- Page 1 AF-60 The JET mode of the AP-7 Jet Phaser Contents of this document are ©2023 Pedal Parts Ltd. No reproduction permitted without the express written permission of Pedal Parts Ltd. All rights reserved.
- Page 2 Important notes - DO NOT SKIP! If you’re using any of our footswitch daughterboards, DOWNLOAD THE DAUGHTERBOARD DOCUMENT • Download and read the appropriate build document for the daughterboard as well as this one BEFORE you start the build. • DO NOT solder the supplied Current Limiting Resistor (CLR) to the main circuit board even if there is a place for it.
- Page 3 Schematic + BOM 100K 1N5817 D2-3 1N4148 220K 250p 470K LM741 470K Q1-2 2N3904 GAIN** TONE 100KB 10u elec 50KA 10u elec 10u elec 100u elec 100u elec 100K *Original has a 47K resistor here, but there’s really no need. **Original has no gain control - it’s fixed at all-out wowzer.
- Page 5 The power and signal pads on the PCB conform To omit the GAIN control simply add a jumper as to the FuzzDog Direct Connection format, so can shown above in red in place of the pot. be paired with the appropriate daughterboard for quick and easy offboard wiring.
- Page 6 Test the board! Check the relevant daughterboard document for more info before you undertake this stage. UNDER NO CIRCUMSTANCES will troubleshooting help be offered if you have skipped this stage. No exceptions. Once you’ve finished the circuit it makes sense to test is before starting on the switch and LED wiring.
- Page 7 Now’s the time to refer to the daughterboard document for your chosen bypass method. Enjoy your pedal!
- Page 8 3 mm This template is a rough guide only. You should ensure correct marking of your enclosure before drilling. You use this template at your own risk. Pedal Parts Ltd can accept no responsibility for incorrect drilling of enclosures. FuzzDog.co.uk...
