Recurring Nightmare
Mad modulated fuzz delay
Contents of this document are ©2020 Pedal Parts Ltd.
No reproduction permitted without the express written
permission of Pedal Parts Ltd. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Recurring Nightmare and is the answer not in the manual?

Questions and answers

Summary of Contents for FuzzDog Recurring Nightmare

  • Page 1 Recurring Nightmare Mad modulated fuzz delay Contents of this document are ©2020 Pedal Parts Ltd. No reproduction permitted without the express written permission of Pedal Parts Ltd. All rights reserved.
  • Page 2: Important Notes

    Important notes If you’re using any of our footswitch daughterboards, DOWNLOAD THE DAUGHTERBOARD DOCUMENT • Download and read the appropriate build document for the daughterboard as well as this one BEFORE you start. • DO NOT solder the supplied Current Limiting Resistor (CLR) to the main circuit board even if there is a place for it.
  • Page 3 Schematic + BOM 100n XR2206P** 100n PT2399 7660S*** MC33172P ‡ 14001 D2-3 14001 1u elec 78L05 100n BLEND 1OOKB 10u elec DEPTH 100KC 1u elec FBACK 100KC 1u elec FUZZ 1u elec SPEED 1u elec TIME 100KA 220R 10u elec 100KA 10u elec 680R...
  • Page 5 PCB layout ©2019 Pedal Parts Ltd. 9V or 18V supply? The power and signal pads on the PCB conform to the FuzzDog Direct Connection format, so can be paired with the appropriate The circuit works best at 18V, so we’ve included...
  • Page 6 Testing You can test the Distortion and Boost sections individually, as if they’re separate boards. Do the test wiring as shown below for each section. UNDER NO CIRCUMSTANCES will troubleshooting help be offered if you have skipped this stage. No exceptions. Solder some nice, long lengths of wire to the board connections for 9V, GND, IN and OUT.
  • Page 7 Wire it up (if using a daughterboard please refer to the relevant document) BOARD BOARD INPUT BOARD BOARD BOARD BOARD BOARD BOARD BATTERY Wiring shown above will disconnect the battery when you remove the jack plug from the input, and also when a DC plug is inserted. The Board GND connections don’t all have to directly attach to the board.
  • Page 8: Drilling Template

    Drilling template Recommended drill sizes: Pots Jacks 10mm Hammond 1590BB Footswitch 12mm DC Socket 8/12mm Toggle switches It’s a good idea to drill the pot and toggle switch holes 1mm bigger if you’re board-mounting them. 30mm 30mm 20mm FuzzDog.co.uk...
