizing any potential shock hazard to the user. Major Science recommends against the use of unshielded wires.
- Page 6 dry before making any connections or operating the equipments. 5. ONLY connect the power cord to a properly grounded AC outlet. Avoiding Damage to the Instrument 1. Do not attempt to operate the device if it is damaged. 2. Protect this unit from physical damage, corrosive agents and extreme temperatures (direct sunlight, etc.).
-
Page 7: Introduction
Excellent temperature control figures can deliver accurate and reliable experimental results from one experiment to another. MD-MINI Dry Bath provides great values in term of space as well as the price. More importantly, MD-MINI Dry Bath is RoHS compliant and designed to comply with the CE regulation. - Page 8 Rear View Key – to increase temperature or time value Key – to decrease temperature or time value Key – to start or stop the program Key – switch between temp or timer mode (5) Temp – This LED lights up when the unit is operating under temperature setting mode.
-
Page 9: Product Description
Section 2 Product Description This single block MD-MINI Dry Bath uses interchangeable heating block modules for a variety of applications, includes restriction enzyme digestion, denaturing DNA, Blood Urea Nitrogen, melting agar, coagulation studies, hybridization, and Hot Start thermo-cycled reaction. Due to its molded aluminum alloy chamber, it can be applied as a mini water bath. -
Page 10: Product Specifications
Section 3 Product Specifications Controller Digital microprocessor controller Display LED display Heating Power 50 W Power Rating AC input : 100-240V~, 2A, 50/60 Hz DC input: +12V/5A, 60W max. Temperature Control Range 5°C above ambient to 100°C (Dry Bath) Temperature Control Range 5°C above ambient to 90°C (Water Bath) Temperature Increment... -
Page 11: Installation Instructions
Section 4 Installation Instructions Mini Dry Bath Incubator is actually a pre-installed instrument. As long as it is placed on a sturdy and leveled surface in a safe, dry place, as well as inserted with one aluminum block or simply add water as a mini-water bath, it is ready for operation. -
Page 12: Operating Instructions
Section 5 Operating Instructions 1. Place MD-MINI Dry Bath on a sturdy and leveled surface in a safe, dry place, away from laboratory traffic. 2. Ensure that the power switch is OFF, then plug the three-pronged power cord into a grounded three-prong AC outlet of the appropriate voltage. -
Page 13: Temperature Calibration
5.1 Temperature Calibration MD-MINI Dry Bath with the optional block has been calibrated as a set. However, different block types or different water source may have different influences and may cause different results. For optimum accurate temperature control, or while changing with different kinds of block or water, MD-MINI Dry Bath should be calibrated in accordance with the procedure outlined below. -
Page 14: Power Recover Function
5.2 Power Recover function 1. If MD-mini was turned off during the heating state and then turned back on again. It will buzz and display countdown from 10 to 0, then it will recover back to the last state. The timer will resume from last state as well. -
Page 15: Troubleshooting Guide
Maintenance MD-MINI Dry Bath may be cleaned with a moist cloth containing a mild soap solution. The chamber and blocks are constructed of aluminum alloy and may be cleaned with any of the commercial aluminum cleaners on the market. -
Page 16: Ordering Information
L71xW47xH32, Depth 30mm For 2.0ml or 1.5ml tube, ø 11.0mm, 12 wells, MD-MINI-B07 L71xW47xH32, Depth 30mm MS-BL95-E Block lifter 95mm, with E-Type Retaining Rings MD-MINI-CAR-ADAPTER Car Adapter for MD-MINI, 1.5m MD-MINI-LID MD-MINI Lid, 58.5x83x31.5mm Note: 1. Customized Aluminum block is also available. -
Page 17: Warranty
All claims made under this warranty must be presented to Major Science within one year following the date of delivery of the product to the customer. - Page 18 MEMO...
