Page 1 All manuals and user guides at all-guides.com SXV70G/SXV70ERG SXV70G SXV70ERG...
Page 2 All manuals and user guides at all-guides.com F O R E W O R D NOTICE HOW TO USE THIS MANUAL MANUAL FORMAT EXLODED DIAGRAM...
Page 3: Illustrated Symbols
All manuals and user guides at all-guides.com ILLUSTRATED SYMBOLS...
Page 4 All manuals and user guides at all-guides.com INDEX...
Page 5 All manuals and user guides at all-guides.com...
Page 6 All manuals and user guides at all-guides.com...
Page 7 All manuals and user guides at all-guides.com GENERAL INFORMATION MACHINE IDENTIFICATION FRAME SERIAL NUMBER ENGINE SERIAL NUMBER...
Page 8: Special Tools
All manuals and user guides at all-guides.com SPECIAL TOOLS...
Page 9 All manuals and user guides at all-guides.com...
Page 10 All manuals and user guides at all-guides.com...
Page 11 All manuals and user guides at all-guides.com PERIODIC INSPECTIONS AND ADJUSTMENTS INTRODUCTION PERIODIC MAINTENANCE TABLE...
Page 12 All manuals and user guides at all-guides.com...
Page 13 All manuals and user guides at all-guides.com ENGINE OIL PUMP...
Page 14 All manuals and user guides at all-guides.com...
Page 15: Cooling System
All manuals and user guides at all-guides.com COOLING SYSTEM...
Page 16 All manuals and user guides at all-guides.com...
Page 17 All manuals and user guides at all-guides.com...
Page 18 All manuals and user guides at all-guides.com...
Page 19 All manuals and user guides at all-guides.com HEAT SHELD CLAMP REPLACEMENT...
Page 20 All manuals and user guides at all-guides.com YAMAHA POWER VALVE SYSTEM (Y.P.V.S.) ADJUSTMENT...
Page 21 All manuals and user guides at all-guides.com YAMAHA POWER VALVE SYSTEM (Y.P.V.S.) PRE-SEASON CHECKS...
Page 22 All manuals and user guides at all-guides.com...
Page 23 All manuals and user guides at all-guides.com POWER TRAIN SHEAVE DISTANCE AND OFFSET ADJUSTMENT...
Page 24 All manuals and user guides at all-guides.com...
Page 25 All manuals and user guides at all-guides.com ENGAGEMENT SPEED CHECK TRACK TENSION ADJUSTMENT...
Page 26 All manuals and user guides at all-guides.com CHASSIS SKI/SKI RUNNER STEERING SYSTEM...
Page 27 All manuals and user guides at all-guides.com ELECTRICAL HEADLIGHT BEAM ADJUSTMENT FUSE INSPECTION (SXV70ER)
Page 28 All manuals and user guides at all-guides.com...
Page 29: Speedometer Unit Inspection
All manuals and user guides at all-guides.com SPEEDOMETER UNIT INSPECTION...
Page 30 All manuals and user guides at all-guides.com TUNING CARBURETOR TUNING...
Page 31 All manuals and user guides at all-guides.com...
Page 32 All manuals and user guides at all-guides.com...
Page 33 All manuals and user guides at all-guides.com...
Page 34 All manuals and user guides at all-guides.com...
Page 35 All manuals and user guides at all-guides.com...
Page 36 All manuals and user guides at all-guides.com...
Page 37 All manuals and user guides at all-guides.com CLUTCH...
Page 38: Gear Selection
All manuals and user guides at all-guides.com GEAR SELECTION...
Page 39 All manuals and user guides at all-guides.com...
Page 40 All manuals and user guides at all-guides.com...
Page 41 All manuals and user guides at all-guides.com...
Page 42 All manuals and user guides at all-guides.com...
Page 43 All manuals and user guides at all-guides.com...
Page 44: High Altitude Tuning
All manuals and user guides at all-guides.com HIGH ALTITUDE TUNING...
Page 45: Front Suspension
All manuals and user guides at all-guides.com FRONT SUSPENSION...
Page 46: Rear Suspension
All manuals and user guides at all-guides.com REAR SUSPENSION...
Page 47 All manuals and user guides at all-guides.com...
Page 48 All manuals and user guides at all-guides.com...
Page 49 All manuals and user guides at all-guides.com...
Page 50 All manuals and user guides at all-guides.com CHASSIS STEERING...
Page 51 All manuals and user guides at all-guides.com...
Page 52: Installation
All manuals and user guides at all-guides.com INSTALLATION...
Page 53 All manuals and user guides at all-guides.com...
Page 54 All manuals and user guides at all-guides.com...
Page 55 All manuals and user guides at all-guides.com FRONT SUSPENSION...
Page 56 All manuals and user guides at all-guides.com HANDLING NOTES INSPECTION...
Page 57 All manuals and user guides at all-guides.com INSTALLATION...
Page 58 All manuals and user guides at all-guides.com...
Page 59 All manuals and user guides at all-guides.com...
Page 60 All manuals and user guides at all-guides.com POWER TRAIN PRIMARY SHEAVE AND DRIVE V-BELT...
Page 61 All manuals and user guides at all-guides.com...
Page 62 All manuals and user guides at all-guides.com INSPECTION...
Page 63: Secondary Sheave
All manuals and user guides at all-guides.com SECONDARY SHEAVE...
Page 64 All manuals and user guides at all-guides.com...
Page 65 All manuals and user guides at all-guides.com INSPECTION ASSEMBLY...
Page 66 All manuals and user guides at all-guides.com...
Page 67 All manuals and user guides at all-guides.com...
Page 68 All manuals and user guides at all-guides.com DRIVE CHAIN HOUSING SXV70...
Page 69 All manuals and user guides at all-guides.com INSPECTION...
Page 70 All manuals and user guides at all-guides.com...
Page 71: Installation
All manuals and user guides at all-guides.com INSTALLATION...
Page 72 All manuals and user guides at all-guides.com SXV70ER...
Page 73 All manuals and user guides at all-guides.com...
Page 74: Slide Rail Suspension
All manuals and user guides at all-guides.com SLIDE RAIL SUSPENSION...
Page 75 All manuals and user guides at all-guides.com...
Page 76 All manuals and user guides at all-guides.com...
Page 77 All manuals and user guides at all-guides.com...
Page 78 All manuals and user guides at all-guides.com...
Page 79 All manuals and user guides at all-guides.com INSPECTION ASSEMBLY...
Page 80 All manuals and user guides at all-guides.com...
Page 81: Front Axle And Track
All manuals and user guides at all-guides.com FRONT AXLE AND TRACK...
Page 82 All manuals and user guides at all-guides.com INSPECTION INSTALLATION...
Page 83 All manuals and user guides at all-guides.com ENGINE EXHAUST ASSEMBLY...
Page 84: Installation
All manuals and user guides at all-guides.com INSTALLATION...
Page 85: Engine Assembly
All manuals and user guides at all-guides.com ENGINE ASSEMBLY...
Page 86 All manuals and user guides at all-guides.com INSPECTION INSTALLATION...
Page 87: Cylinder Head And Cylinder
All manuals and user guides at all-guides.com CYLINDER HEAD AND CYLINDER...
Page 88 All manuals and user guides at all-guides.com...
Page 89 All manuals and user guides at all-guides.com INSPECTION...
Page 90 All manuals and user guides at all-guides.com...
Page 91 All manuals and user guides at all-guides.com INSTALLATION...
Page 92 All manuals and user guides at all-guides.com...
Page 93 All manuals and user guides at all-guides.com...
Page 94: Oil Pump, Crankcase And Crankshaft
All manuals and user guides at all-guides.com OIL PUMP, CRANKCASE AND CRANKSHAFT...
Page 95 All manuals and user guides at all-guides.com INSPECTION...
Page 96 All manuals and user guides at all-guides.com...
Page 97 All manuals and user guides at all-guides.com INSTALLATION...
Page 98 All manuals and user guides at all-guides.com...
Page 99 All manuals and user guides at all-guides.com AC MAGNETO...
Page 100 All manuals and user guides at all-guides.com INSTALLATION...
Page 101 All manuals and user guides at all-guides.com...
Page 102: Recoil Starter
All manuals and user guides at all-guides.com RECOIL STARTER...
Page 103 All manuals and user guides at all-guides.com INSPECTION...
Page 104 All manuals and user guides at all-guides.com INSTALLATION...
Page 105 All manuals and user guides at all-guides.com YAMAHA POWER VALVE SYSTEM (Y.P.V.S.)
Page 106 All manuals and user guides at all-guides.com...
Page 107 All manuals and user guides at all-guides.com R E M O V A L INSPECTION ASSEMBLY...
Page 108 All manuals and user guides at all-guides.com...
Page 109 All manuals and user guides at all-guides.com INSTALLATION...
Page 110 All manuals and user guides at all-guides.com COOLING SYSTEM HEAT EXCHANGER...
Page 111 All manuals and user guides at all-guides.com INSPECTION...
Page 112 All manuals and user guides at all-guides.com THERMOSTAT...
Page 113 All manuals and user guides at all-guides.com INSPECTION...
Page 114 All manuals and user guides at all-guides.com INSTALLATION...
Page 115 All manuals and user guides at all-guides.com CARBURETION CARBURETORS...
Page 116 All manuals and user guides at all-guides.com...
Page 117 All manuals and user guides at all-guides.com...
Page 118 All manuals and user guides at all-guides.com...
Page 119 All manuals and user guides at all-guides.com THROTTLE POSITION SENSOR (T.P.S.) INSPECTION AND ADJUSTMENT...
Page 120 All manuals and user guides at all-guides.com...
Page 121 All manuals and user guides at all-guides.com INSTALLATION...
Page 122 All manuals and user guides at all-guides.com ELECTRICAL SWITCH INSPECTION SWITCH INSPECTION INSPECTING A SWITCH SHOWN IN THE MANUAL...
Page 123: Combination Meter Function
All manuals and user guides at all-guides.com COMBINATION METER FUNCTION...
Page 124 All manuals and user guides at all-guides.com LIGHTING SYSTEM CIRCUIT DIAGRAM...
Page 125: Troubleshooting
All manuals and user guides at all-guides.com TROUBLESHOOTING...
Page 126: Headlight Beam Switch
All manuals and user guides at all-guides.com BULB(S) HEADLIGHT BEAM SWITCH...
Page 127: Headlight Relay
All manuals and user guides at all-guides.com HEADLIGHT RELAY...
Page 128 All manuals and user guides at all-guides.com YAMAHA POWER VALVE SYSTEM (Y.P.V.S.) CIRCUIT DIAGRAM...
Page 129 All manuals and user guides at all-guides.com TROUBLESHOOTING...
Page 130 All manuals and user guides at all-guides.com SERVOMOTOR...
Page 131 All manuals and user guides at all-guides.com SELF-DIAGNOSIS FUEL METER, FUEL LEVEL WARNING INDICATOR AND THE WARNING LIGHT COOLANT TEMPERATURE WARNING LIGHT AND THE WARNING LIGHT...
Page 132: Self-Diagnosis Warning Indicator And The Warning Light
All manuals and user guides at all-guides.com SELF-DIAGNOSIS WARNING INDICATOR AND THE WARNING LIGHT...
Page 133 All manuals and user guides at all-guides.com...
Page 134: Specifications General Specifications
All manuals and user guides at all-guides.com SPECIFICATIONS GENERAL SPECIFICATIONS...
Page 135 All manuals and user guides at all-guides.com...
Page 136: Maintenance Specifications
All manuals and user guides at all-guides.com MAINTENANCE SPECIFICATIONS...
Page 137 All manuals and user guides at all-guides.com...
Page 138 All manuals and user guides at all-guides.com...
Page 139 All manuals and user guides at all-guides.com...
Page 140 All manuals and user guides at all-guides.com...
Page 141 All manuals and user guides at all-guides.com...
Page 142 All manuals and user guides at all-guides.com...
Page 143 All manuals and user guides at all-guides.com...
Page 144 All manuals and user guides at all-guides.com...
Page 145: High Altitude Settings
All manuals and user guides at all-guides.com HIGH ALTITUDE SETTINGS...
Page 146: Tightening Torque
All manuals and user guides at all-guides.com TIGHTENING TORQUE...
Page 147 All manuals and user guides at all-guides.com...
Page 148 All manuals and user guides at all-guides.com...
Page 149 All manuals and user guides at all-guides.com...
Page 150: General Torque Specifications Definition Of Units
All manuals and user guides at all-guides.com GENERAL TORQUE SPECIFICATIONS DEFINITION OF UNITS...
Page 151: Cable Routing
All manuals and user guides at all-guides.com CABLE ROUTING...
Page 152 All manuals and user guides at all-guides.com...
Page 153 All manuals and user guides at all-guides.com...
Page 154 All manuals and user guides at all-guides.com...
Page 155 All manuals and user guides at all-guides.com...
Page 156 All manuals and user guides at all-guides.com...
Page 157 All manuals and user guides at all-guides.com...
Page 158 All manuals and user guides at all-guides.com...
Page 159 All manuals and user guides at all-guides.com...
Page 160 All manuals and user guides at all-guides.com...
Page 161 All manuals and user guides at all-guides.com...
Page 162 All manuals and user guides at all-guides.com...
Page 163 All manuals and user guides at all-guides.com...
Page 164 All manuals and user guides at all-guides.com...
Page 165 All manuals and user guides at all-guides.com...
Page 166 All manuals and user guides at all-guides.com...
Page 167 All manuals and user guides at all-guides.com...
Page 168 All manuals and user guides at all-guides.com...
Page 169 All manuals and user guides at all-guides.com...
Page 170 All manuals and user guides at all-guides.com...
Page 171 All manuals and user guides at all-guides.com...
Page 172: Wiring Diagram
All manuals and user guides at all-guides.com WIRING DIAGRAM...

This manual is also suitable for:

Sxv70erg

Yamaha SXV70G Service Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Yamaha SXV70G

Summary of Contents for Yamaha SXV70G

This manual is also suitable for:

Table of Contents
